Tripp Lite by Eaton SMART3000RXLTAA SmartPro 3000VA Rack/Tower UPS - 3 kVA/3 kW - 120V - AVR - 2U - Pure Sine Wave
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This line-interactive UPS operates on 120V AC input with a wide voltage range of 70-153V AC, delivering stable output at 120V, 100V, 110V, or 125V AC. The pure sine wave output ensures compatibility with sensitive electronic equipment, while the 4ms transfer time provides seamless transition to battery power during outages.
The unit features six NEMA 5-20R outlets and one NEMA L5-30R outlet, with two load management outlets for prioritized shutdown sequencing. A 10-foot NEMA L5-30P power cord connects to standard power sources, and the integrated EMI/RFI noise filtering protects against electrical interference.
This section brings together practical product details such as AVR, Plug/Connector Type, Receptacle Type, Load Capacity (VA), so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
The SMART3000RXLTAA combines high power density with flexible deployment options, making it ideal for space-constrained environments. The 2U rack-mount design maximizes cabinet space utilization while the included tower support stands enable freestanding installation where racks aren't available.
Advanced Power Protection
Automatic voltage regulation maintains stable output during brownouts and overvoltages, while pure sine wave output ensures compatibility with power supplies in servers, storage, and networking equipment.
- AVR corrects ±15% voltage fluctuations
- Pure sine wave for sensitive electronics
- 380J surge energy rating
Enterprise Management
Multiple management interfaces provide comprehensive monitoring and control options for IT administrators.
- SNMP/Web for network integration
- Dry contact for external alarms
- USB HID for direct computer connection
Maintenance-Friendly Design
Hot-swappable batteries allow replacement without powering down connected equipment, minimizing disruption to critical operations.
- Valve-regulated lead-acid batteries
- User-replaceable design
- 72V DC system voltage
Deployment / Use Cases
This 3000VA UPS is engineered for protecting critical infrastructure in commercial and industrial settings. The substantial power capacity supports multiple devices simultaneously, making it suitable for server racks, network closets, and telecommunications equipment.
In data center environments, the 2U form factor integrates seamlessly into standard 19-inch racks alongside servers, switches, and storage arrays. The rack/tower flexibility allows deployment in mixed infrastructure scenarios where some equipment may be rack-mounted while other components reside on shelves or desktops.
Server Room Protection
Provides backup power for rack-mounted servers, storage systems, and network switches during utility outages, allowing for graceful shutdown or continued operation.
- 3 kVA capacity for multiple servers
- 2U height conserves rack space
- SNMP management for remote monitoring
Network Infrastructure
Protects telecommunications equipment, security systems, and lab instrumentation from power disturbances that could cause data loss or equipment damage.
- Pure sine wave for sensitive electronics
- Wide input voltage range
- EMI/RFI noise filtering
Physical Profile
The SMART3000RXLTAA measures 3.40" (86.36 mm) in height, 17.20" (436.88 mm) in width, and 23.70" (601.98 mm) in depth, occupying 2U of vertical space in standard 19-inch racks. The 74.50 lb weight reflects the substantial battery capacity and robust construction suitable for commercial deployment.
Front-panel LCD display provides real-time status information including input/output voltage, load percentage, battery status, and runtime remaining. LED indicators offer at-a-glance status for battery mode, low battery warning, and fault conditions.
- Width
- 17.20" (436.88 mm)
- Depth
- 23.70" (601.98 mm)
- Height
- 3.40" (86.36 mm)
- Weight
- 50 dB(A)
- Length
- 10 ft (3.05 m)
What's in the Box
The package includes all necessary components for both rack-mount and tower deployment configurations.
Highlights
- 3000VA/3000W power capacity for protecting multiple critical devices
- 2U rack/tower form factor with included mounting hardware for flexible deployment
- Automatic voltage regulation (AVR) corrects brownouts and overvoltages without battery drain
- Pure sine wave output ensures compatibility with sensitive server and network equipment
- 3-minute runtime at full load, 9-minute runtime at half load for graceful shutdown
- Hot-swappable, valve-regulated lead-acid batteries for maintenance without downtime
- Multiple management interfaces: SNMP/Web, dry contact, USB, and serial connectivity
- ENERGY STAR 2.0 certified with 96% efficiency in AC mode for reduced operating costs
- Six NEMA 5-20R outlets and one NEMA L5-30R outlet with load management capabilities
- 3-year limited warranty (2-year standard, 3-year with registration)
Specifications
| Specifications | |
|---|---|
| Manufacturer | Eaton Corporation |
| Manufacturer Part Number | SMART3000RXLTAA |
| Brand Name | Tripp Lite series |
| Product Line | SmartPro |
| Product Model | SMART3000RXLTAA |
| Product Name | SmartPro SMART3000RXLTAA 3000VA Rack/Tower UPS |
| Product Type | Line-interactive UPS |
| Technical Information | |
| AVR | Yes |
| Plug/Connector Type | NEMA L5-30P |
| Receptacle Type | NEMA 5-20R,NEMA L5-30R |
| Receptacle Detail | 6 x NEMA 5-20R,1 x NEMA L5-30R |
| Number of Load Management Outlets | 2 |
| Cord Length | 10 ft (3.05 m) |
| Transfer Time | 4 ms |
| EMI/RFI Noise Filter | Yes |
| Phase | Single Phase |
| Efficiency Detail | 96% (AC Mode) |
| Application/Usage | Server,Switch,IT Equipment,Telecommunication,Enterprise,Workstation,Storage,Security,Lab Equipment,Server Room,Data Center,Network,Desktop |
| Surge Suppression | Yes |
| Features | Cold Start Function |
| Power Description | |
| Load Capacity (VA) | 3 kVA |
| Load Capacity (Watt) | 3 kW |
| Input Voltage | 120 V AC |
| Input Voltage Range | 70 V AC - 153 V AC |
| Input Current | 24 A |
| Output Voltage | 120 V AC,100 V AC,110 V AC,125 V AC |
| Output Frequency | 50 Hz,60 Hz |
| Waveform Type | Pure Sine Wave |
| Surge Energy Rating | 380 J |
| Circuit Breaker | Yes |
| Output Power Factor | 1 |
| Display & Graphics | |
| Display | LCD |
| Management | |
| Network Management | Dry Contact,DB-9 RS-232,Contact Closure,SNMP/Web |
| Alarm | Power Failure,Low Battery,Overload,UPS Fault,Remote Shutdown |
| Controls/Indicators | |
| Status Indicators | LED Indicators: Battery Mode Battery Low Warning Fault/Alarm |
| Interfaces/Ports | |
| Serial Port | Yes |
| USB | Yes |
| EPO Port | Yes |
| USB (HID Compliant) Port | Yes |
| Battery Information | |
| DC System Voltage | 72 V DC |
| Battery Characteristics | Valve-regulated |
| Battery Chemistry | Lead Acid |
| Backup/Run Time (Full Load) | 3 Minute |
| Backup/Run Time (Half Load) | 9 Minute |
| Hot Swappable | Yes |
| Typical Battery Recharge Time | 5 Hour |
| Replaceable Battery | Yes |
| Environmental Conditions | |
| Maximum Storage Elevation | 32808 ft (9999878.40 mm) |
| Storage Temperature | 5°F (-15°C) - 122°F (50°C) |
| Minimum Operating Temperature | 32°F (0°C) |
| Maximum Operating Temperature | 104°F (40°C) |
| Sound Emission (A-Weighted) | 50 dB(A) |
| Thermal Dissipation | 944 BTU/h |
| Physical Characteristics | |
| Height | 3.40" (86.36 mm) |
| Width | 17.20" (436.88 mm) |
| Depth | 23.70" (601.98 mm) |
| Rack Height | 2U |
| Form Factor | Rack/Tower |
| Weight (Approximate) | 74.50 lb (33792.63 g) |
| Miscellaneous | |
| Package Contents | SmartPro SMART3000RXLTAA 3000VA Rack/Tower UPS USB Cable DB9 Cable Rack-mounting Hardware Tower Support Stands Safety Instructions Quick Start Guide |
| Energy Star | Yes |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
| Energy Efficiency Certification | ENERGY STAR 2.0 |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Warranty | |
| Limited Warranty | 3 Year |
| Additional Warranty Information | 2-year warranty, 3 year with registration. |
User Manual
FAQ
What is the power capacity of this UPS?
The Tripp Lite by Eaton SmartPro SMART3000RXLTAA provides 3000VA (3 kVA) and 3000W (3 kW) of power capacity. This substantial capacity can support multiple servers, network switches, storage systems, or other critical IT equipment simultaneously during power disturbances or outages.
Can this UPS be installed in both rack and tower configurations?
Yes, this UPS features a rack/tower form factor. It occupies 2U of vertical space in standard 19-inch racks and includes all necessary rack-mounting hardware. For tower deployment, the package contains tower support stands that enable freestanding installation on floors or shelves where rack mounting isn't available.
What type of power output does this UPS provide?
This UPS delivers pure sine wave output, which is essential for sensitive electronic equipment like servers, storage systems, and networking gear. Pure sine wave power ensures compatibility with active PFC power supplies and prevents potential damage or instability that can occur with simulated sine wave outputs.
How long does the battery backup last during a power outage?
At full 3000W load, the battery provides approximately 3 minutes of runtime, allowing for graceful shutdown of connected equipment. At half load (1500W), runtime extends to approximately 9 minutes. The batteries typically recharge within 5 hours after being depleted.
What management and monitoring options are available?
This UPS offers multiple management interfaces including SNMP/Web for network integration, dry contact for external alarm systems, DB-9 RS-232 serial for direct connection, and USB (HID compliant) for computer connectivity. The front-panel LCD display provides real-time status information, and LED indicators show battery mode, low battery warning, and fault conditions.
Are the batteries user-replaceable and hot-swappable?
Yes, the valve-regulated lead-acid batteries are both user-replaceable and hot-swappable. This design allows battery replacement without powering down connected equipment, minimizing disruption to critical operations. The 72V DC battery system supports maintenance during normal operation.
What power capacity is listed for this UPS?
The listed power specification is 3 kVA, which helps position the unit for the right load level and installation role.
How many outlets are available?
The product includes 2, which helps buyers understand how many connected devices it can support in its intended deployment.
