SonicWall 03-SSC-0333 SonicWave 681 Wi-Fi 6 Dual-Band Indoor Wireless Access Point - 4. 80 Gbit/s - 12 Internal Antennas - Ceiling Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The SonicWave 681 leverages Wi-Fi 6 technology to provide significant improvements in network efficiency, capacity, and performance over previous generations. It operates on both 2.4 GHz and 5 GHz frequency bands, utilizing 12 internal antennas to create robust wireless coverage. Advanced features like Multi-User MIMO (MU-MIMO) allow simultaneous data transmission to multiple clients, while beamforming focuses wireless signals directly toward connected devices for stronger, more reliable connections.
For network security, the access point supports WPA3, WPA2, AES, and WPA2-ENT encryption standards, ensuring data protection for enterprise networks. It includes integrated threat detection capabilities such as Wireless Intrusion Detection System (WIDS) and Wireless Intrusion Prevention System (WIPS) to identify and remediate rogue access points and malicious devices on the network.
Relevant factors for this section include Wireless LAN Standard, Bluetooth Standard, Network Band, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SonicWave 681 access point delivers enterprise-grade wireless performance with features designed to maximize network reliability and security in business settings. Its Wi-Fi 6 foundation provides the throughput and low latency required for modern applications, from video conferencing to cloud-based services.
Enhanced Client Capacity and Efficiency
Wi-Fi 6 technology, combined with MU-MIMO and 12 internal antennas, supports a high density of concurrent users and devices without sacrificing performance. Features like Target Wake Time (TWT) help manage client power consumption, extending battery life for IoT and mobile devices.
Integrated Security and Management
Built-in WIDS and WIPS provide continuous monitoring and active threat remediation, protecting the network from unauthorized access points and devices. Support for RADIUS and SSL communication protocols enables secure authentication and encrypted management connections.
Simplified Deployment and Power
The ceiling-mountable design and PoE support allow for flexible, clean installations in offices, classrooms, or retail spaces. A single Ethernet cable provides both network connectivity and power, reducing installation complexity and cost.
Deployment / Use Cases
The SonicWall SonicWave 681 is ideally suited for medium to large business environments where reliable, high-speed wireless connectivity is critical. Its performance and feature set make it a strong choice for modern office networks, educational institutions, healthcare facilities, and retail locations that require secure, scalable Wi-Fi coverage.
In office settings, the access point can support a high density of laptops, smartphones, and VoIP phones, ensuring smooth operation of cloud applications and unified communications. For educational deployments, it provides the capacity for student and faculty devices while integrating security features to protect network resources. The ceiling-mount form factor and PoE capability make installation straightforward in drop-ceiling environments common to these use cases.
Physical Profile
The SonicWave 681 features a compact, circular design measuring 8.39 inches in width and depth, with a slim 1.54-inch profile for discreet ceiling mounting. Weighing approximately 2.43 pounds, it is lightweight yet durable for commercial installations. The all-internal antenna design maintains a clean aesthetic without external protrusions, suitable for professional environments where appearance matters. The unit is designed for indoor use only and includes a ceiling mounting kit in the package for straightforward installation.
- Width
- 8.39" (213 mm)
- Depth
- 1.54" (39 mm)
- Height
- 8.39" (213 mm)
- Weight
- 2.43 lb (1100 g)
What's in the Box
The package includes the SonicWave 681 Wireless Access Point and a Ceiling Mounting Kit, providing everything needed for a standard installation.
Package contents include SonicWave 681 Wireless Access Point Ceiling Mounting Kit, SonicWave 681 Wireless Access Point. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Wi-Fi 6 (802.11ax) for high efficiency and throughput
- Dual-band operation on 2.4 GHz and 5 GHz frequencies
- 12 internal antennas with MU-MIMO and beamforming
- Maximum wireless speed of 4.80 Gbit/s
- Power over Ethernet (PoE) supported for simplified installation
- Ceiling-mountable form factor for discreet placement
- WPA3, WPA2, AES, and WPA2-ENT encryption standards
- Integrated WIDS and WIPS for threat detection and prevention
- Bluetooth 5 for additional device connectivity
- TAA compliant and meets RoHS environmental standards
Specifications
| Specifications | |
|---|---|
| Manufacturer | SonicWall Inc. |
| Manufacturer Part Number | 03-SSC-0333 |
| Brand Name | SonicWall |
| Product Line | SonicWave |
| Product Series | 600 |
| Product Model | 681 |
| Product Name | SonicWave 681 Wireless Access Point |
| Packaged Quantity | 4 |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Bluetooth Standard | Bluetooth 5 |
| Network Band | Dual Band |
| Frequency Band | 2.40 GHz,5 GHz |
| Total Number of Antennas | 12 |
| Number of Internal Antennas | 12 |
| Indoor/Outdoor | Indoor |
| Wireless Transmission Speed | 4.80 Gbit/s |
| MIMO Technology | Yes |
| MIMO Type | Multi User MIMO |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WPA3,WPA2,AES,WPA2-ENT |
| Interfaces/Ports | |
| Ethernet Technology | 5 Gigabit Ethernet,Gigabit Ethernet,Fast Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| PoE PD Port | Yes |
| USB | Yes |
| USB Standard | USB 3.0 |
| Management Port | Yes |
| Network & Communication | |
| Wi-Fi Generation | Wi-Fi 6 |
| Communication Protocols | RADIUS,SSL |
| Power Description | |
| Power Consumption | 34 W |
| Physical Characteristics | |
| Form Factor | Ceiling Mountable |
| Antenna Form Factor | Internal |
| Height | 8.39" (213 mm) |
| Width | 8.39" (213 mm) |
| Depth | 1.54" (39 mm) |
| Weight (Approximate) | 2.43 lb (1100 g) |
| Miscellaneous | |
| Package Contents | SonicWave 681 Wireless Access Point Ceiling Mounting Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
User Manual
FAQ
What is the maximum wireless throughput of the SonicWave 681 access point?
The SonicWave 681 delivers a maximum aggregate wireless throughput of 4.80 Gbit/s. This high-speed performance is achieved through Wi-Fi 6 (802.11ax) technology, which improves efficiency and capacity for handling multiple concurrent clients and bandwidth-intensive applications in enterprise environments.
Does this access point support Power over Ethernet (PoE)?
Yes, the SonicWave 681 includes a PoE PD (Powered Device) port. This allows the access point to receive both data and electrical power over a single Ethernet cable from a compatible PoE switch or injector, simplifying installation by eliminating the need for a separate power outlet near the mounting location.
How many antennas does the SonicWave 681 have, and are they internal or external?
This access point features 12 internal antennas. The internal antenna design provides a clean, low-profile appearance suitable for ceiling-mounted installations in professional settings, while still delivering robust wireless coverage and performance across both 2.4 GHz and 5 GHz bands.
What wireless security features are included with this access point?
The SonicWave 681 supports multiple encryption standards including WPA3, WPA2, AES, and WPA2-ENT to secure wireless communications. It also includes integrated Wireless Intrusion Detection System (WIDS) and Wireless Intrusion Prevention System (WIPS) capabilities for monitoring the network and actively remediating threats such as rogue access points and unauthorized devices.
Is the SonicWave 681 designed for indoor or outdoor use?
This access point is designed for indoor use only. It features a ceiling-mountable form factor ideal for installation in offices, classrooms, retail spaces, and other commercial indoor environments where controlled temperature and conditions are present.
What is included in the package with the SonicWave 681 access point?
The package contains the SonicWave 681 Wireless Access Point unit and a Ceiling Mounting Kit. The mounting kit includes the necessary hardware for installing the access point onto a standard ceiling tile or surface, providing a complete solution for deployment right out of the box.
