SonicWall 03-SSC-0462 SonicWave 681 Wi-Fi 6 Dual-Band Indoor Access Point - 12 Internal Antennas - MU-MIMO - PoE - Ceiling Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The SonicWave 681 operates on Wi-Fi 6 technology, which introduces efficiencies like Target Wake Time (TWT) for better power management on client devices and Orthogonal Frequency-Division Multiple Access (OFDMA) to reduce latency and increase throughput in congested networks. Its 12 internal antennas are arranged to support Multi-User MIMO, allowing simultaneous data streams to multiple devices, while beamforming focuses signal strength toward connected clients for more reliable performance.
Network connectivity is anchored by a single RJ-45 port that supports 5 Gigabit Ethernet, Gigabit Ethernet, and Fast Ethernet speeds, with PoE PD capability for streamlined power delivery. The integrated USB 3.0 port enables connections to external storage or peripherals, and a separate management port offers out-of-band administration. Power consumption is rated at 34 watts under typical operation.
Relevant factors for this section include Wireless LAN Standard, Bluetooth Standard, Network Band, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The SonicWave 681 combines advanced radio design with enterprise-grade security and management features to address the demands of high-density wireless deployments. Its Wi-Fi 6 foundation ensures compatibility with the latest client devices while improving network efficiency and user experience.
Enhanced Performance
Twelve internal antennas with MU-MIMO and beamforming deliver strong, consistent coverage and support multiple concurrent data streams, reducing bottlenecks in busy environments.
- Increased throughput
- Reduced latency
- Better client density handling
Robust Security
Integrated WIDS and WIPS provide threat detection and active remediation, while WPA3 encryption and RADIUS authentication protect network integrity and user data.
- WPA3/WPA2-ENT encryption
- Rogue AP and device detection
- RADIUS and SSL support
Simplified Deployment
Ceiling-mountable form factor and PoE support allow for flexible placement and easier installation without separate power outlets, reducing cabling complexity and setup time.
- Ceiling mountable
- PoE powered
- Single-cable installation
Deployment / Use Cases
The SonicWave 681 is suited for indoor environments where reliable, high-performance Wi-Fi is critical. Its ceiling-mount design and PoE capability make it ideal for offices, classrooms, retail spaces, and healthcare facilities where aesthetics and installation flexibility are important.
In enterprise settings, this access point supports dense device deployments with its Wi-Fi 6 efficiencies, handling numerous concurrent connections from laptops, smartphones, IoT devices, and video conferencing systems. The integrated security features, including rogue AP detection and WIPS, make it a fit for organizations with strict compliance or data protection requirements.
Office and Corporate Networks
Provides stable connectivity for employee devices, video meetings, and cloud applications, with security protocols to safeguard corporate data.
Education and Campus Environments
Supports high-density student and faculty device usage in classrooms and common areas, with management tools for IT oversight.
Physical Profile
The SonicWave 681 features a compact, low-profile design optimized for ceiling mounting. Its dimensions are 8.39 inches in height and width, with a depth of 1.54 inches, allowing for discreet installation in drop ceilings or surface mounts. The unit weighs approximately 2.43 pounds, and its internal antenna design eliminates external protrusions for a clean, professional appearance. The form factor is specifically engineered for indoor use, with materials compliant with RoHS and WEEE environmental standards.
- Width
- 8.39" (213 mm)
- Depth
- 1.54" (39 mm)
- Height
- 8.39" (213 mm)
- Weight
- 2.43 lb (1100 g)
What's in the Box
The package includes the SonicWave 681 wireless access point and a ceiling mounting kit, providing all necessary hardware for installation.
Highlights
- Wi-Fi 6 (802.11ax) for improved efficiency and throughput
- Dual-band operation on 2.4 GHz and 5 GHz frequencies
- 12 internal antennas with MU-MIMO and beamforming
- Power over Ethernet (PoE) support for simplified installation
- WPA3, WPA2-ENT, AES encryption for robust security
- Ceiling-mountable form factor for discreet placement
- USB 3.0 port for peripheral expansion
- RADIUS and SSL communication protocols
- TAA compliant and RoHS/WEEE environmental compliance
- Includes ceiling mounting kit in the package
Specifications
| Specifications | |
|---|---|
| Manufacturer | SonicWall Inc. |
| Manufacturer Part Number | 03-SSC-0462 |
| Brand Name | SonicWall |
| Product Line | SonicWave |
| Product Series | 600 |
| Product Model | 681 |
| Product Name | SonicWave 681 Wireless Access Point |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11 a/b/g/n/ac/ax |
| Bluetooth Standard | Bluetooth 5 |
| Network Band | Dual Band |
| Frequency Band | 2.40 GHz,5 GHz |
| Total Number of Antennas | 12 |
| Number of Internal Antennas | 12 |
| Indoor/Outdoor | Indoor |
| MIMO Technology | Yes |
| MIMO Type | Multi User MIMO |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WPA3,WPA2,AES,WPA2-ENT |
| Interfaces/Ports | |
| Ethernet Technology | 5 Gigabit Ethernet,Gigabit Ethernet,Fast Ethernet |
| Number of Network (RJ-45) Ports | 1 |
| PoE PD Port | Yes |
| USB | Yes |
| USB Standard | USB 3.0 |
| Management Port | Yes |
| Network & Communication | |
| Wi-Fi Generation | Wi-Fi 6 |
| Communication Protocols | RADIUS,SSL |
| Power Description | |
| Power Consumption | 34 W |
| Physical Characteristics | |
| Form Factor | Ceiling Mountable |
| Antenna Form Factor | Internal |
| Height | 8.39" (213 mm) |
| Width | 8.39" (213 mm) |
| Depth | 1.54" (39 mm) |
| Weight (Approximate) | 2.43 lb (1100 g) |
| Miscellaneous | |
| Package Contents | SonicWave 681 Wireless Access Point Ceiling Mounting Kit |
| Environmentally Friendly | Yes |
| Environmental Compliance | China Restriction of Hazardous Substances (China RoHS),Restriction of Hazardous Substances (RoHS),Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | Taiwan |
| TAA Compliant | Yes |
User Manual
FAQ
What Wi-Fi standards does the SonicWave 681 support?
The SonicWave 681 supports Wi-Fi 6 (IEEE 802.11ax) along with backward compatibility to earlier standards including 802.11a, b, g, n, and ac. This ensures it works with both modern Wi-Fi 6 devices and legacy clients, providing a versatile solution for mixed-device environments.
Does this access point support Power over Ethernet?
Yes, the SonicWave 681 includes a PoE PD (Power over Ethernet Powered Device) port. This allows it to receive both data and electrical power over a single Ethernet cable, simplifying installation by eliminating the need for a separate power outlet near the mounting location.
How many antennas does the SonicWave 681 have, and are they internal or external?
This access point features 12 internal antennas. The internal design provides a clean, low-profile appearance without external antenna protrusions, making it suitable for ceiling-mounted installations where aesthetics are important. The antennas support Multi-User MIMO for efficient multi-device communication.
What security features are included with this wireless access point?
Security features include WPA3 and WPA2-ENT encryption, AES support, RADIUS authentication, and SSL communication protocols. It also incorporates Wireless Intrusion Detection System (WIDS) and Wireless Intrusion Prevention System (WIPS) capabilities for threat detection and active remediation, along with rogue access point and device detection.
Is the SonicWave 681 designed for indoor or outdoor use?
The SonicWave 681 is an indoor wireless access point. It is not rated for outdoor environments. Its form factor is ceiling mountable, making it ideal for installation inside offices, schools, retail spaces, and other indoor facilities where protection from weather elements is not required.
What is included in the package with the SonicWave 681?
The package contains the SonicWave 681 wireless access point itself and a ceiling mounting kit. The mounting kit includes the necessary hardware for installing the access point on a ceiling, providing a complete solution for deployment without requiring additional purchase of mounting components.
