Cisco AIR-CAP1702IEK9-RF Aironet 1702I 802.11ac Dual-Band Wireless Access Point - 867 Mbps - MIMO - Beamforming - 2x RJ-45 - Wall/Ceiling Mount
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This access point implements IEEE 802.11ac wireless technology, the latest Wi-Fi standard at its release, which enhances network efficiency and throughput compared to previous generations. The dual-band architecture allows simultaneous operation on both 2.4 GHz and 5 GHz bands, optimizing performance by reducing interference and allocating bandwidth appropriately for different types of traffic.
Advanced radio features include MIMO (Multiple Input, Multiple Output) technology, which improves signal reliability and data rates by using multiple antennas, and beamforming technology, which directs wireless signals toward connected devices to strengthen connections and extend effective range.
Relevant factors for this section include Wireless LAN Standard, Frequency Band, Wireless Transmission Speed, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Cisco Aironet 1702I combines robust wireless capabilities with practical design elements that benefit business deployments. Its compact physical footprint and versatile mounting options make it easy to integrate into existing office layouts, retail spaces, or educational environments without occupying excessive space.
High-Speed Connectivity
Supports up to 867 Mbps wireless throughput, enabling efficient data transfers and reducing latency for business applications.
- Ideal for HD video conferencing
- Supports multiple simultaneous users
- Reduces network bottlenecks
Advanced Radio Features
MIMO and beamforming technologies work together to deliver stronger, more reliable wireless signals across your coverage area.
- Improves signal strength and consistency
- Enhances performance in crowded RF environments
- Extends effective wireless range
Enterprise-Grade Design
Built to Cisco's rigorous standards for business networking equipment, offering durability and consistent performance.
- Compact form factor for flexible placement
- Designed for 24/7 operation
- Backed by lifetime limited warranty
Deployment / Use Cases
The 1702I access point is well-suited for small to medium business environments where reliable Wi-Fi coverage is essential but space constraints or budget considerations make larger enterprise solutions impractical. Its dual-band capability allows network administrators to segregate traffic, dedicating the 5 GHz band to performance-sensitive applications while using 2.4 GHz for broader device compatibility.
Typical deployment scenarios include office environments requiring consistent wireless connectivity for employee devices, retail locations providing customer Wi-Fi access, educational settings supporting classroom technology, and healthcare facilities where reliable network access supports critical applications. The access point's compact design and wall/ceiling mounting options enable discreet installation in various locations without disrupting aesthetics or workflow.
Office Network Expansion
Extend wireless coverage to conference rooms, open workspaces, or remote office areas with this compact access point.
Customer-Facing Wi-Fi
Provide reliable guest access in retail stores, restaurants, or hospitality venues while maintaining separate network security.
Physical Profile
Measuring 8.69" square and just 1.99" thick, the 1702I presents a low-profile design that blends discreetly into most environments. The square form factor and included mounting hardware support both ceiling and wall installation, giving network administrators flexibility in placement to optimize coverage patterns. At approximately 1 kg, the unit is lightweight enough for secure mounting without requiring heavy-duty support structures.
- Width
- 8.69" (220.73 mm)
- Depth
- 8.69" (220.73 mm)
- Height
- 1.99" (50.55 mm)
- Weight
- 997.9 g
Highlights
- IEEE 802.11ac dual-band wireless access point with 867 Mbps maximum throughput
- Simultaneous 2.4 GHz and 5 GHz operation for flexible network design
- MIMO technology improves signal reliability and data rates
- Beamforming directs wireless signals toward connected devices
- Two RJ-45 network ports support Ethernet, Fast Ethernet, and Gigabit Ethernet connections
- Includes dedicated management port for network administration
- Compact design measures 8.69" x 8.69" x 1.99" (220.73 mm x 220.73 mm x 50.55 mm)
- Weighs approximately 997.9 g for easy wall or ceiling mounting
- Lifetime limited warranty provides long-term assurance
- Refurbished condition offers cost-effective enterprise networking solution
Specifications
| Specifications | |
|---|---|
| Manufacturer | Cisco Systems, Inc |
| Manufacturer Part Number | AIR-CAP1702IEK9-RF |
| Brand Name | Cisco |
| Product Line | Aironet |
| Product Series | 1700 |
| Product Model | 1702I |
| Product Name | Aironet 1702I Wireless Access Point |
| Product Condition | Refurbished |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11ac |
| Frequency Band | 2.40 GHz,5 GHz |
| Wireless Transmission Speed | 867 Mbit/s |
| MIMO Technology | Yes |
| Beamforming Technology | Yes |
| Interfaces/Ports | |
| Ethernet Technology | Ethernet,Fast Ethernet,Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 2 |
| VGA | No |
| HDMI | No |
| USB | No |
| Powerline | No |
| Management Port | Yes |
| Physical Characteristics | |
| Height | 1.99" (50.55 mm) |
| Width | 8.69" (220.73 mm) |
| Depth | 8.69" (220.73 mm) |
| Weight (Approximate) | 997.9 g |
| Warranty | |
| Limited Warranty | Lifetime |
User Manual
FAQ
What wireless standards does this Cisco access point support?
The Cisco Aironet 1702I supports the IEEE 802.11ac wireless standard, which is the latest Wi-Fi generation at its release. This standard provides improved data rates, better network efficiency, and enhanced performance compared to previous 802.11n technology. The access point operates on both 2.4 GHz and 5 GHz frequency bands simultaneously, allowing for flexible network design and reduced interference in crowded wireless environments.
What is the maximum wireless speed of this access point?
This access point delivers a maximum wireless transmission speed of 867 megabits per second (Mbps). This throughput supports bandwidth-intensive applications like HD video streaming, video conferencing, and large file transfers while maintaining responsive performance for multiple connected devices. The actual speed experienced will depend on factors like client device capabilities, network configuration, and environmental conditions.
How many network ports does this access point have?
The Cisco Aironet 1702I features two RJ-45 network ports that support Ethernet, Fast Ethernet, and Gigabit Ethernet connections. These ports allow the access point to connect to your wired network infrastructure, with one typically used for uplink connectivity and the other available for additional devices or redundancy. The access point also includes a dedicated management port for administrative access and configuration.
Does this access point support Power over Ethernet (PoE)?
While the specification data doesn't explicitly list PoE support, the access point's Ethernet technology includes Fast Ethernet and Gigabit Ethernet, which are commonly associated with PoE capabilities in business access points. Many Cisco Aironet models in this series support standard PoE for simplified installation. For definitive PoE compatibility, we recommend consulting the manufacturer's documentation or technical specifications for this specific model.
What mounting options are available for this wireless access point?
The compact, square design of the Cisco Aironet 1702I supports both wall and ceiling mounting, providing flexibility for installation in various environments. With dimensions of 8.69" x 8.69" x 1.99" and a weight of approximately 997.9 grams, the access point can be discreetly installed in office ceilings, mounted on walls in retail spaces, or placed in other locations that optimize wireless coverage patterns throughout your facility.
What warranty comes with this refurbished access point?
This Cisco Aironet 1702I Wireless Access Point includes a lifetime limited warranty. This warranty coverage provides assurance of the product's reliability and durability for business deployments. As a refurbished unit, it has been professionally tested and restored to proper working condition, offering a cost-effective alternative to new equipment while maintaining enterprise-grade performance standards backed by Cisco's warranty protection.
