This multi-input HDBaseT™ extender kit extends your A/V signals to a remote location up to 230 ft. (70 m) away. It features a built-in switch and scaler, so you can choose which video source is output from four independent video sources (2 x HDMI, 1 x VGA and 1 x DisplayPort).
Seamless Integration and Operation
The HDBaseT extender's built-in converter switch lets you connect two HDMI sources, a VGA source, and a DP source to the same remote and local HDMI display. You don't need adapters or scalers, or a video switch.
Along with manually switching your video source with easy-to-use buttons, the video extender ensures hassle-free operation with two auto-switching modes: auto-detect switching, which detects and selects a newly connected device, and priority selection, which lets you choose which port is activated by default, for automatic switching.
Built-In Video Scaling
This HDBaseT extender features a built-in scaler that scales the image to 1080p, so you can rest assured your HDMI display will intuitively work with any source that's connected through it. Scaling is easy to do, with an intuitive OSD that's accessible using buttons on the remote receiver. Newer HDMI displays no longer support legacy resolution video signals. Without support for these common VGA resolutions, your source may not work with your new HDMI display.
High-Definition 1080p Video at 230 Feet (70 Meters)
The extender kit maintains your HD picture quality, even at 230 ft. (70 m) away from your video source, ensuring you can provide the best possible viewing experience.
The ST121HDBTSC is backed by a 2-year StarTech.com warranty and free lifetime technical support.
Connectivity Technology: WiredNumber of Input Devices Supported: 4Number of Output Devices Supported: 1Maximum Operating Distance: 229.66 ft (70000 mm)Graphics Modes: WUXGAMaximum Video Resolution: 1920 x 1200Network (RJ-45): YesHDMI In: YesHDMI Out: YesVGA In: YesDisplayPort: YesNumber of Network (RJ-45) Ports: 2Number of HDMI Inputs: 2Number of HDMI Outputs: 2Number of VGA Inputs: 1Media Type Supported: Twisted PairTwisted Pair Cable Standard: Category 6Color: BlackTransmitter Height: 2.60" (66.04 mm)Transmitter Width: 2.40" (60.96 mm)Transmitter Depth: 4.20" (106.68 mm)Receiver Height: 2.60" (66.04 mm)Receiver Width: 2.40" (60.96 mm)Receiver Depth: 4.20" (106.68 mm)Form Factor: DesktopTransmitter Weight (Approximate): 2 kgReceiver Weight (Approximate): 2 kgPackage Contents:[custom-specifications]
