TP-LINK SG2210P Omada 10-Port Gigabit Smart Switch with 8-Port PoE+ - 61W Budget - 2 SFP Slots - Layer 2 Managed
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Layer 2 managed switch provides advanced networking features including VLAN, Access Control Lists (ACL), Quality of Service (QoS), and IGMP snooping for efficient traffic segmentation and prioritization. It supports link aggregation, loopback detection, and broadcast/multicast/unicast storm control to enhance network stability and performance.
The switch complies with IEEE 802.3af and 802.3at PoE standards, delivering up to 30 watts per PoE+ port. Its dual SFP slots support 100/1000Base-X fiber or copper uplinks, extending network reach and bandwidth. Data transfer rates reach 128 MB/s across twisted pair or optical fiber media.
Relevant factors for this section include Data Link Protocols, Features, Total Number of Network Ports, Network (RJ-45). When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SG2210P balances PoE capacity, management capabilities, and physical durability for cost-effective network expansion. Its 61-watt PoE budget powers multiple devices simultaneously, while the dual SFP slots provide fiber-ready uplinks for backbone connectivity or long-distance runs.
Centralized & Standalone Management
Manage the switch through the Omada cloud platform for unified control across sites, or use local web, CLI, SNMP, and RMON interfaces for standalone operation. Zero-Touch Provisioning (ZTP) simplifies deployment.
- Omada cloud management
- Web/CLI/SNMP/RMON
- Zero-Touch Provisioning
Robust Feature Set
Includes VLAN, ACL, QoS, IGMP snooping, DHCP relay, and static routing to optimize traffic flow, security, and internal routing efficiency in growing networks.
- VLAN & ACL
- QoS & IGMP Snooping
- Static Routing
Deployment / Use Cases
Ideal for small offices, retail stores, or branch locations needing reliable PoE and managed switching. The eight PoE+ ports efficiently support VoIP phones, wireless access points, and IP cameras, reducing cable clutter and power adapter requirements.
The dual SFP slots enable fiber uplinks to core switches or connections over longer distances, making it suitable for multi-floor deployments or connections between buildings. Its desktop or wall-mount form factor fits neatly in wiring closets, under desks, or on wall racks.
Unified PoE Deployment
Power and connect up to eight PoE+ devices like access points and cameras from a single switch, simplifying installation and reducing power outlet needs.
Fiber-Ready Edge Switching
Use SFP modules for high-speed fiber uplinks to aggregate traffic or connect over extended distances, ensuring reliable backbone connectivity.
Physical Profile
The switch features a compact metal chassis measuring 8.20" wide, 4.90" deep, and 1" tall, with a desktop and wall-mountable design. Its fanless construction ensures silent operation in quiet environments, while included rubber feet provide stability on desks. The durable metal casing offers robust protection for continuous operation.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 1" (25.40 mm), 8.20" (208.28 mm), 4.90" (124.46 mm). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 8.20" (208.28 mm)
- Depth
- 4.90" (124.46 mm)
- Height
- 1" (25.40 mm)
What's in the Box
The package includes all essential components for immediate deployment.
Highlights
- 8 Gigabit PoE+ ports with 61W total budget
- 2 SFP slots for fiber or copper uplinks
- Layer 2 managed with VLAN, ACL, QoS, IGMP snooping
- Omada cloud management and standalone web/CLI/SNMP
- Fanless metal design for silent operation
- Desktop or wall-mountable form factor
- Supports IEEE 802.3af/at PoE standards
- Zero-Touch Provisioning for easy deployment
Specifications
| Specifications | |
|---|---|
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | SG2210P |
| Brand Name | Omada |
| Product Model | SG2210P |
| Product Name | 10-Port Gigabit Smart Switch with 8-Port PoE+ |
| Product Type | Ethernet Switch |
| Technical Information | |
| Data Link Protocols | HTTP,HTTPs |
| Features | Virtual LAN (VLAN),Access Control List,Quality of Service (QoS),IGMP Snooping,Zero-Touch Provisioning (ZTP),Fanless,Reset Button,Auto-negotiation,Broadcast Storm Control,Multicast Storm Control,Unicast Storm Control,DHCP Relay,Link Aggregation,Loopback Detection,Flow Control,Remote Monitoring (RMON) |
| Interfaces/Ports | |
| Total Number of Network Ports | 8 |
| Network (RJ-45) | Yes |
| Port/Expansion Slot Details | 8 x Gigabit Ethernet PoE+,2 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 10/100/1000Base-T,100/1000Base-X |
| Maximum Data Transfer Rate | 128 MB/s |
| I/O Expansions | |
| Total Number of Expansion Slots | 2 |
| Expansion Slot Type | SFP |
| Number of SFP Slots | 2 |
| Network & Communication | |
| Layer Supported | 2 |
| Networking Standards | IEEE 802.3af,IEEE 802.3at,IEEE 802.1p,IEEE 802.3x,IEEE 802.1ab,IEEE 802.1Q,IEEE 802.1x |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| PoE (RJ-45) Port | Yes |
| PoE Budget | 61 W |
| Input Voltage | 110 V |
| Power Source | Power Adapter,DC |
| Power Consumption | 77.80 W |
| Physical Characteristics | |
| Product Material | Metal |
| Form Factor | Desktop,Wall Mountable |
| Height | 1" (25.40 mm) |
| Width | 8.20" (208.28 mm) |
| Depth | 4.90" (124.46 mm) |
| Miscellaneous | |
| Package Contents | 10-Port Gigabit Smart Switch with 8-Port PoE+ Power Adapter Installation Guide Rubber Feet |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
FAQ
How many PoE+ ports does the SG2210P have, and what is the total PoE budget?
The SG2210P has eight Gigabit PoE+ ports with a total PoE budget of 61 watts. This budget supports IEEE 802.3af and 802.3at standards, delivering up to 30 watts per port to power devices like IP phones, wireless access points, and security cameras simultaneously.
What are the SFP slots used for on this switch?
The two SFP slots provide uplink connectivity for fiber or copper Gigabit Ethernet (100/1000Base-X). They allow for extended distance connections, backbone links to core switches, or integration into fiber-based network segments, offering flexibility beyond standard twisted-pair cabling.
Is the SG2210P a managed switch, and what management options are available?
Yes, it is a Layer 2 managed switch. Management options include centralized cloud control via the Omada platform, as well as standalone management through a web interface, command-line interface (CLI), SNMP, and RMON. This allows for both unified multi-site administration and local configuration.
Does this switch support VLAN and QoS for network traffic control?
Yes, the SG2210P supports Virtual LAN (VLAN) for segmenting network traffic and Quality of Service (QoS) for prioritizing critical data. These features help optimize bandwidth usage, improve security, and ensure reliable performance for voice, video, and data applications.
What is the form factor, and can the switch be wall-mounted?
The switch has a compact desktop form factor with dimensions of 8.20" wide, 4.90" deep, and 1" tall. It is designed for both desktop placement and wall mounting, offering installation flexibility in offices, retail spaces, or wiring closets. The metal casing ensures durability.
Is the switch fanless, and what are the benefits of a fanless design?
Yes, the SG2210P features a fanless design, which eliminates moving parts for silent operation. This makes it ideal for noise-sensitive environments like offices, classrooms, or retail areas. The fanless construction also reduces dust intake and potential points of failure, enhancing reliability.
