- Next-generation KVM extension and matrix switching simplifies access to both physical and virtual servers
- Visually lossless full HD DVI video up to 1920x1200
- Low IP bandwidth requirements with less than 40-Mbps required for 1080p video
- Supports USB HID, transparent USB 2.0 and audio
- Manage bandwidth and user access, deploy new endpoints, update firmware and more from the receiver's OSD
Marketing Information: High-performance KVM
Emerald SE provides users with a seamless desktop experience anywhere on a TCP/IP network while allowing the actual hardware to be housed in a corporate data center or in the cloud. The performance of Emerald SE allows easy deployment on standard corporate networks and even across WANs. The solution enables the same experience of a desktop PC even for media-rich applications, like video and photo editing.
Emerald SE provides Full HD DVI-D with resolutions up to 1920 x 1200, transparent USB and bi-directional analog audio. Link them in a point-to-point KVM extension over CATx up to 328 ft./100 m or even further using an IP or WAN connection. Or Connect multiple transmitters and receivers to an Emerald or IP switch to create a matrix switching setup.
Virtualization support
Emerald SE simplifies access to both physical and virtual servers with high-performance connectivity to virtual machines, supporting VMware®, Microsoft® HyperV®, and Citrix®, using RDP 8.1/RemoteFX.
Limitless scaling
Your Emerald KVM network may start small, but scalable to meet your future needs just by adding endpoints. Connect up to 32 endpoints, no additional KVM management appliance, cards or chassis required. For larger deployments, use our Boxilla KVM management solution.
A welcome addition to the Emerald product family
Emerald SE works seamlessly with the rest of the Emerald product family and these popular Black Box KVM product families:
- DKM proprietary, direct-connect KVM system
- Freedom II Multi-Monitor Switch with Glide-and-Switch technology
- ControlBridge our system for one-touch, multisystem control
- Boxilla KVM manager
Connectivity Technology: WiredNumber of Computers Supported: 1Maximum Operating Distance: 328 ft (99974.40 mm)Device Type: KVM ExtenderGraphic Mode: WUXGAMaximum Video Resolution: 1920 x 1200Network (RJ-45): YesUSB: YesDVI: YesHeadphone: YesMicrophone: YesNumber of Network (RJ-45) Ports: 1Number of USB Ports: 4Number of DVI Ports: 2Input Voltage: Input Voltage Range: 100V AC to 240V ACPower Consumption: 6.50 WReceiver Height: 1.15" (29.21 mm)Receiver Width: 6.20" (157.48 mm)Receiver Depth: 4.20" (106.68 mm)Receiver Weight (Approximate): 616.9 gPackage Contents: - Emerald SE KVM-over-IP - DVI-D, USB 2.0, Audio, RJ45
- 1 x 5VDC Power Supply with Power Cord
Platform Supported: Environmentally Friendly: YesCountry of Origin: IrelandLimited Warranty: 2 Year
[custom-specifications]
SpecificationsManufacturer: Black Box Corporation
Manufacturer Part Number: EMD2002SE-R
Manufacturer Website Address: http://www.blackbox.com
Brand Name: Black Box
Product Line: Emerald SE
Product Model: EMD2002SE-R
Product Name: Emerald SE KVM-over-IP - DVI-D, USB 2.0, Audio, RJ45
Packaged Quantity: 1
Product Type: KVM Extender Receiver
Technical InformationConnectivity Technology: Wired
Number of Computers Supported: 1
Maximum Operating Distance: 328 ft (99974.40 mm)
Device Type: KVM Extender
VideoGraphic Mode: WUXGA
Maximum Video Resolution: 1920 x 1200
Interfaces/PortsNetwork (RJ-45): Yes
USB: Yes
DVI: Yes
Headphone: Yes
Microphone: Yes
Number of Network (RJ-45) Ports: 1
Number of USB Ports: 4
Number of DVI Ports: 2
Power DescriptionInput Voltage:
Input Voltage Range: 100V AC to 240V AC
Power Consumption: 6.50 W
Physical CharacteristicsReceiver Height: 1.15" (29.21 mm)
Receiver Width: 6.20" (157.48 mm)
Receiver Depth: 4.20" (106.68 mm)
Receiver Weight (Approximate): 616.9 g
MiscellaneousPackage Contents:
- Emerald SE KVM-over-IP - DVI-D, USB 2.0, Audio, RJ45
- 1 x 5VDC Power Supply with Power Cord
Platform Supported:
Environmentally Friendly: Yes
Country of Origin: Ireland
WarrantyLimited Warranty: 2 Year
