TP-Link ER7406 Omada Gigabit Rackmount/Desktop VPN Gateway - 5 Port - 1000Base-T, 1000Base-F - Gigabit Ethernet - SHA-1, SHA-256, AES (ER7406)
Write a Review
TP-LINK
TP-Link ER7406 Omada Gigabit Rackmount/Desktop VPN Gateway - 5 Port - 1000Base-T, 1000Base-F - Gigabit Ethernet - SHA-1, SHA-256, AES (ER7406)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
Marketing Information:
Omada Solution
? Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network-all controlled from a single interface.
Encryption Standard: SHA-1,SHA-256,SHA-384,SHA-512,AES 256-bit,DES,3DES,AES (128-bit),AES (192-bit),MD5,SHA-2 512-bit,SHA-2 384-bit
Data Link Protocols: TCP/IP,HTTP,HTTPS,L2TP,FTP
Connectivity Technology: Wired
Number of Concurrent Sessions (Max): 150000
Processor Manufacturer: ARM
Processor Type: Cortex A53
Processor Core: Dual-core (2 Core)
Total Number of Ports: 5
USB: Yes
Number of Network (RJ-45) Ports: 5
VPN Throughput: 133.01 MB/s
IPS Throughput: 28.63 MB/s
Ethernet Technology: Gigabit Ethernet
Network Standard: 1000Base-T,1000Base-F
Total Number of Expansion Slots: 1.0
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 1
Frequency: 50 Hz,60 Hz
Power Consumption: 4.50 W
Form Factor: Rack-mountable,Desktop
Height: 1.70" (43.18 mm)
Width: 11.60" (294.64 mm)
Depth: 5.50" (139.70 mm)
- Up to 10x faster than the standard Ethernet connectivity and provides high-performance
- Quickly set up a secure network with 5 ports Firewall
- Rack mounting enables you to organize wires & secure cables for professional installation
[custom-specifications]
| Specifications | |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| Manufacturer Part Number | ER7406 |
| Manufacturer Website Address | http://www.tp-link.com |
| Brand Name | TP-Link |
| Product Line | Omada |
| Product Model | ER7406 |
| Product Name | ER7406 Omada Gigabit Rackmount/Desktop VPN Gateway |
| Product Type | Network Security Appliance |
| Technical Information | |
| Encryption Standard | SHA-1,SHA-256,SHA-384,SHA-512,AES 256-bit,DES,3DES,AES (128-bit),AES (192-bit),MD5,SHA-2 512-bit,SHA-2 384-bit |
| Data Link Protocols | TCP/IP,HTTP,HTTPS,L2TP,FTP |
| Connectivity Technology | Wired |
| Number of Concurrent Sessions (Max) | 150000 |
| Processor Manufacturer | ARM |
| Processor Type | Cortex A53 |
| Processor Core | Dual-core (2 Core) |
| Interfaces/Ports | |
| Total Number of Ports | 5 |
| USB | Yes |
| Number of Network (RJ-45) Ports | 5 |
| Media & Performance | |
| VPN Throughput | 133.01 MB/s |
| IPS Throughput | 28.63 MB/s |
| Network & Communication | |
| Ethernet Technology | Gigabit Ethernet |
| Network Standard | 1000Base-T,1000Base-F |
| I/O Expansions | |
| Total Number of Expansion Slots | 1.0 |
| Expansion Slot Type | SFP (mini-GBIC) |
| Number of SFP Slots | 1 |
| Power Description | |
| Frequency | 50 Hz,60 Hz |
| Power Consumption | 4.50 W |
| Physical Characteristics | |
| Form Factor | Rack-mountable,Desktop |
| Height | 1.70" (43.18 mm) |
| Width | 11.60" (294.64 mm) |
| Depth | 5.50" (139.70 mm) |
[/custom-specifications]
[custom-options]
[/custom-options]
[custom-user-manual]
Available Documentation:
Additional-pdf1
Additional-pdf2
Additional-pdf3
[/custom-user-manual]
