Tripp Lite by Eaton SU6000RT SmartOnline 6000VA Rack/Tower UPS - 6 kVA / 5. 40 kW Double Conversion - 3U - 230V AVR - Pure Sine Wave
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This SmartOnline UPS operates with single-phase 230V AC input and provides a configurable output supporting voltages from 200V to 240V AC at 50/60 Hz. Its 98% efficient ECO mode reduces operating costs and heat generation. The unit is equipped with a comprehensive set of receptacles: two NEMA L6-20R and two NEMA L6-30R outlets, plus hardwiring capability via an included cable gland.
A valve-regulated, hot-swappable lead-acid battery system supports 3 minutes of runtime at full load and extends to approximately 8 minutes at half load, providing critical time for graceful system shutdowns or generator start-up. The integrated LCD display and four status LEDs deliver clear system status, while multiple management interfaces—including a network card slot, USB, RS-232, and dry contacts—enable local and remote monitoring, configuration, and automated shutdown procedures.
Key Product Advantages
The SU6000RT combines high-capacity power protection with flexible deployment and robust management, making it an ideal solution for demanding IT and commercial applications.
Uninterruptible Power Quality
Double-conversion technology ensures connected equipment receives only clean, regulated pure sine wave power, completely isolated from utility line disturbances, spikes, and frequency variations.
- 0 ms transfer time for seamless protection
- AVR corrects brownouts and overvoltages without battery use
- EMI/RFI filtering suppresses electrical noise
Operational Resilience & Manageability
Hot-swappable batteries allow for maintenance without downtime, while extensive monitoring options provide complete visibility and control over power events.
- Network management via optional WEBCARDLXE card
- LCD with status LEDs for at-a-glance diagnostics
- Audible alarms for utility failure, low battery, and overloads
Deployment Flexibility
The 3U rack/tower design includes tower support stands and rack-mounting hardware, offering installation versatility for server rooms, network closets, or floor-standing applications.
- Includes all necessary hardware for rack or tower setup
- Hardwiring capability for permanent installations
- Compact 3U footprint optimizes rack space
Deployment / Use Cases
The SmartOnline SU6000RT is designed to protect critical infrastructure where power interruptions can lead to data loss, system damage, or operational downtime. Its 6 kVA capacity and robust feature set suit it for a range of professional and industrial environments.
In IT server rooms and data closets, it safeguards rack-mounted servers, network switches, and storage arrays. For commercial and financial settings, it ensures point-of-sale systems, security systems, and medical equipment remain online. The unit's support for hardwired connections and compatibility with generator systems also makes it suitable for industrial control systems and telecommunications infrastructure.
Server & Network Infrastructure Protection
Provides clean, uninterrupted power to rack-mounted servers, network gear, and storage, preventing data corruption and hardware damage during outages.
Critical Commercial & Healthcare Applications
Ensures continuous operation of financial terminals, medical devices, and security systems where uptime is essential for safety and compliance.
Physical Profile
The UPS measures 5.10" (129.54 mm) in height, 17.30" (439.42 mm) in width, and 27.03" (686.56 mm) in depth, occupying a standard 3U rack space. Its substantial 106 lb weight reflects the robust internal components and battery capacity. The design includes integrated handles and provisions for both rack-mounting and tower placement using the included support stands.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 5.10" (129.54 mm), 17.30" (439.42 mm), 27.03" (686.56 mm), 106 lb (48080.79 g). This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 17.30" (439.42 mm)
- Depth
- 27.03" (686.56 mm)
- Height
- 5.10" (129.54 mm)
- Weight
- 106 lb (48080.79 g)
- Length
- 10 ft (3.05 m)
What's in the Box
The package includes all essential components for immediate deployment in either rack or tower configurations.
Highlights
- 6000VA / 5.40 kW double-conversion online UPS for maximum power protection
- 3U rack/tower form factor with included hardware for flexible installation
- Pure sine wave output ensures compatibility with sensitive active PFC equipment
- 3-minute full-load runtime (8 minutes at half load) for graceful shutdowns
- Automatic voltage regulation (AVR) corrects brownouts without battery drain
- Hot-swappable, valve-regulated lead-acid batteries for maintenance without downtime
- Comprehensive management via LCD, network card, USB, RS-232, and dry contacts
- Energy Star certified with 98% efficient ECO mode to reduce operating costs
- Includes two NEMA L6-20R and two NEMA L6-30R outlets plus hardwiring capability
- Backed by a 2-year limited warranty with $250,000 ultimate lifetime insurance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SU6000RT |
| Brand Name | Tripp Lite series |
| Product Line | SmartOnline |
| Product Model | SU6000RT |
| Product Name | SmartOnline SU6000RT 6000VA Rack/tower UPS |
| Product Type | Double Conversion Online UPS |
| Technical Information | |
| AVR | Yes |
| Plug/Connector Type | NEMA L6-30P,Hardwired |
| Receptacle Type | NEMA L6-20R,NEMA L6-30R,Hardwired |
| Receptacle Detail | 2 x NEMA L6-20R,2 x NEMA L6-30R |
| Cord Length | 10 ft (3.05 m) |
| Transfer Time | 0 ns |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Efficiency Detail | 98% (ECO Mode) |
| Application/Usage | Mission Critical Equipment,IT Equipment,Network Device,Education,Commercial,Financial,Healthcare |
| Surge Suppression | Yes |
| Features | Audible Alarm,Cold Start Function,Green Energy Saving |
| Power Description | |
| Load Capacity (VA) | 6 kVA |
| Load Capacity (Watt) | 5.40 kW |
| Input Voltage | 230 V AC |
| Input Current | 24.80 A |
| Output Voltage | 230 V AC,240 V AC,220 V AC,208 V AC,200 V AC |
| Output Frequency | 50 Hz,60 Hz |
| Waveform Type | Pure Sine Wave |
| Circuit Breaker | Yes |
| Output Power Factor | 0.9 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | Network Card,DB-9 RS-232,Dry Contact,USB,SNMP |
| Alarm | Utility Power Failure,Low Battery,Overload,Battery Fault,Remote Shutdown |
| Controls/Indicators | |
| Status Indicators | LED Indicators: 4 status-indicating LEDs |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| Battery Information | |
| DC System Voltage | 180 V DC |
| Battery Characteristics | Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3 Minute |
| Backup/Run Time (Half Load) | 8 Minute |
| Hot Swappable | Yes |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Thermal Dissipation | 1895 BTU/h |
| Physical Characteristics | |
| Height | 5.10" (129.54 mm) |
| Width | 17.30" (439.42 mm) |
| Depth | 27.03" (686.56 mm) |
| Rack Height | 3U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 106 lb (48080.79 g) |
| Miscellaneous | |
| Package Contents | SmartOnline SU6000RT 6000VA Rack/tower UPS WEBCARDLXE Network Card USB Cable RS-232 Cable Tower Support Stands Cable Gland for Hardwire Connection Rack-mounting Hardware Quick Start Guide |
| Energy Star | Yes |
| Country of Origin | Philippines |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 2 Year |
| Additional Warranty Information | 250,000 Ultimate Lifetime Insurance |
User Manual
FAQ
What is the power capacity of the SU6000RT UPS?
The Tripp Lite by Eaton SmartOnline SU6000RT provides 6000 volt-amps (6 kVA) of apparent power and 5400 watts (5.40 kW) of real power capacity. This double-conversion online UPS can support substantial loads such as multiple servers, network switches, and storage arrays, making it suitable for small server rooms or critical commercial equipment.
How long will this UPS run on battery during a power outage?
At full rated load (6 kVA / 5.40 kW), the SU6000RT provides approximately 3 minutes of battery runtime. When supporting a half load (3 kVA / 2.70 kW), runtime extends to about 8 minutes. These times allow for orderly system shutdowns or the activation of a backup generator, protecting against data loss and hardware damage.
What types of power outlets does this UPS have?
This unit includes two NEMA L6-20R and two NEMA L6-30R receptacles for connecting equipment with corresponding plugs. It also supports a hardwired connection via an included cable gland for permanent installations, offering flexibility for both standard plug-in and direct-wired applications.
Can this UPS be mounted in a standard server rack?
Yes, the SU6000RT is designed for both rack and tower deployment. It occupies 3U (5.10 inches) of vertical rack space and includes all necessary rack-mounting hardware. For tower use, the package contains support stands, allowing the same unit to be placed on the floor or a shelf if rack space is unavailable.
What management and monitoring options are available?
The UPS features an LCD display and four status LEDs for local monitoring. For remote management, it includes a slot for an optional WEBCARDLXE network management card, plus built-in USB, DB-9 RS-232, and dry contact interfaces. These support monitoring, configuration, and automated shutdown via SNMP, web browser, or compatible power management software.
Are the batteries user-replaceable and hot-swappable?
Yes, the SU6000RT uses valve-regulated, lead-acid batteries that are both user-replaceable and hot-swappable. The hot-swap capability allows you to replace battery modules without powering down the UPS or connected equipment, ensuring continuous protection during maintenance and extending system uptime.
What power capacity is listed for this UPS?
The listed power specification is 6 kVA, which helps position the unit for the right load level and installation role.
What voltage details are listed?
The listed power specification is 230 V AC, which helps position the unit for the right load level and installation role.
