D-Link DWL-8710AP 802. 11ac Dual-Band Wireless Access Point - 1. 14 Gbit/s - 4 External Antennas - PoE PD - 2x Gigabit Ethernet Ports
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This access point operates on the IEEE 802.11ac wireless standard, which provides improved throughput and network efficiency compared to previous generations. The dual-band capability allows it to utilize both 2.4 GHz and 5 GHz frequencies, reducing interference and optimizing performance for a variety of devices and applications.
The DWL-8710AP includes two Gigabit Ethernet ports that support Ethernet, Fast Ethernet, and Gigabit Ethernet technologies, offering flexible wired connectivity options. One of these ports is PoE PD (Power over Ethernet Powered Device) compatible, enabling simplified installation by receiving both data and power over a single Ethernet cable from a PoE switch or injector.
Relevant factors for this section include Wireless LAN Standard, Frequency Band, Number of External Antennas, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The DWL-8710AP combines advanced wireless features with practical installation benefits to support reliable business networking. Its high-speed data transfer capabilities facilitate efficient network performance, enabling smooth operations for bandwidth-intensive tasks such as video conferencing, file transfers, and cloud-based applications.
Enhanced Coverage with External Antennas
Four external antennas provide adjustable positioning to optimize signal direction and coverage area, improving Wi-Fi reach and reducing dead zones in larger spaces.
- Adjustable antenna design
- Improved signal reliability
- Reduced interference
Simplified Deployment with PoE
PoE PD support allows the access point to be powered through the Ethernet cable, eliminating the need for a nearby power outlet and simplifying ceiling or wall mounting in optimal locations.
- Single-cable installation
- Flexible placement options
- Reduced wiring complexity
Deployment / Use Cases
The DWL-8710AP is ideal for businesses seeking to upgrade or expand their wireless infrastructure with a reliable and high-performance access point. Its dual-band operation and Gigabit Ethernet ports make it suitable for environments where both Wi-Fi and wired connections are necessary to support a mix of devices and network demands.
Common deployment scenarios include office networks, retail stores, small to medium-sized enterprises, and educational institutions. The access point can be mounted on ceilings or walls to provide centralized coverage, and its PoE capability streamlines installation in locations where power access is limited. It supports creating a unified wireless network that handles concurrent users and data-intensive applications without compromising performance.
Relevant factors for this section include Wireless LAN Standard, Frequency Band, Number of External Antennas, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
The DWL-8710AP has a compact form factor with dimensions of 9.84 inches wide, 8.66 inches deep, and 1.77 inches high (250 mm x 220 mm x 45 mm), making it discreet for ceiling or wall mounting. Its weight of approximately 4.53 pounds (2053 g) ensures stable installation without excessive bulk. The design supports standard mounting hardware for secure placement in commercial environments.
- Width
- 9.84" (250 mm)
- Depth
- 8.66" (220 mm)
- Height
- 1.77" (45 mm)
- Weight
- 4.53 lb (2053 g)
Highlights
- IEEE 802.11ac dual-band wireless access point for modern business networks
- Delivers up to 1.14 Gbit/s aggregate wireless speeds for high-performance connectivity
- Simultaneous 2.4 GHz and 5 GHz frequency bands reduce interference and optimize device compatibility
- Four external antennas with MIMO technology enhance signal range and reliability
- Two Gigabit Ethernet ports support Ethernet, Fast Ethernet, and Gigabit Ethernet connections
- PoE PD port enables simplified installation with power and data over a single cable
- Compact design suitable for ceiling or wall mounting in commercial environments
- Ideal for offices, retail spaces, and SMEs requiring robust Wi-Fi coverage
Specifications
| Specifications | |
|---|---|
| Manufacturer | D-Link Systems, Inc |
| Manufacturer Part Number | DWL-8710AP |
| Brand Name | D-Link |
| Product Model | DWL-8710AP |
| Product Name | 802.11n/ac Unified Wireless Outdoor Access Point |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11ac |
| Frequency Band | 2.40 GHz,5 GHz |
| Number of External Antennas | 4 |
| Wireless Transmission Speed | 1.14 Gbit/s |
| MIMO Technology | Yes |
| Interfaces/Ports | |
| Ethernet Technology | Ethernet,Fast Ethernet,Gigabit Ethernet |
| Number of Network (RJ-45) Ports | 2 |
| PoE PD Port | Yes |
| VGA | No |
| HDMI | No |
| USB | No |
| Powerline | No |
| Management Port | No |
| Physical Characteristics | |
| Height | 1.77" (45 mm) |
| Width | 9.84" (250 mm) |
| Depth | 8.66" (220 mm) |
| Weight (Approximate) | 4.53 lb (2053 g) |
User Manual
FAQ
What wireless standard does the D-Link DWL-8710AP support?
The D-Link DWL-8710AP supports the IEEE 802.11ac wireless standard, which provides improved throughput and network efficiency for modern business environments. This standard enables faster data transfer rates and better performance in crowded Wi-Fi networks compared to older standards like 802.11n.
Does this access point support Power over Ethernet (PoE)?
Yes, the DWL-8710AP includes a PoE PD (Power over Ethernet Powered Device) port. This allows the access point to receive both data and electrical power over a single Ethernet cable from a compatible PoE switch or injector, simplifying installation and enabling flexible placement without needing a nearby power outlet.
How many Ethernet ports are available on the DWL-8710AP?
The DWL-8710AP has two network (RJ-45) ports that support Ethernet, Fast Ethernet, and Gigabit Ethernet technologies. These ports provide wired connectivity options for linking the access point to your network infrastructure, such as switches or routers, and one port is PoE PD compatible for integrated power delivery.
What is the maximum wireless speed of this access point?
The DWL-8710AP offers a maximum wireless transmission speed of 1.14 Gbit/s. This aggregate speed is achieved through its dual-band operation on 2.4 GHz and 5 GHz frequencies, supporting high-performance networking for tasks like large file transfers, video streaming, and multiple connected devices.
Can the antennas on the DWL-8710AP be adjusted?
Yes, the DWL-8710AP is equipped with four external antennas that are adjustable. This allows you to position the antennas to optimize Wi-Fi coverage and signal direction for your specific environment, helping to improve range and reduce dead zones in areas like offices or retail spaces.
Is the DWL-8710AP suitable for ceiling mounting?
Yes, the DWL-8710AP is designed for ceiling or wall mounting in commercial settings. Its compact dimensions of 9.84" x 8.66" x 1.77" and PoE support make installation straightforward, allowing it to be placed in optimal locations for centralized Wi-Fi coverage without requiring complex wiring or power access.
