SonicWall 03-SSC-0319 SonicWave 681 Wi-Fi 6 Dual-Band Indoor Access Point - 12 Internal Antennas - MU-MIMO - PoE - Ceiling Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The SonicWave 681 operates as a Power over Ethernet (PoE) Powered Device (PD), receiving both data and power over a single Ethernet cable for simplified installation. Its single RJ-45 network port supports 5 Gigabit Ethernet, Gigabit Ethernet, and Fast Ethernet connections, providing flexible uplink options.
Advanced radio features include Target Wake Time (TWT) for better power management on client devices, neighboring network avoidance to reduce interference, and integrated Wireless Intrusion Detection System (WIDS) and Wireless Intrusion Prevention System (WIPS) for threat detection and active remediation. Rogue access point and device detection further enhance network security.
Relevant factors for this section include Wireless LAN Standard, Bluetooth Standard, Network Band, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SonicWave 681 combines advanced Wi-Fi 6 performance with robust security and easy deployment, making it a versatile choice for upgrading wireless infrastructure.
Enhanced Performance
Leverages 12 internal antennas with MU-MIMO and beamforming to support more concurrent clients with stronger, more reliable connections, ideal for high-density environments.
- Increased throughput
- Reduced latency
- Better power management for client devices
Integrated Security
Features WPA3 encryption alongside WIDS and WIPS capabilities to detect and remediate wireless threats, protecting the network from rogue devices and attacks.
- WPA3/WPA2/AES encryption
- Rogue AP and device detection
- Active threat remediation
Simplified Deployment
PoE-powered design and included ceiling mounting kit allow for clean, flexible installation without separate power outlets, reducing cabling complexity and costs.
- Ceiling mountable form factor
- PoE PD support
- Included mounting hardware
Deployment / Use Cases
The SonicWave 681 is tailored for indoor environments requiring robust, secure Wi-Fi coverage. Its ceiling-mountable form factor and PoE support make it particularly suitable for installations where aesthetics and cable management are priorities.
Common deployment scenarios include corporate offices, educational institutions, healthcare facilities, retail stores, and hospitality venues. The access point's advanced features support applications like high-density video conferencing, cloud-based software access, IoT device connectivity, and secure guest networking.
Relevant factors for this section include Wireless LAN Standard, Bluetooth Standard, Network Band, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Enterprise Offices
Provides reliable Wi-Fi for employees and guests, with security features to protect sensitive business data and network resources.
Education & Healthcare
Supports high client densities in classrooms or patient areas, with encryption and threat detection to meet compliance and privacy requirements.
Physical Profile
The access point features a compact, low-profile design measuring 8.39" (213 mm) in width and height, with a depth of 1.54" (39 mm). It weighs approximately 2.43 lb (1100 g), making it lightweight for ceiling installation. The internal antenna design provides a clean aesthetic without external protrusions, and the unit is built for durable performance in indoor commercial environments.
- Width
- 8.39" (213 mm)
- Depth
- 1.54" (39 mm)
- Height
- 8.39" (213 mm)
- Weight
- 2.43 lb (1100 g)
What's in the Box
The package includes everything needed for immediate deployment of the access point.
Package contents include SonicWave 681 Wireless Access Point Ceiling Mounting Kit, SonicWave 681 Wireless Access Point. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Wi-Fi 6 (802.11ax) dual-band access point for high-speed wireless
- 12 internal antennas with MU-MIMO and beamforming technology
- PoE PD support for simplified installation and power delivery
- WPA3, WPA2, AES, and WPA2-ENT encryption standards
- Integrated WIDS and WIPS for threat detection and remediation
- Ceiling-mountable form factor with included mounting kit
- Bluetooth 5 for additional device connectivity
- USB 3.0 port for expanded functionality
- RADIUS and SSL communication protocols
- TAA compliant and environmentally friendly design
Specifications
| Specifications | |
|---|---|
| Manufacturer | SonicWall Inc. |
| Manufacturer Part Number | 03-SSC-0319 |
| Brand Name | SonicWall |
| Product Line | SonicWave |
| Product Series | 600 |
| Product Model | 681 |
| Product Name | SonicWave 681 Wireless Access Point |
| Packaged Quantity | 4 |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Bluetooth Standard | Bluetooth 5 |
| Network Band | Dual Band |
| Frequency Band | 2.40 GHz,5 GHz |
| Total Number of Antennas | 12 |
| Number of Internal Antennas | 12 |
| Indoor/Outdoor | Indoor |
| MIMO Technology | Yes |
| MIMO Type | Multi User MIMO |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WPA3,WPA2,AES,WPA2-ENT |
| Interfaces/Ports | |
| Ethernet Technology | 5 Gigabit Ethernet,Gigabit Ethernet,Fast Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| PoE PD Port | Yes |
| USB | Yes |
| USB Standard | USB 3.0 |
| Management Port | Yes |
| Network & Communication | |
| Wi-Fi Generation | Wi-Fi 6 |
| Communication Protocols | RADIUS,SSL |
| Power Description | |
| Power Consumption | 34 W |
| Physical Characteristics | |
| Form Factor | Ceiling Mountable |
| Antenna Form Factor | Internal |
| Height | 8.39" (213 mm) |
| Width | 8.39" (213 mm) |
| Depth | 1.54" (39 mm) |
| Weight (Approximate) | 2.43 lb (1100 g) |
| Miscellaneous | |
| Package Contents | SonicWave 681 Wireless Access Point Ceiling Mounting Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
User Manual
FAQ
What Wi-Fi standard does the SonicWave 681 support?
The SonicWave 681 supports Wi-Fi 6, also known as IEEE 802.11ax. This latest standard provides increased throughput, reduced latency, better power management for client devices, and improved performance in high-density environments compared to previous Wi-Fi generations like 802.11ac.
Does this access point support Power over Ethernet (PoE)?
Yes, the SonicWave 681 includes a PoE PD (Powered Device) port. This allows it to receive both data and electrical power over a single Ethernet cable from a compatible PoE switch or injector, simplifying installation by eliminating the need for a separate power outlet near the access point.
How many antennas does the SonicWave 681 have, and are they internal or external?
This access point features 12 internal antennas. The internal design provides a clean, low-profile appearance without external antenna protrusions, making it suitable for ceiling-mounted installations in professional environments where aesthetics are important.
What security features are included with this wireless access point?
The SonicWave 681 offers robust security including WPA3, WPA2, AES, and WPA2-ENT encryption standards. It also includes a Wireless Intrusion Detection System (WIDS) for threat detection, a Wireless Intrusion Prevention System (WIPS) for active threat remediation, and rogue access point and device detection capabilities to protect your network.
Is the SonicWave 681 designed for indoor or outdoor use?
This access point is designed specifically for indoor use. It features a ceiling-mountable form factor with an included mounting kit, making it ideal for deployment in offices, schools, retail spaces, and other commercial indoor environments where reliable Wi-Fi coverage is needed.
What is included in the package with the SonicWave 681 access point?
The package includes the SonicWave 681 Wireless Access Point itself along with a Ceiling Mounting Kit. This provides all necessary hardware for immediate installation and deployment of the access point in your environment without requiring additional mounting components.
