Lenovo ThinkSystem DE2000H Hybrid Storage Array - 24 x HDD Supported - 24 x SSD Supported - 2 x 12Gb/s SAS Controller - RAID Supported (7Y71A003WW)
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Number of Hard Drives Supported: 24
Number of Hard Drives Installed: No
Number of Solid State Drive Supported: 24
Number of Solid State Drive Installed: No
Ethernet Technology: 10 Gigabit Ethernet
Number of Total Expansion Bays: 24
Number of 2.5" Bays: 24
Number of Controllers: 2
Controller Type: 12Gb/s SAS
RAID Supported: Yes
RAID Levels: 0, 1, 3, 5, 6, 10
Number of SAS Ports (External): 4
Total Number of USB Ports: 2
Network (RJ-45): Yes
Protocols: iSCSI,SSH,SMI-S,SNMP,SSL,LDAP
Maximum Power Supply Wattage: 913 W
Height: 3.35" (85 mm)
Width: 17.68" (449 mm)
Depth: 21.77" (553 mm)
Form Factor: Rack-mountable
Rack Height: 2U
- Through RAID levels (0, 1, 3, 5, 6, 10), RAID provides data reliability, fault tolerance and improves overall performance
- Optimize business network's performance with 10 Gigabit Ethernet connectivity
[custom-specifications]
| Specifications | |
| Manufacturer | Lenovo Group Limited |
| Manufacturer Part Number | 7Y71A003WW |
| Manufacturer Website Address | http://www.lenovo.com |
| Brand Name | Lenovo |
| Product Line | ThinkSystem |
| Product Series | DE |
| Product Model | DE2000H |
| Product Name | ThinkSystem DE2000H Hybrid Storage Array |
| Product Type | SAN Storage System |
| Storage | |
| Number of Hard Drives Supported | 24 |
| Number of Hard Drives Installed | No |
| Number of Solid State Drive Supported | 24 |
| Number of Solid State Drive Installed | No |
| Network & Communication | |
| Ethernet Technology | 10 Gigabit Ethernet |
| I/O Expansions | |
| Number of Total Expansion Bays | 24 |
| Number of 2.5" Bays | 24 |
| Controllers | |
| Number of Controllers | 2 |
| Controller Type | 12Gb/s SAS |
| RAID Supported | Yes |
| RAID Levels | 0, 1, 3, 5, 6, 10 |
| Interfaces/Ports | |
| Number of SAS Ports (External) | 4 |
| Total Number of USB Ports | 2 |
| Network (RJ-45) | Yes |
| Management & Protocols | |
| Protocols | iSCSI,SSH,SMI-S,SNMP,SSL,LDAP |
| Power Description | |
| Maximum Power Supply Wattage | 913 W |
| Physical Characteristics | |
| Height | 3.35" (85 mm) |
| Width | 17.68" (449 mm) |
| Depth | 21.77" (553 mm) |
| Form Factor | Rack-mountable |
| Rack Height | 2U |
[/custom-specifications]
