- 1 x HDMI over CAT6 Transmitter
- 1 x HDMI over CAT6 Receiver
- 2 x Ethernet Cables
- 2 x USB to Mini-USB Cables
- 1 X Universal Power Adapter (NA/EU/UK/AU)
- 1 x Mounting Kit
- 1 X Quick Install Guide
Marketing Information:
This HDMI® extender kit lets you transmit yourHD video sourceto your remote HDMIdisplay at a distance of up to 165 ft. (50 m) away. 1080p video can be extended 131 ft. (40 m) using shielded CAT 6 cabling. The extender features a built-in4-port USB 2.0 hub that also lets you connect four remote USB peripheral devices at your display location.
Crystal-clear picture quality
Using this HDMI extender, you can maintain the quality ofyour high-definition video signal along with theaccompanying 7.1 digital audio, even at 165 feet away from your source device. The extender supportsresolutions up to 1920x1200 or 1080p -perfectfor dazzling your audience in remote digital-signage applications in hospitalsor at shopping centers.
Hassle-free remote USB integration
The built-in 4-port USB 2.0 hub lets you remotely connect, access or control up to four USB devices located at your remote display -great forflash drives, printers, scanners, external hard drives andI/O devices.Remote USB extension also enables you to remotelycontrol your sourcedevice, which is idealfor adding touchscreen interfaces at your display in market or POS kiosks.
Easy installation and setup
For hassle-freesetupthe HDMI extender offerseasy plug-and-play installation with noadditional software or drivers required. Plus, the extender passes theEDID information included inyour HDMIsignal,and automatically adjusts video equalizationensuring you won't have to configure it manually. Mounting hardware is also included, for a tidy and professional installation.
Note: To maximize performance this extender requires shielded CAT6 cable. When using unshielded CAT6 cable the maximum distance is reduced to 30m. When using CAT5 cable the maximum distance is reduced to 15m.
The ST121USBHD is TAA compliant and backed by a 2-year StarTech.com warranty with free lifetime technical support.
Connectivity Technology: Wired
Number of Input Devices Supported: 1
Number of Output Devices Supported: 1
Maximum Operating Distance: 260 ft (79248 mm)
Graphics Modes: WUXGA
Maximum Video Resolution: 1920 x 1200
Network (RJ-45): Yes
HDMI In: Yes
HDMI Out: Yes
USB: Yes
Number of Network (RJ-45) Ports: 4
Number of USB Ports: 5
Number of HDMI Inputs: 1
Number of HDMI Outputs: 1
Media Type Supported: Twisted Pair
Twisted Pair Cable Standard: Category 6
Transmitter Height: 0.80" (20.32 mm)
Transmitter Width: 3.20" (81.28 mm)
Transmitter Depth: 3.20" (81.28 mm)
Receiver Height: 0.80" (20.32 mm)
Receiver Width: 3.20" (81.28 mm)
Receiver Depth: 3.20" (81.28 mm)
Transmitter Weight (Approximate): 460 g
Receiver Weight (Approximate): 460 g
Package Contents:
Country of Origin: Taiwan
TAA Compliant: Yes
Environmentally Friendly: Yes
Limited Warranty: 2 Year
- Crystal-clear picture quality, with support for uncompressed 1920x1200 or 1080p HD video extension
- Easy remote peripheral integration, with a built-in 4-port USB hub
- Tidy, professional installation using the included mounting hardware
- Extends HDMI video and four USB peripheral devices up to 165 ft
- Supports CAT5e and CAT6 Ethernet cable
- HDMI transmitter and receiver included
[custom-specifications]
Specifications | |
---|---|
Manufacturer | StarTech.com |
Manufacturer Part Number | ST121USBHD |
Manufacturer Website Address | http://www.startech.com |
Brand Name | StarTech.com |
Product Name | HDMI over CAT6 Extender with 4-port USB Hub - 165 ft (50m) - 1080p |
Packaged Quantity Condition | Kit |
Product Type | Video Extender Transmitter/Receiver | Technical Information |
Connectivity Technology | Wired |
Number of Input Devices Supported | 1 |
Number of Output Devices Supported | 1 |
Maximum Operating Distance | 260 ft (79248 mm) | Video |
Graphics Modes | WUXGA |
Maximum Video Resolution | 1920 x 1200 | Interfaces/Ports |
Network (RJ-45) | Yes |
HDMI In | Yes |
HDMI Out | Yes |
USB | Yes |
Number of Network (RJ-45) Ports | 4 |
Number of USB Ports | 5 |
Number of HDMI Inputs | 1 |
Number of HDMI Outputs | 1 | Media & Performance |
Media Type Supported | Twisted Pair |
Twisted Pair Cable Standard | Category 6 | Physical Characteristics |
Transmitter Height | 0.80" (20.32 mm) |
Transmitter Width | 3.20" (81.28 mm) |
Transmitter Depth | 3.20" (81.28 mm) |
Receiver Height | 0.80" (20.32 mm) |
Receiver Width | 3.20" (81.28 mm) |
Receiver Depth | 3.20" (81.28 mm) |
Transmitter Weight (Approximate) | 460 g |
Receiver Weight (Approximate) | 460 g | Miscellaneous |
Package Contents |
|
Country of Origin | Taiwan |
TAA Compliant | Yes |
Environmentally Friendly | Yes | Warranty |
Limited Warranty | 2 Year |
[/custom-specifications]
[custom-options]
[/custom-options]
[custom-user-manual]
Available Documentation:
Additional-pdf1
Additional-pdf2
[/custom-user-manual]
Warranty Infomartion
2 Year
