Ubiquiti UAP-BeaconHD-US UniFi AP Beacon HD 802.11ac Wireless Access Point - 1.69 Gbit/s - Dual-Band - Wall Mountable
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
This access point operates on the IEEE 802.11ac standard, providing wireless transmission speeds up to 1.69 Gbit/s across both 2.40 GHz and 5 GHz frequency bands. It incorporates MIMO technology to enhance signal reliability and beamforming to direct Wi-Fi signals toward connected devices, improving overall network performance.
The integrated Gigabit Ethernet port ensures high-speed wired connectivity for backhaul or device connections, while robust encryption standards including WEP, WPA-PSK, WPA-ENT, WPA, WPA2, TKIP, and AES safeguard network data. With a power draw of 11.50 W, it balances performance with energy efficiency.
Relevant factors for this section include Wireless LAN Standard, Frequency Band, Wireless Transmission Speed, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The UniFi AP Beacon HD stands out for its ability to deliver high-density Wi-Fi coverage in a discreet, easy-to-install package. Its integration with the UniFi Controller software allows for centralized management, monitoring, and configuration of multiple access points from a single interface.
Enhanced Coverage
Extends Wi-Fi reach into areas with weak signals, using mesh technology to create a unified network without additional wiring.
- Eliminates dead zones
- Seamless roaming between access points
Advanced Wireless Features
Leverages 802.11ac with MIMO and beamforming to maximize throughput and signal stability for bandwidth-intensive tasks.
- Optimized for HD media and gaming
- Reduces interference and lag
Simplified Deployment
Wall-mountable design and low power requirements enable quick installation in offices, homes, or retail spaces.
- Minimal footprint
- Energy-efficient operation
Deployment / Use Cases
Ideal for expanding wireless networks in environments where running Ethernet cables is impractical or costly, the AP Beacon HD serves as a versatile mesh point. It is commonly deployed in multi-story buildings, large homes, offices with thick walls, or outdoor areas requiring extended coverage.
Use cases include supplementing existing UniFi networks to improve signal strength in remote rooms, providing reliable Wi-Fi for smart home devices, and ensuring consistent connectivity in small business settings. Its compact size allows for discreet placement on walls or ceilings, blending into various decors while maintaining professional-grade performance.
Relevant factors for this section include Wireless LAN Standard, Frequency Band, Wireless Transmission Speed, Ethernet Technology. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Physical Profile
Measuring 6.68 inches in height, 4.42 inches in width, and 1.27 inches in depth, the AP Beacon HD features a slim, wall-mountable enclosure that minimizes visual clutter. Weighing approximately 260 grams, it is lightweight yet durable, suitable for indoor installations in diverse environments. The design supports easy mounting with standard hardware, facilitating flexible placement to optimize signal propagation.
The physical profile is practical for deployment planning because the dimensions and weight are clearly defined: 6.68" (169.70 mm), 4.42" (112.15 mm), 1.27" (32.20 mm), 260 g. This helps confirm rack, shelf, desk, or cabinet fit before installation.
- Width
- 4.42" (112.15 mm)
- Depth
- 1.27" (32.20 mm)
- Height
- 6.68" (169.70 mm)
- Weight
- 260 g
Highlights
- IEEE 802.11ac Wi-Fi standard with dual-band 2.40 GHz and 5 GHz operation
- Wireless transmission speed up to 1.69 Gbit/s for high-density applications
- MIMO and beamforming technologies enhance signal reliability and coverage
- Gigabit Ethernet port for high-speed wired connectivity
- Wall-mountable form factor for flexible, discreet installation
- Low power consumption at 11.50 W for energy-efficient operation
- Supports WEP, WPA-PSK, WPA-ENT, WPA, WPA2, TKIP, and AES encryption
- Compact dimensions: 6.68" H x 4.42" W x 1.27" D (169.70 mm x 112.15 mm x 32.20 mm)
- Lightweight design at approximately 260 grams
- Complies with Waste Electrical and Electronic Equipment Directive (WEEE)
Specifications
| Specifications | |
|---|---|
| Manufacturer | Ubiquiti Inc. |
| Manufacturer Part Number | UAP-BeaconHD-US |
| Brand Name | Ubiquiti |
| Product Line | UniFi AP Beacon HD |
| Product Model | UAP-BeaconHD |
| Product Name | UniFi AP Beacon HD Wi-Fi Meshpoint |
| Product Type | Wireless Access Point |
| Technical Information | |
| Wireless LAN Standard | IEEE 802.11ac |
| Frequency Band | 2.40 GHz,5 GHz |
| Wireless Transmission Speed | 1.69 Gbit/s |
| MIMO Technology | Yes |
| Beamforming Technology | Yes |
| Data Encryption | Yes |
| Encryption Standard | WEP,WPA-PSK,WPA-ENT,WPA,WPA2,TKIP,AES |
| Interfaces/Ports | |
| Ethernet Technology | Gigabit Ethernet |
| Power Description | |
| Power Consumption | 11.50 W |
| Physical Characteristics | |
| Form Factor | Wall Mountable |
| Height | 6.68" (169.70 mm) |
| Width | 4.42" (112.15 mm) |
| Depth | 1.27" (32.20 mm) |
| Weight (Approximate) | 260 g |
| Miscellaneous | |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Country of Origin | China |
User Manual
FAQ
What Wi-Fi standard does the Ubiquiti UniFi AP Beacon HD support?
The AP Beacon HD supports the IEEE 802.11ac Wi-Fi standard, which provides faster speeds and improved performance over previous generations like 802.11n. This standard operates on both 2.40 GHz and 5 GHz frequency bands, offering flexibility for different device connections and reducing network congestion in busy environments.
What is the maximum wireless throughput of this access point?
This access point delivers a maximum wireless transmission speed of 1.69 Gbit/s. This high throughput supports bandwidth-intensive activities such as streaming HD video, online gaming, and large file transfers, ensuring a smooth and responsive network experience for multiple connected devices simultaneously.
Does the AP Beacon HD support Power over Ethernet (PoE)?
The product specifications do not indicate support for Power over Ethernet. It features a Gigabit Ethernet port for data connectivity and requires separate power input, with a power consumption of 11.50 W. Users should verify power requirements based on their specific installation setup.
How is this access point mounted for installation?
The AP Beacon HD is designed as a wall-mountable access point. Its compact form factor allows for easy installation on walls or ceilings using standard mounting hardware, making it suitable for discreet placement in offices, homes, or commercial spaces to extend Wi-Fi coverage without occupying desk space.
What encryption standards are supported for network security?
This access point supports multiple encryption standards to secure wireless networks, including WEP, WPA-PSK, WPA-ENT, WPA, WPA2, TKIP, and AES. These options provide robust protection against unauthorized access, ensuring data privacy and compliance with security best practices for both personal and business use.
Can the AP Beacon HD be used as a standalone access point or does it require a UniFi controller?
While it can function as a standalone access point for basic Wi-Fi extension, it is optimized for integration with the UniFi ecosystem. Using a UniFi controller software allows for advanced features like centralized management, network monitoring, and seamless roaming across multiple access points, enhancing overall network performance and ease of administration.
