Seagate Exos X22 ST20000NM004E 20 TB Hard Drive - Internal - SATA (SATA/600) - Conventional Magnetic Recording (CMR) Method - Storage (ST20000NM004E)

Marketing Information:

Powerful performance with proven technology-Seagate's ® Exos® X22 drives are built off the platform that's shipped millions globally and deployed in leading cloud service provider solutions-making them the most sought-after drives in our datasphere. Designed with the highest rack-space efficiency and protected with Seagate Secure™, Exos X22 offers extreme market-leading capacity, earning customer confidence by delivering trusted peace of mind.

Maximum Storage Capacity for Highest Rack Space Efficiency

Market-leading 22TB HDD offering the highest capacity available for more petabytes per rack

Highly reliable performance with enhanced caching-making it the logical choice for cloud data center and massive scale-out data center applications

Hyperscale SATA model tuned for large data transfers and low latency

PowerBalance™ feature optimizes watts per TB

Maximize total cost of ownership savings through lower power and weight with helium-sealed drive design

Proven helium side-sealing weld technology for added handling, robustness, and leak protection

Digital environmental sensors to monitor internal drive conditions for optimal operation and performance

Data protection and security-featuring Seagate Secure for safe, affordable, fast, and easy drive retirement

Proven enterprise-class reliability backed by a 5-year limited warranty and 2.5M-hr MTBF rating

Storage Capacity: 20 TB

Disk Format: 512e/4Kn

Recording Technology: Conventional Magnetic Recording (CMR)

Random 4KB Read: 168IOPS

Random 4KB Write: 550IOPS

Spindle Speed (rpm): 7200

Buffer: 512 MB

Drive Interface: SATA

Drive Interface Standard: SATA/600

Drive Type: Internal

Hot Pluggable: Yes

Height: 1.03" (26.11 mm)

Width: 4.01" (101.85 mm)

Depth: 5.79" (147 mm)

Weight (Approximate): 679.9 g

Device Supported: Storage Array

Limited Warranty: 5 Year
