TRENDnet TEG-524WS 52-Port Gigabit Web Smart Switch - 48 RJ-45 Ports - 4 Shared SFP Slots - 104 Gbps - 1U Rack-Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This Layer 2 managed switch operates on Gigabit Ethernet technology (1000Base-T and 1000Base-X), supporting both twisted pair and optical fiber media. The four shared SFP slots offer critical flexibility, allowing you to use copper for short runs or install SFP transceivers for fiber connections up to kilometers, enabling seamless integration into existing fiber backbones or creating long-distance uplinks between buildings.
The management suite is accessible via a standard web browser, providing tools for VLAN segmentation, QoS prioritization, bandwidth control per port, and support for modern protocols like IPv6 and LACP for link aggregation. While it does not feature a dedicated stack port, its comprehensive feature set supports stable, scalable network growth.
Relevant factors for this section include Total Number of Network Ports, Uplink Port, Modular, Media Type Supported. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The TEG-524WS balances high port density with operational simplicity, offering a cost-effective path to a managed network. Its shared port design future-proofs your investment by accommodating either copper or fiber connectivity as needs evolve, without requiring a separate uplink module.
Enhanced Control & Security
Implement private VLANs for device isolation, voice VLANs for prioritizing VoIP traffic, and IGMP snooping for efficient multicast streaming. Per-port bandwidth limits prevent any single device from monopolizing network resources.
- Port-based VLANs
- IEEE 802.1p QoS
- Bandwidth Control
- IGMP Snooping
Deployment Flexibility
The compact 1U metal housing is designed for standard 19-inch racks, making it easy to integrate into server rooms, wiring closets, or network cabinets. Its low power consumption and RoHS/WEEE compliance align with sustainable IT practices.
- 1U Rack-Mountable
- Metal Housing
- RoHS/WEEE Compliant
- TAA Compliant
Deployment / Use Cases
This switch is particularly well-suited for medium-sized offices, retail environments, school computer labs, or small business server rooms where a high number of wired connections must be organized, segmented, and managed reliably. The 48 copper ports can handle a dense cluster of workstations, IP phones, and security cameras, while the SFP slots provide the necessary uplink to a core switch or router.
For businesses adopting cloud management, the optional TRENDnet Hive service offers remote monitoring and configuration from a centralized dashboard, though this requires a separate subscription. The switch's support for advanced features like LACP allows for the bundling of multiple ports to create a high-bandwidth, fault-tolerant trunk connection to a server or network storage device.
Physical Profile
The switch features a durable, rack-mountable metal chassis with dimensions of 3" (H) x 17.4" (W) x 20" (D), occupying a single rack unit (1U) of space. This compact form factor maximizes port density per rack while maintaining efficient airflow. The included rack mount kit facilitates secure installation in standard 19-inch equipment racks. At approximately 1.54 pounds, it is lightweight for easy handling during deployment.
- Width
- 3" (76.20 mm)
- Depth
- 20" (508 mm)
- Height
- 3" (76.20 mm)
- Weight
- 1.54 lb (698.53 g)
- Length
- 17.40" (441.96 mm)
What's in the Box
The package includes all necessary components for immediate installation and operation.
Highlights
- 52 total ports: 48 fixed Gigabit RJ-45 and 4 shared Gigabit (RJ-45/SFP).
- 104 Gbps non-blocking switching capacity for full wire-speed performance.
- Web-based smart management interface for easy VLAN, QoS, and bandwidth control.
- Optional remote cloud management via TRENDnet Hive (subscription required).
- Supports modern protocols: IPv6, LACP, IGMP snooping, and Voice VLAN.
- Compact 1U rack-mountable metal housing for standard 19-inch racks.
- Low power consumption at 34.90 watts under typical operation.
- Compliant with RoHS, WEEE, and TAA regulations.
- Backed by a manufacturer's lifetime limited warranty.
Specifications
| Specifications | |
|---|---|
| Manufacturer | TRENDnet |
| Manufacturer Part Number | TEG-524WS |
| Brand Name | TRENDnet |
| Product Model | TEG-524WS |
| Product Name | 52 Port Gigabit Web Smart Switch |
| Product Condition | New |
| Product Type | Ethernet Switch |
| Interfaces/Ports | |
| Total Number of Network Ports | 52 |
| Uplink Port | No |
| Modular | Yes |
| Stack Port | No |
| Port/Expansion Slot Details | 52 x Gigabit Ethernet Network,4 x Gigabit Ethernet Expansion Slot |
| Media & Performance | |
| Media Type Supported | Twisted Pair,Optical Fiber |
| Ethernet Technology | Gigabit Ethernet |
| Network Technology | 1000Base-T,1000Base-X |
| I/O Expansions | |
| Total Number of Expansion Slots | 4 |
| Expansion Slot Type | SFP |
| Shared SFP Slot | Yes |
| Number of SFP Slots | 4 |
| Network & Communication | |
| Layer Supported | 2 |
| Management & Protocols | |
| Manageable | Yes |
| Power Description | |
| Power Source | Power Supply |
| Redundant Power Supply Supported | No |
| Power Consumption | 34.90 W |
| Physical Characteristics | |
| Compatible Rack Unit | 1U |
| Form Factor | Rack-mountable |
| Height | 3" (76.20 mm) |
| Width | 3" (76.20 mm) |
| Depth | 20" (508 mm) |
| Length | 17.40" (441.96 mm) |
| Weight (Approximate) | 1.54 lb (698.53 g) |
| Miscellaneous | |
| Package Contents | 52-Port Gigabit Web Smart Switch Quick Installation Guide CD-ROM (Utility & User's Guide) Power cord (1.8m/6 ft.) Rack mount kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What is the total number of ports on this switch and how are they configured?
The TRENDnet TEG-524WS has a total of 52 ports. This includes 48 dedicated Gigabit RJ-45 Ethernet ports for connecting end devices and 4 shared Gigabit ports. These four shared ports are flexible; each can be used as a standard RJ-45 copper port or, with an installed SFP transceiver, as a fiber optic port. This design provides high-density connectivity with built-in uplink flexibility.
Does this switch support Power over Ethernet (PoE)?
No, the TEG-524WS is a standard Gigabit switch and does not provide Power over Ethernet. It is designed for data connectivity only. If you require PoE to power devices like wireless access points or IP phones, you would need to pair this switch with a separate PoE injector or consider a dedicated PoE switch model from TRENDnet's product line.
What management features are available on this web smart switch?
As a web smart (Layer 2 managed) switch, it offers a comprehensive set of management features accessible through a built-in web interface. Key capabilities include VLAN creation for network segmentation, Quality of Service (QoS) with IEEE 802.1p prioritization, bandwidth rate limiting on a per-port basis, support for Link Aggregation (LACP), IGMP snooping for multicast traffic management, and support for both IPv4 and IPv6 addressing. It also supports remote cloud management via TRENDnet Hive with an additional subscription.
Can I use fiber optic connections with this switch?
Yes, fiber optic connectivity is supported through the four shared SFP slots. These slots accept industry-standard SFP (Small Form-factor Pluggable) transceiver modules, which you must purchase separately based on your required fiber type (e.g., multi-mode or single-mode) and distance. This allows you to create fiber uplinks to other switches or routers over long distances where copper Ethernet would be impractical.
Is this switch rack-mountable and what are its physical dimensions?
Yes, it is designed for rack mounting. The switch has a compact 1U form factor, meaning it occupies one unit of vertical space in a standard 19-inch equipment rack. Its dimensions are 3 inches in height, 17.4 inches in width, and 20 inches in depth. A complete rack mount kit is included in the box for easy installation into server cabinets or network racks.
What warranty does TRENDnet offer for the TEG-524WS switch?
TRENDnet backs the TEG-524WS with a lifetime limited warranty. This warranty covers defects in materials and workmanship for the life of the product under normal use. It is a strong commitment to product reliability and provides long-term peace of mind for your network infrastructure investment. Always refer to the official TRENDnet warranty terms for specific details and conditions.
