USRobotics USR3513 Courier M2M 4G LTE CAT 1 Cellular Gateway - DIN Rail Mountable - 1 SIM - Fast Ethernet - VPN
Business volume discounts
Technical guidance
Preparation & staging
QC · ON · AB · BC
Product Features
Technical Overview
The USR3513 delivers 4G LTE CAT 1 cellular connectivity, supporting data technologies like HSDPA, HSUPA, and LTE for efficient upstream and downstream communication. It features one network (RJ-45) port and one broadband (RJ-45) port, both utilizing Fast Ethernet technology to facilitate wired LAN and WAN connections.
Security is enhanced through VPN support and username/password-based management mechanisms. The device includes two external 0db SMA penta-band antennas to optimize signal reception, and its concealed SIM slot helps prevent unauthorized removal, adding an extra layer of physical security.
Relevant factors for this section include Broadband Transmission Technology, Cellular Generation, Cellular Network Supported, Number of Network (RJ-45) Ports. When those points are considered together, they give buyers a clearer picture of how the product is equipped, how it fits into deployment, and what kind of day-to-day role it is meant to support.
Key Product Advantages
The Courier M2M gateway stands out with its rugged steel housing and DIN rail mountable design, making it suitable for harsh conditions and easy integration into industrial control panels or small IT closets. Its compact footprint and versatile mounting options increase stability and security in space-constrained environments.
Reliable Connectivity
Built-in persistent cellular and Ethernet connectivity ensures uninterrupted remote management, critical for applications like medical safety compliance or off-site monitoring.
- Supports multiple LTE and WCDMA bands
- Fast Ethernet for wired backup
User-Friendly Management
A graphical user interface (GUI) simplifies configuration of SIMs, firewalls, port filtering, and status monitoring, allowing quick carrier changes in under a minute.
- Easy SIM and network configuration
- Real-time status monitoring
Deployment / Use Cases
This cellular gateway is ideal for remote management solutions where reliable connectivity is paramount. Its design supports deployments in branch offices, small off-site locations, or industrial settings that require durable, low-maintenance networking equipment.
Common use cases include remote monitoring of equipment, M2M communication for IoT devices, backup internet for retail sites, and connectivity in areas with limited wired infrastructure. The DIN rail mounting facilitates installation in electrical cabinets, while the rugged housing withstands demanding environments.
Industrial Automation
Deploy in manufacturing or utility sites for secure, persistent connectivity to control systems and sensors, leveraging cellular networks to avoid wired limitations.
Remote Office Backup
Provide failover internet access for small offices or retail locations, ensuring business continuity during primary connection outages with easy carrier switching.
Physical Profile
The USR3513 features a compact, DIN rail mountable form factor with dimensions of 1.04" (26.50 mm) in height, 5.86" (148.80 mm) in width, and 4.46" (113.30 mm) in depth. Weighing approximately 15.17 oz (430 g), its small footprint and lightweight design make it easy to install in tight spaces like control panels or network racks. The rugged steel housing ensures durability in harsh conditions, while the concealed SIM slot adds physical security against tampering.
- Width
- 5.86" (148.80 mm)
- Depth
- 4.46" (113.30 mm)
- Height
- 1.04" (26.50 mm)
- Weight
- 15.17 oz (430 g)
What's in the Box
The package includes all necessary components for quick setup and operation.
Highlights
- 4G LTE CAT 1 cellular gateway with Fast Ethernet for reliable remote connectivity
- Supports LTE 1900, LTE 1700, LTE 850, LTE 700, WCDMA 1900, and WCDMA 850 bands
- DIN rail mountable design with rugged steel housing for harsh environments
- Single SIM slot with concealed design to prevent unauthorized removal
- VPN support and username/password security for protected management
- Two external 0db SMA penta-band antennas for optimized signal reception
- User-friendly GUI for configuring SIMs, firewalls, port filtering, and monitoring
- Compact size ideal for branch offices or small off-site locations
- Includes Ethernet cable, power supply, and quick start guide for easy setup
- Backed by a 2-year limited warranty and RoHS compliance
Specifications
| Specifications | |
|---|---|
| Manufacturer | U.S. Robotics |
| Manufacturer Part Number | USR3513 |
| Brand Name | USRobotics |
| Product Line | Courier |
| Product Model | USR3513 |
| Product Name | Courier M2M 4G LTE CAT 1 Cellular Gateway |
| Product Type | Modem/Wireless Router |
| Wireless Specifications | |
| Broadband Transmission Technology | Cellular,Ethernet |
| Cellular Generation | 4G |
| Cellular Network Supported | LTE 1900,LTE 1700,LTE 850,LTE 700,WCDMA 1900,WCDMA 850 |
| Cellular Data Connectivity Technology | HSDPA,HSUPA,LTE |
| Number of External Antennas | 2 |
| Interfaces/Ports | |
| Number of Network (RJ-45) Ports | 1 |
| Number of Broadband (RJ-45) Ports | 1 |
| Network & Communication | |
| Ethernet Technology | Fast Ethernet |
| VPN Supported | Yes |
| Multi-SIM Supported | No |
| Number of SIM Card Supported | 1 |
| Physical Characteristics | |
| Form Factor | DIN Rail Mountable |
| Height | 1.04" (26.50 mm) |
| Width | 5.86" (148.80 mm) |
| Depth | 4.46" (113.30 mm) |
| Weight (Approximate) | 15.17 oz (430 g) |
| Miscellaneous | |
| Package Contents | Courier M2M 4G LTE CAT 1 Cellular Gateway 2 x 0db SMA Penta-band Antennas Ethernet Cable US Power Supply Quick Start Guide |
| Environmentally Friendly | Yes |
| Environmental Compliance | Restriction of Hazardous Substances (RoHS) |
| Country of Origin | Taiwan |
| Warranty | |
| Limited Warranty | 2 Year |
User Manual
FAQ
What cellular networks does the USR3513 support?
The USR3513 supports a range of 4G LTE and WCDMA networks, including LTE 1900, LTE 1700, LTE 850, LTE 700, WCDMA 1900, and WCDMA 850. This multi-band compatibility ensures reliable connectivity across various cellular providers and regions, making it suitable for deployments in diverse geographic areas.
How many SIM cards can this gateway accommodate?
This gateway supports a single SIM card. It does not offer multi-SIM functionality, but the concealed SIM slot design helps secure the SIM against unauthorized removal, which is beneficial for remote or unsupervised installations where physical tampering might be a concern.
What are the mounting options for the USR3513?
The USR3513 is designed for DIN rail mounting, allowing easy installation in industrial control panels, electrical cabinets, or network racks. This form factor provides stability and security in space-constrained environments, and its compact dimensions make it ideal for integration into existing infrastructure without requiring additional shelving or brackets.
Does this device support VPN for secure connections?
Yes, the USR3513 supports VPN (Virtual Private Network) functionality. This enables secure, encrypted connections over cellular or Ethernet networks, protecting data transmission for remote management applications. Combined with username and password-based security mechanisms, it helps safeguard all management functions against unauthorized access.
What is included in the package with the USR3513?
The package includes the Courier M2M 4G LTE CAT 1 Cellular Gateway unit, two 0db SMA penta-band antennas, an Ethernet cable, a US power supply, and a quick start guide. These components provide everything needed for initial setup and operation, ensuring a straightforward installation process out of the box.
What warranty comes with the USRobotics USR3513?
The USR3513 is backed by a 2-year limited warranty from the manufacturer. This warranty covers defects in materials and workmanship under normal use, providing peace of mind for long-term deployments. The device is also RoHS compliant, meeting environmental standards for hazardous substance restrictions.
