SonicWall 03-SSC-0331 SonicWave 681 Wi-Fi 6 Dual-Band Indoor Wireless Access Point - 12 Internal Antennas - MU-MIMO - PoE - Ceiling Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The SonicWave 681 leverages Wi-Fi 6 technology to optimize network efficiency and client performance. It incorporates Multi-User MIMO (MU-MIMO) and beamforming technologies to direct wireless signals to connected devices, improving throughput and reducing interference in high-density scenarios.
This access point includes a single RJ-45 Ethernet port that supports 5 Gigabit Ethernet, Gigabit Ethernet, and Fast Ethernet connections. The integrated PoE PD port allows for simplified installation using Power over Ethernet, eliminating the need for separate power cabling. A USB 3.0 port is available for potential expansion or management purposes.
Relevant factors for this section include Wireless LAN Standard, Bluetooth Standard, Network Band, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SonicWave 681 offers several advantages for enterprise wireless deployments, combining modern Wi-Fi standards with robust security and management features.
Enhanced Wi-Fi 6 Performance
Supports IEEE 802.11ax for higher data rates, improved capacity in client-dense environments, and better power management through features like Target Wake Time (TWT).
- Increased throughput
- Reduced latency
- Longer battery life for client devices
Advanced Security Capabilities
Includes WPA3 encryption alongside WPA2 and AES for robust wireless security. Integrated Wireless Intrusion Detection System (WIDS) and Wireless Intrusion Prevention System (WIPS) help detect and remediate threats.
- WPA3/WPA2/AES encryption
- Rogue AP and device detection
- Active threat remediation
Simplified Deployment
Ceiling-mountable design with included mounting kit and PoE support streamlines installation. Internal antennas provide a clean aesthetic without external protrusions.
- Ceiling mounting kit included
- PoE powered
- Internal antenna design
Deployment / Use Cases
The SonicWave 681 is suited for various indoor wireless networking scenarios where reliable, high-speed connectivity is required. Its dual-band Wi-Fi 6 capabilities make it effective in environments with many concurrent users and bandwidth-intensive applications.
Typical deployments include corporate offices, conference rooms, and open-plan workspaces where ceiling mounting provides optimal coverage. Educational campuses can use these access points in classrooms and libraries to support student devices and digital learning tools. Retail stores and hospitality venues benefit from the consistent connectivity for point-of-sale systems, guest Wi-Fi, and inventory management.
Enterprise Office Networks
Provides stable wireless connectivity for employees across workspaces, meeting rooms, and common areas, supporting business applications and collaboration tools.
Education & Healthcare
Delivers reliable Wi-Fi for student devices, digital signage, and medical IoT equipment in environments where uptime and security are paramount.
Physical Profile
The SonicWave 681 features a compact, low-profile design measuring 8.39 inches in width and height, with a depth of 1.54 inches. Its approximate weight is 2.43 pounds, making it lightweight for ceiling installations. The internal antenna design maintains a sleek appearance while providing omnidirectional coverage. The unit is intended for indoor use only and includes a ceiling mounting kit for straightforward installation.
- Width
- 8.39" (213 mm)
- Depth
- 1.54" (39 mm)
- Height
- 8.39" (213 mm)
- Weight
- 2.43 lb (1100 g)
What's in the Box
The package includes the SonicWave 681 Wireless Access Point and a ceiling mounting kit for immediate deployment.
Package contents include SonicWave 681 Wireless Access Point Ceiling Mounting Kit, SonicWave 681 Wireless Access Point. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Wi-Fi 6 (802.11ax) dual-band wireless access point
- 12 internal antennas for optimized coverage
- Multi-User MIMO (MU-MIMO) and beamforming technologies
- Power over Ethernet (PoE) support for simplified installation
- Ceiling-mountable form factor with included mounting kit
- WPA3, WPA2, AES, and WPA2-ENT encryption standards
- Integrated USB 3.0 port for expansion
- Wireless Intrusion Detection and Prevention (WIDS/WIPS)
- TAA compliant for government and public sector use
- RoHS, WEEE, and China RoHS environmental compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | SonicWall Inc. |
| Manufacturer Part Number | 03-SSC-0331 |
| Brand Name | SonicWall |
| Product Line | SonicWave |
| Product Series | 600 |
| Product Model | 681 |
| Product Name | SonicWave 681 Wireless Access Point |
| Packaged Quantity | 8 |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Bluetooth Standard | Bluetooth 5 |
| Network Band | Dual Band |
| Frequency Band | 2.40 GHz,5 GHz |
| Total Number of Antennas | 12 |
| Number of Internal Antennas | 12 |
| Indoor/Outdoor | Indoor |
| MIMO Technology | Yes |
| MIMO Type | Multi User MIMO |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WPA3,WPA2,AES,WPA2-ENT |
| Interfaces/Ports | |
| Ethernet Technology | 5 Gigabit Ethernet,Gigabit Ethernet,Fast Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| PoE PD Port | Yes |
| USB | Yes |
| USB Standard | USB 3.0 |
| Management Port | Yes |
| Network & Communication | |
| Wi-Fi Generation | Wi-Fi 6 |
| Communication Protocols | RADIUS,SSL |
| Power Description | |
| Power Consumption | 34 W |
| Physical Characteristics | |
| Form Factor | Ceiling Mountable |
| Antenna Form Factor | Internal |
| Height | 8.39" (213 mm) |
| Width | 8.39" (213 mm) |
| Depth | 1.54" (39 mm) |
| Weight (Approximate) | 2.43 lb (1100 g) |
| Miscellaneous | |
| Package Contents | SonicWave 681 Wireless Access Point Ceiling Mounting Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
User Manual
FAQ
What Wi-Fi standard does the SonicWave 681 support?
The SonicWave 681 supports the Wi-Fi 6 standard, also known as IEEE 802.11ax. This includes backward compatibility with earlier standards like 802.11a/b/g/n/ac. Wi-Fi 6 provides higher data rates, improved efficiency in dense client environments, and features like Target Wake Time for better power management on connected devices.
Does this access point support Power over Ethernet (PoE)?
Yes, the SonicWave 681 includes a PoE PD (Powered Device) port. This allows the access point to receive both power and data over a single Ethernet cable from a compatible PoE switch or injector, simplifying installation by eliminating the need for a separate power outlet near the mounting location.
How many antennas does the SonicWave 681 have, and are they internal or external?
This access point has 12 internal antennas. The internal design provides a clean, low-profile appearance without external antenna protrusions, making it suitable for ceiling-mounted installations in professional environments where aesthetics are important.
What security features are included with this wireless access point?
The SonicWave 681 supports multiple encryption standards including WPA3, WPA2, AES, and WPA2-ENT. It also includes Wireless Intrusion Detection System (WIDS) for threat detection and Wireless Intrusion Prevention System (WIPS) for active threat remediation. These features help identify and mitigate rogue access points and unauthorized devices on the network.
Is the SonicWave 681 suitable for ceiling mounting?
Yes, the SonicWave 681 is designed for ceiling mounting and includes a ceiling mounting kit in the package. Its form factor is specifically intended for indoor ceiling installations, providing broad wireless coverage in office spaces, classrooms, retail environments, and other commercial settings.
What is the power consumption of this access point?
The SonicWave 681 has a power consumption of 34 watts. This power draw is typical for a high-performance dual-band Wi-Fi 6 access point with multiple internal antennas and advanced features. When using PoE, ensure your PoE switch or injector can provide sufficient power, typically requiring 802.3at (PoE+) or higher.
