Tripp Lite by Eaton B119-4X1-MV HDMI Quad Multi-Viewer Switch - 4 x 1 HDMI Switch - 1080p Full HD - Remote Control Included
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This HDMI multi-viewer switch transmits video at 1920 x 1080 resolution with Full HD graphics modes, ensuring crisp, clear picture quality across supported devices. The unit features four HDMI inputs and one HDMI output, utilizing cable-based connectivity for reliable signal transmission. Audio switching operates independently from video, allowing users to watch one source while listening to audio from another, enhancing multitasking capabilities.
The switch supports simultaneous display from one, two, or all four HDMI sources, with a remote control for easy toggling between display modes. It is powered by an external supply with a 4 ft. cord, accepting 100-240V input and delivering 12V 2A output, compatible with international plug adapters for North America, Europe, U.K., and Australia.
Relevant factors for this section include Connectivity Technology, Number of Input Devices Supported, Device Supported, Graphics Modes. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The B119-4X1-MV stands out with its ability to handle multiple HDMI sources efficiently, reducing clutter and simplifying AV management. Its independent audio switching feature provides flexibility in multimedia presentations, while the included remote control enhances user convenience by allowing quick changes to display configurations without physical access to the unit.
Simultaneous Multi-View Display
Display video from one, two, or all four HDMI sources at the same time, ideal for monitoring multiple feeds in real-time.
- Flexible viewing options
- Real-time monitoring capability
High-Definition Performance
Transmits high-definition picture quality at 1080p video resolutions with 60 Hz refresh rates, ensuring smooth, detailed visuals.
- Full HD support
- 60 Hz refresh rate
Deployment / Use Cases
This HDMI switch is versatile for various professional and commercial applications. In control rooms and security monitoring centers, it enables operators to view multiple camera feeds on a single display. For retail and digital signage, it supports rotating content from different media players, while in conference rooms and educational settings, it facilitates switching between presentation sources like laptops, Blu-ray players, and document cameras.
Home entertainment systems benefit from its ability to consolidate gaming consoles, streaming devices, and set-top boxes, with the remote control offering easy management from a distance. The compact design and mounting options allow for discreet installation behind displays or in AV racks, maintaining a clean aesthetic.
Security & Surveillance
Monitor up to four camera feeds simultaneously on one display, enhancing situational awareness in security operations.
Conference & Presentation
Switch seamlessly between presentation sources such as laptops, projectors, and media players during meetings or lectures.
Physical Profile
The switch measures 5.85" in height, 4.07" in width, and 0.84" in depth, with an approximate weight of 12 oz, making it lightweight and space-efficient for integration into tight spaces. Its slim profile and included mounting hardware support vertical or horizontal installation, suitable for rack mounting or placement behind equipment. The durable construction ensures reliable performance in continuous use environments.
- Width
- 4.07" (103.38 mm)
- Depth
- 0.84" (21.34 mm)
- Height
- 5.85" (148.59 mm)
- Weight
- 12 oz (340.19 g)
What's in the Box
The package includes all necessary components for immediate setup and operation.
Highlights
- Supports 4 HDMI inputs to 1 output for multi-source management
- Delivers 1080p Full HD video resolution at 60 Hz
- Includes remote control for easy display mode toggling
- Independent audio switching allows separate video and audio sources
- Plug-and-play operation with no software required
- Compatible with displays, projectors, TVs, Blu-ray players, and cameras
- Compact design with mounting hardware for flexible installation
- Includes international plug adapters for global use
- Backed by a 2-year limited warranty
- Environmentally compliant with RoHS and REACH standards
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | B119-4X1-MV |
| Brand Name | Tripp Lite series |
| Product Model | B119-4X1-MV |
| Product Name | B119-4X1-MV HDMI Quad Multi-Viewer Switch |
| Product Type | Audio/Video Switchbox |
| Technical Information | |
| Connectivity Technology | Cable |
| Number of Input Devices Supported | 4 |
| Device Supported | Display,Projector,TV,Blu-ray Disc Player,Camera |
| Number of Displays Supported | 1 |
| Video | |
| Graphics Modes | Full HD |
| Maximum Video Resolution | 1920 x 1080 |
| Interfaces/Ports | |
| HDMI In | Yes |
| HDMI Out | Yes |
| Number of HDMI Inputs | 4 |
| Number of HDMI Outputs | 1 |
| Physical Characteristics | |
| Height | 5.85" (148.59 mm) |
| Width | 4.07" (103.38 mm) |
| Depth | 0.84" (21.34 mm) |
| Weight (Approximate) | 12 oz (340.19 g) |
| Miscellaneous | |
| Package Contents | B119-4X1-MV HDMI Quad Multi-Viewer Switch External Power Supply w/4 ft. Cord (Input: 100-240V, 50/60 Hz, 0.6A; Output: 12V 2A) 4 x International Plug Adapters (North America, Europe, U.K., Australia) Mounting Hardware Remote Control Owner's Manual |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
| Country of Origin | China |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What is the maximum video resolution supported by this HDMI switch?
The Tripp Lite by Eaton B119-4X1-MV HDMI Quad Multi-Viewer Switch supports a maximum video resolution of 1920 x 1080, which is Full HD. This ensures high-definition picture quality for all connected HDMI sources, making it suitable for displays, projectors, and other compatible devices that require crisp, clear visuals at 1080p.
How many HDMI inputs and outputs does this switch have?
This switch features four HDMI inputs and one HDMI output, configured as a 4x1 HDMI multi-viewer. It allows you to connect up to four HDMI source devices, such as cameras, Blu-ray players, or media streamers, and output the video to a single display, monitor, or projector, simplifying AV setups by reducing cable clutter.
Can I display multiple HDMI sources simultaneously with this switch?
Yes, the B119-4X1-MV can display video from one, two, or all four HDMI sources at the same time. This multi-view capability is ideal for applications like security monitoring, control rooms, or digital signage where real-time viewing of multiple feeds on a single screen enhances operational efficiency and situational awareness.
Does this HDMI switch include a remote control?
Yes, a remote control is included with the switch, allowing you to toggle between different display modes with ease. This feature provides convenient operation from a distance, making it practical for use in conference rooms, home theaters, or installations where the switch may be mounted out of direct reach.
Is the audio switching independent from the video on this device?
Yes, the audio switches independently from the video on this HDMI multi-viewer switch. This means you can watch video from one HDMI source while listening to audio from another, offering flexibility in multimedia presentations, gaming, or scenarios where separate audio and video sources are desired for enhanced user control.
What is included in the package with this HDMI switch?
The package includes the B119-4X1-MV HDMI Quad Multi-Viewer Switch, an external power supply with a 4 ft. cord (input: 100-240V, 50/60 Hz, 0.6A; output: 12V 2A), four international plug adapters for North America, Europe, U.K., and Australia, mounting hardware, a remote control, and an owner's manual. This comprehensive set ensures ready-to-use deployment in various global environments.
