Zebra LI3678-SR3U42A0S1W LI3678-SR Barcode Scanner Kit - Wireless 1D Imager - 42" Scan Distance - Bluetooth - USB - Industrial Green/Black
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The LI3678-SR scanner features advanced optical specifications including 65° reading angles for skew and pitch, plus 45° for roll, allowing flexible scanning orientations. The device maintains reliable performance with a minimum print contrast of 15% and handles barcode elements from 4 mil (0.10 mm) to 20 mil (0.51 mm) resolution.
Wireless connectivity via Bluetooth enables compatibility with most smart devices and mobile computers, while the included USB cable provides direct host connection options. The scanner supports multiple host interfaces including serial, keyboard wedge, and USB for seamless integration with existing systems.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Bluetooth, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
A strong technical summary explains how the product's interfaces, hardware profile, and operating characteristics work together in real deployment. Buyers often need this context to confirm compatibility with existing devices, expected performance in daily use, and whether installation will be straightforward for IT staff or end users.
Key Product Advantages
This scanner stands out with industrial-grade durability and versatile wireless operation. The IP67 and IP65 ratings provide complete protection against dust ingress and water immersion, while the rugged construction withstands multiple 8-foot drops to concrete surfaces.
Industrial Durability
Built to survive harsh environments with IP67/IP65 protection and drop resistance up to 8 feet.
- IP67/IP65 rated
- 8-foot drop tested
- 108,000 lux ambient light tolerance
Wireless Flexibility
Bluetooth connectivity enables mobile scanning operations without cable restrictions.
- Bluetooth wireless
- USB cable included
- Multiple interface support
Precision Scanning
Advanced imager technology captures 1D barcodes with 4 mil resolution at 42-inch distances.
- 42" scan distance
- 4 mil minimum resolution
- 65° reading angles
Deployment / Use Cases
The LI3678-SR scanner excels in industrial settings where reliability and mobility are critical. Its wireless capability allows workers to move freely while scanning inventory, tracking assets, or managing warehouse operations without being tethered to fixed workstations.
Manufacturing facilities benefit from the scanner's rugged design that withstands production floor conditions, while logistics operations appreciate the extended 42-inch scanning distance for pallet-level barcode reading. The device's compatibility with multiple host interfaces ensures easy integration with existing point-of-sale, inventory management, and enterprise resource planning systems.
This section brings together practical product details such as Connectivity Technology, Scanning Capability, Barcode Symbology Supported, Bluetooth, so buyers can judge configuration, deployment fit, and day-to-day suitability with less guesswork.
Warehouse Operations
Mobile scanning for inventory management, receiving, and shipping with wireless connectivity.
Manufacturing Floor
Durable scanning for production tracking, quality control, and asset management in industrial environments.
Physical Profile
The handheld scanner features a compact form factor measuring 7.30" × 3" × 5.60" (185.42 × 76.20 × 142.24 mm) with a weight of 13.60 ounces (385.55 grams). The dual-color Industrial Green and Black finish provides both visibility and professional appearance in industrial settings. The ergonomic design supports comfortable extended use during shift-long scanning operations.
- Width
- 3" (76.20 mm)
- Depth
- 5.60" (142.24 mm)
- Height
- 7.30" (185.42 mm)
- Weight
- 13.60 oz (385.55 g)
What's in the Box
The scanner kit includes the USB cable for direct host connectivity and charging.
Package contents include USB. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Wireless 1D barcode scanner with Bluetooth connectivity
- 42-inch (1066.80 mm) scanning distance for flexible operation
- Industrial-grade durability with IP67/IP65 protection
- Withstands 8-foot drops to concrete surfaces
- Supports multiple 1D barcode symbologies including Code 39 and UPC/EAN
- Includes USB cable for direct host connection
- Compact handheld design with Industrial Green/Black finish
- Suitable for warehouse, manufacturing, and industrial applications
Specifications
| Specifications | |
|---|---|
| Manufacturer | Zebra Technologies Corporation |
| Manufacturer Part Number | LI3678-SR3U42A0S1W |
| Brand Name | Zebra |
| Product Series | 3600 |
| Product Model | LI3678-SR |
| Product Name | LI3678-SR Barcode Scanner Kit |
| Product Type | Barcode Scanner Kit |
| Technical Information | |
| Connectivity Technology | Wireless |
| Scanning Capability | 1D |
| Barcode Symbology Supported | 1D: Code 39 Code 128 Code 93 Codabar/NW7 Code 11 MSI Plessey UPC/EAN I 2 of 5 Korean 3 of 5 GS1 DataBar Base 32 (Italian Pharma) |
| Image Sensor Type | Imager |
| Scan Pattern | Linear |
| Scanner Range | Standard Range |
| Scanning Distance | 42" (1066.80 mm) |
| Cable Type Included | USB |
| Reading Angle (Skew) | 65° |
| Reading Angle (Pitch) | 65° |
| Reading Angle (Roll) | 45° |
| Maximum Ambient Light | 108000 lux |
| Drop Specification | Withstands multiple 8.0 ft. / 2.4 m drops to concrete |
| Minimum Print Contrast | 15% |
| Minimum Element Resolution (Code 39) | 4 mil (0.10 mm) |
| Maximum Element Resolution (Code 39) | 20 mil (0.51 mm) |
| Network & Communication | |
| Bluetooth | Yes |
| Interfaces/Ports | |
| Host Interface | Serial,Keyboard Wedge,USB |
| Physical Characteristics | |
| Form Factor | Handheld |
| Rugged | Yes |
| Color Family | Dual Color |
| Product Color | Industrial Green,Black |
| Height | 7.30" (185.42 mm) |
| Width | 3" (76.20 mm) |
| Depth | 5.60" (142.24 mm) |
| Weight (Approximate) | 13.60 oz (385.55 g) |
| Miscellaneous | |
| Ingress Protection (IP) Rating | IP67,IP65 |
| Application/Usage | Industrial,Warehouse,Manufacturing |
| Country of Origin | China |
User Manual
FAQ
What types of barcodes can the Zebra LI3678-SR scanner read?
The scanner reads 1D barcode symbologies including Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, and Base 32 (Italian Pharma). It uses imager technology with a linear scan pattern for reliable 1D barcode capture.
How does the wireless connectivity work with this scanner?
The LI3678-SR features Bluetooth wireless technology that enables compatibility with most smart devices, tablets, and mobile computers. This allows untethered scanning operations while maintaining data transmission to connected devices. The scanner also includes a USB cable for direct wired connections when needed.
What is the maximum scanning distance of this barcode scanner?
The scanner has a 42-inch (1066.80 mm) scanning distance with standard range capability. This extended reach allows operators to scan barcodes from comfortable distances, making it suitable for pallet-level scanning and other applications where close proximity isn't practical.
How durable is the LI3678-SR scanner for industrial use?
The scanner is built for industrial environments with IP67 and IP65 ingress protection ratings, making it dust-tight and protected against water immersion. It withstands multiple 8.0-foot (2.4-meter) drops to concrete and operates in ambient light up to 108,000 lux, ensuring reliable performance in harsh conditions.
What interfaces does this scanner support for connecting to host systems?
The scanner supports multiple host interfaces including serial, keyboard wedge, and USB connections. This versatility allows integration with various point-of-sale systems, computers, and mobile devices. The included USB cable provides plug-and-play connectivity for most modern systems.
What are the physical dimensions and weight of the scanner?
The handheld scanner measures 7.30 inches in height, 3 inches in width, and 5.60 inches in depth (185.42 × 76.20 × 142.24 mm). It weighs approximately 13.60 ounces (385.55 grams), making it lightweight enough for extended use while maintaining a sturdy construction for industrial applications.
What print speed is listed?
Zebra LI3678-SR Barcode Scanner Kit - Wireless Connectivity - 42" (1066.80 mm) Scan Distance - 1D - Imager - Linear - Bluetooth - USB (LI3678-SR3U42A0S1W) is described for practical deployment use, and the specification set helps buyers confirm fit, compatibility, and expected day-to-day operation.
What sheet capacity, media size, or paper handling detail is listed?
Zebra LI3678-SR Barcode Scanner Kit - Wireless Connectivity - 42" (1066.80 mm) Scan Distance - 1D - Imager - Linear - Bluetooth - USB (LI3678-SR3U42A0S1W) is described for practical deployment use, and the specification set helps buyers confirm fit, compatibility, and expected day-to-day operation.
