Middle Atlantic Forward FWD-LT-UTL-24-27-D Rack Light - 0.94" (24 mm) Width - 9 W LED Bulb - IR Sensor, Dimmable, Automatic On/Off - - (FWD-LT-UTL-24-27-D)

Marketing Information:

Forward Family Utility Lighting shall be Middle Atlantic Products model # FWD-LT-UTL-__-__-D (refer to chart). FWD-LT-UTL shall have an overall height of __ (refer to chart.) FWD-LT-UTL shall have a light temperature of 4,000K, and provide __lm (refer to chart). FWD-LT-UTL shall have a 1 rackspace
IR/dimming module that allows for brightness setting and automatic on/off when door is opened. FWD-LT-UTL shall include 2 lights that mount to the rack side and are angled 45°. FWD-LT-UTL shall have a 110V UL Listed power supply with an output of 24VDC, 2 Amps. FWD-LT-UTL shall have an input volt-age range of 100VAC to 240VAC, an input frequency range of 50/60Hz, and a max AC current draw of 1.6A AC. FWD-LT-UTL shall be warrantied to be free from defects in materials and workmanship under normal use and conditions for a period of 3 years. FWD-LT-UTL shall be UL Listed and CE Marked.

Bulb/Tube Type: LED

Maximum Bulb/Tube Power: 9 W

Light Color: Bright White

Light Output: 1710 lm

Mount Type: Rail-mountable

Application/Usage: Rack

Switch Type: Touch Sensor,On/Off

Features: IR Sensor,Dimmable,Automatic On/Off

Power Source: Electric

Input Voltage: 230 V AC

Power Consumption: 9 W

Width: 0.94" (24 mm)

Depth: 0.39" (10 mm)

Package Contents:

• Forward FWD-LT-UTL-24-27-D Rack Light
• IR sensor for automatic on/off with the door
• Dimmer
• UP1 panel to mount IR/Dimming module on the rackrail
• All hardware for mounting in any other Middle Atlantic enclosure

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 3 Year
