Kingston SKC600MS/512G KC600 1TB mSATA Internal SSD - SATA/600 - 550 MB/s Read - 520 MB/s Write - 300 TBW
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The KC600 SSD features sequential read speeds up to 550 MB/s and write speeds up to 520 MB/s, enabling faster boot times, application launches, and file transfers. Random 4KB performance reaches 90,000 IOPS for reads and 80,000 IOPS for writes, improving responsiveness during multitasking and data-intensive operations. The drive's 300 TBW endurance rating and 228.2-year MTBF reflect its durability under typical consumer and light commercial use.
Hardware-based 256-bit AES-XTS encryption secures data at rest without impacting performance, meeting security requirements for sensitive information. The mSATA form factor measures 50.80 mm x 29.85 mm x 4.85 mm and weighs just 7 grams, fitting into space-constrained systems. Standby power consumption is minimal at 80 mW, contributing to energy efficiency in always-on or portable devices.
Relevant factors for this section include Storage Capacity, Encryption Standard, Maximum Read Transfer Rate, Maximum Write Transfer Rate. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Kingston KC600 stands out with its combination of encryption, endurance, and compact design. Hardware-based AES-XTS encryption operates independently of the host system, providing robust security without software overhead. The 300 TBW endurance ensures long-term reliability for write-intensive tasks, while the mSATA form factor enables upgrades in systems where larger 2.5-inch drives won't fit.
Built-in Security
256-bit AES-XTS encryption protects data at the hardware level, suitable for environments requiring compliance or protection against unauthorized access.
- No performance penalty
- Transparent to the OS
- Supports TCG Opal 2.0
Endurance & Warranty
With a 300 TBW rating and 5-year limited warranty, this drive is backed for sustained use in both consumer and light commercial scenarios.
- Long-term data integrity
- Manufacturer support
- Ideal for frequent writes
Deployment / Use Cases
This mSATA SSD is ideal for upgrading older laptops, ultrabooks, or compact desktops that lack space for standard 2.5-inch drives. Its combination of speed and encryption makes it suitable for business notebooks handling confidential data, point-of-sale systems, or embedded applications where security and reliability are priorities.
In educational or office environments, the KC600 can breathe new life into aging hardware by replacing mechanical hard drives, resulting in faster boot times and improved application responsiveness. The drive's low power consumption and small footprint also make it a fit for industrial PCs, digital signage, or networking equipment where energy efficiency and space are constraints.
Notebook & Desktop Upgrades
Replace slow HDDs in compatible systems to achieve faster overall performance and better battery life due to lower power draw.
Secure Data Environments
Deploy in systems handling sensitive information, leveraging hardware encryption to meet data protection standards without complex software setups.
Physical Profile
The mSATA form factor measures 50.80 mm in length, 29.85 mm in width, and just 4.85 mm in depth, making it one of the slimmest SSD options available. Weighing only 7 grams, it adds negligible mass to portable devices. This compact design is specifically engineered for integration into systems with limited internal space, such as thin laptops, mini-PCs, or embedded boards, without requiring additional mounting brackets or adapters.
- Width
- 1.18" (29.85 mm)
- Depth
- 0.19" (4.85 mm)
- Weight
- 0.25 oz (7 g)
- Length
- 2" (50.80 mm)
Highlights
- 1TB capacity for ample storage of OS, apps, and files
- mSATA form factor fits space-constrained systems
- 550 MB/s read and 520 MB/s write speeds
- 256-bit AES-XTS hardware encryption for data security
- 300 TBW endurance rating for long-term reliability
- SATA/600 interface ensures broad compatibility
- 5-year limited warranty for peace of mind
- Low 80 mW standby power consumption
- Compatible with desktop PCs and notebooks
- 3D TLC NAND flash for consistent performance
Specifications
| Specifications | |
|---|---|
| Manufacturer | Kingston Technology Company |
| Manufacturer Part Number | SKC600MS/512G |
| Brand Name | Kingston |
| Product Series | KC600 |
| Product Name | Hardware-based self-encrypting drive with 3D TLC NAND |
| Product Type | Solid State Drive |
| Technical Information | |
| Storage Capacity | 1 TB |
| Encryption Standard | 256-bit AES-XTS |
| Drive Performance | |
| Maximum Read Transfer Rate | 550 MB/s |
| Maximum Write Transfer Rate | 520 MB/s |
| Random 4KB Read | 90000IOPS |
| Random 4KB Write | 80000IOPS |
| Endurance (TBW) | 300 TB |
| Mean Time Between Failures (MTBF) | 228.2 Year |
| Interfaces/Ports | |
| Drive Interface | SATA |
| Drive Interface Standard | SATA/600 |
| Power Description | |
| Standby Power Consumption | 80 mW |
| Physical Characteristics | |
| Drive Type | Internal |
| Form Factor | mSATA |
| Width | 1.18" (29.85 mm) |
| Depth | 0.19" (4.85 mm) |
| Length | 2" (50.80 mm) |
| Weight (Approximate) | 0.25 oz (7 g) |
| Miscellaneous | |
| Device Supported | Desktop PC,Notebook |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),China Restriction of Hazardous Substances (China RoHS),Taiwan Restriction of Hazardous Substances (Taiwan RoHS) |
| Warranty | |
| Limited Warranty | 5 Year |
FAQ
What systems are compatible with this mSATA SSD?
The Kingston KC600 mSATA SSD is compatible with desktop PCs and notebooks that have an mSATA slot. It uses the SATA/600 interface, so it works with any system supporting SATA III and an mSATA connector. This makes it ideal for upgrading older laptops, ultrabooks, compact desktops, or embedded systems where space is limited and a standard 2.5-inch drive won't fit.
How does the 256-bit AES-XTS encryption work?
This SSD features hardware-based 256-bit AES-XTS encryption, which secures data at the drive level without relying on host software. The encryption is always active and transparent to the operating system, providing protection against unauthorized access even if the drive is removed from the system. It supports TCG Opal 2.0 standards, making it suitable for environments with strict data security requirements.
What does the 300 TBW endurance rating mean?
TBW stands for Terabytes Written, and the 300 TB rating indicates the total amount of data that can be written to the drive over its lifetime under typical use. This endurance level is suitable for consumer and light commercial workloads, such as everyday computing, office applications, and moderate file transfers. It reflects the drive's durability and is backed by a 5-year warranty for added assurance.
Can this SSD improve my computer's performance?
Yes, replacing a traditional hard drive with this SSD can significantly improve system performance. With read speeds up to 550 MB/s and write speeds up to 520 MB/s, you'll experience faster boot times, quicker application launches, and smoother multitasking. The random I/O performance of 90,000 read IOPS and 80,000 write IOPS also enhances responsiveness during data-intensive tasks.
What is the difference between mSATA and standard SATA SSDs?
mSATA SSDs like the KC600 use a smaller form factor and connector compared to standard 2.5-inch SATA SSDs. The mSATA drive measures 50.80 mm x 29.85 mm x 4.85 mm and connects directly to a motherboard's mSATA slot, making it ideal for compact systems. Both use the SATA interface for data transfer, but mSATA is physically smaller and designed for space-constrained applications where a 2.5-inch drive won't fit.
Does this drive come with installation software or cables?
The Kingston KC600 is a bare drive and does not include installation software, cables, or mounting brackets. Installation requires connecting the drive to an available mSATA slot on your motherboard or system board. For data migration from an existing drive, you may need third-party cloning software and appropriate adapters if your system doesn't have a secondary mSATA connection for the transfer process.
