Product Features
Technical Overview
This SFP module operates on the 1000Base-LX standard, supporting data rates of 1 Gbps over single-mode optical fiber. It utilizes an LC duplex connector interface, which is widely adopted in enterprise and data center environments for its compact size and reliable performance. The dual wavelength capability enables efficient bidirectional communication, optimizing fiber utilization and reducing infrastructure costs.
The module's design incorporates advanced optical components to maintain signal integrity over its 20km reach, ensuring low bit error rates and stable network performance. It is compatible with both Gigabit Ethernet and Fiber Channel protocols, making it suitable for a variety of high-speed networking applications. The hot-pluggable form factor adheres to industry standards, allowing for easy deployment and management in dynamic network environments.
Key Product Advantages
The TRENDnet TEG-MGBS20D3 SFP module offers several advantages for network administrators seeking reliable and compliant optical connectivity. Its dual wavelength design enhances fiber efficiency, while the 20km reach supports long-distance links without signal degradation. The module's MSA compliance guarantees interoperability with a broad ecosystem of networking hardware, reducing compatibility concerns and simplifying procurement.
Extended Reach
Supports transmission distances up to 20 kilometers over single-mode fiber, ideal for connecting remote network segments or campus environments.
- 20km maximum distance
- Single-mode fiber optimized
- Low signal loss
Compliance & Certification
MSA compliant for broad hardware compatibility and TAA compliant to meet U.S. and Canadian government procurement standards.
- MSA standards adherence
- TAA certification
- NDAA compliant
Hot-Pluggable Design
Allows installation and removal without disrupting network operations, enabling maintenance and upgrades with minimal downtime.
- Live insertion/removal
- No power cycling required
- Easy module swaps
Deployment / Use Cases
The TEG-MGBS20D3 is well-suited for enterprise networks, data centers, and service provider environments where reliable long-distance fiber connectivity is required. It can be deployed in switches, routers, or media converters to extend Gigabit Ethernet or Fiber Channel links across buildings, campuses, or metropolitan areas. The module's single-mode fiber support makes it ideal for high-bandwidth applications that demand low latency and high signal integrity.
Common use cases include connecting network equipment in separate facilities, uplinking between distribution and core switches, and supporting storage area networks (SANs) over Fiber Channel. The hot-pluggable feature facilitates quick deployment in modular chassis systems, while the TAA compliance ensures eligibility for government and educational projects requiring certified components.
Campus Network Extension
Connect buildings across a campus with 20km single-mode fiber links, maintaining high-speed data transfer for voice, video, and data applications.
Data Center Interconnects
Link switches or routers within or between data centers to support Gigabit Ethernet or Fiber Channel traffic, ensuring scalable and resilient network infrastructure.
Physical Profile
The module features a compact form factor with dimensions of 0.50" (12.70 mm) in height, 0.50" (12.70 mm) in width, and 2.20" (55.88 mm) in depth, weighing approximately 9.60 oz (272.16 g). Its small size allows for high-density installations in networking equipment, maximizing port utilization without sacrificing performance. The robust construction ensures durability in various operating environments, from controlled data centers to industrial settings.
- Width
- 0.50" (12.70 mm)
- Depth
- 2.20" (55.88 mm)
- Height
- 0.50" (12.70 mm)
- Weight
- 9.60 oz (272.16 g)
What's in the Box
Each package includes the SFP dual wavelength single-mode LC module (20km) and a quick installation guide to assist with setup and configuration.
Highlights
- Dual wavelength SFP module for single-mode fiber networks
- Supports Gigabit Ethernet and Fiber Channel up to 20km reach
- LC duplex connector interface for reliable optical connectivity
- Hot-pluggable design for easy installation and maintenance
- MSA compliant for broad hardware compatibility
- TAA compliant (U.S. and Canada only)
- Compact dimensions: 0.50" x 0.50" x 2.20"
- Includes quick installation guide
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TEG-MGBS20D3 |
| Brand Name | TRENDnet |
| Product Name | SFP Dual Wavelength Single Mode LC Module (20km) |
| Product Condition | New |
| Product Type | SFP (mini-GBIC) |
| Technical Information | |
| Application/Usage | Optical Network,Data Networking |
| Interfaces/Ports | |
| Total Number of Ports | 1 |
| Connector Type | LC |
| Interfaces/Ports Details | 1 x LC Duplex 1000Base-LX Network |
| Media & Performance | |
| Media Type Supported | Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-LX,Fiber Channel |
| Physical Characteristics | |
| Form Factor | Hot-pluggable |
| Height | 0.50" (12.70 mm) |
| Width | 0.50" (12.70 mm) |
| Depth | 2.20" (55.88 mm) |
| Weight (Approximate) | 9.60 oz (272.16 g) |
| Miscellaneous | |
| Package Contents | SFP Dual Wavelength Single Mode LC Module (20km) Quick Installation Guide |
| Compatibility | MSA Compliant |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the maximum transmission distance of this SFP module?
The TRENDnet TEG-MGBS20D3 SFP module supports transmission distances up to 20 kilometers over single-mode optical fiber. This reach makes it suitable for connecting network segments across campuses, between buildings, or in metropolitan area networks where long-distance links are required without signal repeaters.
Is this module compatible with my existing networking equipment?
Yes, the module is MSA (Multi-Source Agreement) compliant, ensuring broad compatibility with a wide range of switches, routers, and media converters from various manufacturers. It is designed to work with devices that support SFP slots and the 1000Base-LX standard, but always verify compatibility with your specific hardware model before purchase.
What type of fiber connector does this SFP module use?
This module uses an LC duplex connector, which is a small form-factor connector commonly used in high-density networking environments. The LC interface provides reliable optical connections with low insertion loss, making it ideal for single-mode fiber applications in enterprise and data center networks.
Does this SFP module support hot-plugging?
Yes, the TEG-MGBS20D3 features a hot-pluggable design, allowing you to install or remove the module without powering down the host networking device. This capability minimizes network downtime during maintenance, upgrades, or module replacements, supporting continuous operation in critical environments.
What is the significance of TAA compliance for this module?
TAA (Trade Agreements Act) compliance indicates that the module meets U.S. and Canadian government procurement requirements, ensuring it is manufactured or substantially transformed in a designated country. This certification is essential for projects funded by government agencies or institutions that mandate TAA-compliant components for security and regulatory adherence.
Can this module be used for both Gigabit Ethernet and Fiber Channel applications?
Yes, the TRENDnet TEG-MGBS20D3 supports both Gigabit Ethernet (1000Base-LX) and Fiber Channel network technologies. This dual-protocol capability allows it to be deployed in diverse environments, such as data networks for internet connectivity or storage area networks (SANs) for high-speed data storage and retrieval over fiber optic links.
