StarTech.com Multi-Input HDBaseT Extender Kit with Built-In Switch and Video Scaler - DisplayPort HDMI and VGA Over CAT6 or CAT5 - to (ST121HDBTSC)

Marketing Information:

This multi-input HDBaseT™ extender kit extends your A/V signals to a remote location up to 230 ft. (70 m) away. It features a built-in switch and scaler, so you can choose which video source is output from four independent video sources (2 x HDMI, 1 x VGA and 1 x DisplayPort).

Seamless Integration and Operation

TheHDBaseT extender's built-in converter switch lets you connect two HDMI sources, a VGA source, and a DPsource to the same remote and local HDMI display. You don't needadapters or scalers, or a video switch.

Along with manuallyswitching your video source with easy-to-use buttons, the video extender ensures hassle-free operationwith twoauto-switching modes: auto-detect switching, which detects and selects a newly connected device, andpriority selection, which lets you choose whichport is activated by default, for automatic switching.

Built-In Video Scaling

This HDBaseT extenderfeatures a built-in scaler that scales the image to 1080p, so you can rest assured yourHDMI display will intuitively work with any source that's connected through it. Scaling is easy to do,with an intuitive OSD that's accessible using buttons on theremote receiver. Newer HDMI displays no longer support legacy resolution video signals. Without support for these common VGA resolutions, your source may not work with your new HDMI display.

High-Definition 1080p Video at230 Feet (70 Meters)

The extender kit maintains your HD picture quality, even at230ft. (70 m) away from your video source, ensuringyou can provide the best possible viewing experience.

The ST121HDBTSC is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Connectivity Technology: Wired

Number of Input Devices Supported: 4

Number of Output Devices Supported: 1

Maximum Operating Distance: 229.66 ft (70000 mm)

Graphics Modes: WUXGA

Maximum Video Resolution: 1920 x 1200

Network (RJ-45): Yes

HDMI In: Yes

HDMI Out: Yes

VGA In: Yes

DisplayPort: Yes

Number of Network (RJ-45) Ports: 2

Number of HDMI Inputs: 2

Number of HDMI Outputs: 2

Number of VGA Inputs: 1

Media Type Supported: Twisted Pair

Twisted Pair Cable Standard: Category 6

Product Color: Black

Transmitter Height: 2.60" (66.04 mm)

Transmitter Width: 2.40" (60.96 mm)

Transmitter Depth: 4.20" (106.68 mm)

Receiver Height: 2.60" (66.04 mm)

Receiver Width: 2.40" (60.96 mm)

Receiver Depth: 4.20" (106.68 mm)

Form Factor: Desktop

Transmitter Weight (Approximate): 2 kg

Receiver Weight (Approximate): 2 kg

Package Contents:

• 1 x HDBaseT Transmitter
• 1 x HDBaseT Scaler Receiver
• 1 x Remote Control
• 1 x RJ-11 to RS-232 Adapter
• 1 x CAT5 Cable
• 1 x RJ-11 Cable
• 2 x Sets of Mounting Brackets
• 1 x Universal Power Adapter (NA/JP, EU, UK, ANZ)
• 1 x IR Blaster
• 1 x IR Receiver
• 2 x Sets of Rubber Feet
• 1 x Quick-Start Guide

Country of Origin: Taiwan

TAA Compliant: Yes

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)

Limited Warranty: 2 Year
