SonicWall 03-SSC-0344 SonicWave 681 Wi-Fi 6 Dual-Band Indoor Wireless Access Point - 12 Internal Antennas - MU-MIMO - PoE - Ceiling Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The SonicWave 681 operates on both 2.4 GHz and 5 GHz frequency bands, providing flexible channel selection and reduced interference in congested wireless environments. With Wi-Fi 6 technology, it offers increased throughput, reduced latency, and improved power management for connected devices through features like Target Wake Time (TWT).
This access point incorporates advanced security capabilities including WPA3 encryption, RADIUS and SSL communication protocols, and integrated threat detection through Wireless Intrusion Detection System (WIDS) and Wireless Intrusion Prevention System (WIPS). These features help identify and remediate rogue access points and unauthorized devices on the network.
Relevant factors for this section include Wireless LAN Standard, Bluetooth Standard, Network Band, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SonicWave 681 combines enterprise-grade wireless performance with simplified deployment and management. Its 12 internal antennas and MU-MIMO technology enable simultaneous data transmission to multiple devices, improving overall network efficiency in client-dense environments.
Enhanced Wi-Fi 6 Performance
Delivers higher data rates, increased capacity, and better performance in environments with many connected devices through OFDMA and 1024-QAM modulation.
- Increased throughput
- Reduced latency
- Better power management
- Longer battery life for devices
Advanced Security Features
Provides comprehensive wireless security with the latest encryption standards and threat detection capabilities.
- WPA3 encryption support
- RADIUS authentication
- WIDS/WIPS for threat detection
- Rogue AP and device detection
Simplified Deployment
Designed for easy installation with included ceiling mounting hardware and PoE support for single-cable connectivity.
- Ceiling mountable form factor
- PoE PD port
- Management port for configuration
- USB 3.0 for additional connectivity
Deployment / Use Cases
The SonicWave 681 is ideal for medium to large-scale indoor wireless deployments where reliable, high-performance Wi-Fi is essential. Its ceiling-mountable design and PoE capability make it particularly suitable for environments where aesthetics and cable management are important considerations.
This access point excels in educational institutions for classroom connectivity, healthcare facilities for medical device connectivity, retail environments for point-of-sale systems and customer Wi-Fi, and corporate offices supporting high-density work areas. The neighboring network avoidance feature helps maintain optimal performance in multi-tenant buildings and crowded RF environments.
Enterprise Office Deployment
Supports high-density work areas with multiple connected devices per user, including laptops, smartphones, and IoT devices, while maintaining consistent performance.
Education & Healthcare
Provides reliable connectivity for classroom technology, medical devices, and staff communications with enhanced security features for sensitive environments.
Physical Profile
The SonicWave 681 features a compact, circular design measuring 8.39" in diameter and 1.54" in depth, with a weight of approximately 2.43 pounds. Its low-profile form factor blends discreetly into ceiling installations while housing 12 internal antennas. The unit is designed specifically for indoor use and includes all necessary mounting hardware for secure ceiling installation.
- Width
- 8.39" (213 mm)
- Depth
- 1.54" (39 mm)
- Height
- 8.39" (213 mm)
- Weight
- 2.43 lb (1100 g)
What's in the Box
The SonicWave 681 ships complete with all necessary components for immediate deployment.
Package contents include SonicWave 681 Wireless Access Point Ceiling Mounting Kit, SonicWave 681 Wireless Access Point. These included items support setup, installation, and immediate deployment without needing to source the core bundled accessories separately.
Highlights
- Wi-Fi 6 (802.11ax) dual-band wireless access point
- 12 internal antennas with MU-MIMO and beamforming technology
- Ceiling mountable design with included mounting kit
- PoE (Power over Ethernet) support for simplified installation
- WPA3, WPA2, AES, and WPA2-ENT encryption standards
- Bluetooth 5 for additional connectivity options
- USB 3.0 port for expanded functionality
- RADIUS and SSL communication protocols
- 34W power consumption with efficient operation
- TAA compliant and environmentally friendly design
Specifications
| Specifications | |
|---|---|
| Manufacturer | SonicWall Inc. |
| Manufacturer Part Number | 03-SSC-0344 |
| Brand Name | SonicWall |
| Product Line | SonicWave |
| Product Series | 600 |
| Product Model | 681 |
| Product Name | SonicWave 681 Wireless Access Point |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Bluetooth Standard | Bluetooth 5 |
| Network Band | Dual Band |
| Frequency Band | 2.40 GHz,5 GHz |
| Total Number of Antennas | 12 |
| Number of Internal Antennas | 12 |
| Indoor/Outdoor | Indoor |
| MIMO Technology | Yes |
| MIMO Type | Multi User MIMO |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WPA3,WPA2,AES,WPA2-ENT |
| Interfaces/Ports | |
| Ethernet Technology | 5 Gigabit Ethernet,Gigabit Ethernet,Fast Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| PoE PD Port | Yes |
| USB | Yes |
| USB Standard | USB 3.0 |
| Management Port | Yes |
| Network & Communication | |
| Wi-Fi Generation | Wi-Fi 6 |
| Communication Protocols | RADIUS,SSL |
| Power Description | |
| Power Consumption | 34 W |
| Physical Characteristics | |
| Form Factor | Ceiling Mountable |
| Antenna Form Factor | Internal |
| Height | 8.39" (213 mm) |
| Width | 8.39" (213 mm) |
| Depth | 1.54" (39 mm) |
| Weight (Approximate) | 2.43 lb (1100 g) |
| Miscellaneous | |
| Package Contents | SonicWave 681 Wireless Access Point Ceiling Mounting Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
User Manual
FAQ
What Wi-Fi generation does the SonicWave 681 support?
The SonicWave 681 supports Wi-Fi 6 (802.11ax), the latest generation of wireless technology. This provides significant improvements over previous standards, including higher data rates, increased network capacity, reduced latency, and better power efficiency for connected devices through features like Target Wake Time (TWT).
Does this access point support Power over Ethernet (PoE)?
Yes, the SonicWave 681 includes a PoE PD (Power over Ethernet Powered Device) port. This allows the access point to receive both data and electrical power through a single Ethernet cable, simplifying installation by eliminating the need for a separate power outlet near the mounting location.
How many antennas does the SonicWave 681 have and are they internal or external?
The SonicWave 681 features 12 internal antennas. All antennas are integrated within the access point's housing, providing a clean aesthetic for ceiling installations while still delivering strong wireless performance through advanced antenna design and beamforming technology.
What mounting options are available for this access point?
The SonicWave 681 is designed specifically for ceiling mounting and includes a complete ceiling mounting kit in the package. Its form factor and included hardware make it ideal for installation in drop ceilings or directly mounted to ceiling surfaces in commercial and enterprise environments.
What security features does the SonicWave 681 offer?
The SonicWave 681 provides comprehensive wireless security including WPA3, WPA2, AES, and WPA2-ENT encryption standards. It also features Wireless Intrusion Detection System (WIDS) and Wireless Intrusion Prevention System (WIPS) capabilities for detecting and remediating threats, along with rogue access point and device detection to maintain network integrity.
What type of Ethernet connectivity does this access point support?
The SonicWave 681 supports multiple Ethernet technologies including 5 Gigabit Ethernet, Gigabit Ethernet, and Fast Ethernet through its single RJ-45 network port. This flexibility allows it to integrate with various network infrastructure setups while providing high-speed uplink connectivity to support its Wi-Fi 6 capabilities.
