- Flexible Full Gigabit 52-Port PoE Configuration - 48× PoE+ (802.3at/af) 10/100/1000 Mbps RJ45 ports providing up to 30W per port and total PoE power budget of 384W, together w/ 4× Gigabit SFP slots for high-speed connections.
- Integrated into Omada SDN - Omada Software Defined Networking platform integrates network devices, including switches, APs & gateways with multiple control options offered - Omada Hardware controller or Software Controller. Standalone Mode also applies.
- Cloud Access - Remote cloud access and Omada app brings centralized cloud management of the whole network at different sites-all controlled from a single interface anywhere, anytime.
- SDN Compatibility - Make sure your devices/controllers are equipped with SDN firmware. (Or upgradable). SDN controllers work only with SDN Access Points, Switches & Gateways. Non-SDN controllers work only with non-SDN APs. Details found on TP-Link website.
- Enhance Network Security - Advanced security features include 802.1Q VLAN, IP-MAC-Port binding, ACL, Port Security, DoS defend, Storm control, DHCP Snooping, 802.1X radius authentication and more.
- L2+ Features - Static Routing helps route internal traffic for more efficient use of network resources.
- Standalone Management - Web, CLI (Console Port, Telnet, SSH), SNMP, RMON, and Dual Image bring powerful management capabilities.
- Limited Lifetime Protection - Backed by our industry-leading limited lifetime protection and free 24/7 technical support, you can work with confidence.
Total Number of Network Ports: 48Network (RJ-45): YesModular: YesPort/Expansion Slot Details: - 48 x Gigabit Ethernet PoE+
- 4 x Gigabit Ethernet Expansion Slot
Media Type Supported: - Optical Fiber
- Twisted Pair
Ethernet Technology: Gigabit EthernetNetwork Technology: - 10/100/1000Base-T
- 1000Base-X
Number of Total Expansion Slots: 4Expansion Slot Type: SFP (mini-GBIC)Number of SFP Slots: 4Layer Supported: 3Networking Standards: - IEEE 802.3af
- IEEE 802.3at
- IEEE 802.1p
- IEEE 802.3ad
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1s
- IEEE 802.3x
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.1ab
Manageable: YesPoE (RJ-45) Port: YesPoE Budget: 384 WPower Source: Power SupplyPower Consumption: 52.50 WForm Factor: Height: 1.70" (43.18 mm)Width: 17.30" (439.42 mm)Depth: 13" (330.20 mm)Package Contents: - JetStream TL-SG3452P Ethernet Switch
- Power Cord
- Quick Installation Guide
- Rackmount Kit
- Rubber Feet
Environmentally Friendly: YesCountry of Origin: ChinaLimited Warranty: 5 Year
[custom-specifications]
SpecificationsManufacturer: TP-LINK Technologies Co., Ltd
Manufacturer Part Number: TL-SG3452P
Manufacturer Website Address: http://www.tp-link.com
Brand Name: TP-Link
Product Line: JetStream
Product Model: TL-SG3452P
Product Name: JetStream TL-SG3452P Ethernet Switch
Product Type: Ethernet Switch
Interfaces/PortsTotal Number of Network Ports: 48
Network (RJ-45): Yes
Modular: Yes
Port/Expansion Slot Details:
- 48 x Gigabit Ethernet PoE+
- 4 x Gigabit Ethernet Expansion Slot
Media & PerformanceMedia Type Supported:
- Optical Fiber
- Twisted Pair
Ethernet Technology: Gigabit Ethernet
Network Technology:
- 10/100/1000Base-T
- 1000Base-X
I/O ExpansionsNumber of Total Expansion Slots: 4
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 4
Network & CommunicationLayer Supported: 3
Networking Standards:
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.1p
- IEEE 802.3ad
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1s
- IEEE 802.3x
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.1ab
Management & ProtocolsManageable: Yes
Power DescriptionPoE (RJ-45) Port: Yes
PoE Budget: 384 W
Power Source: Power Supply
Power Consumption: 52.50 W
Physical CharacteristicsForm Factor:
Height: 1.70" (43.18 mm)
Width: 17.30" (439.42 mm)
Depth: 13" (330.20 mm)
MiscellaneousPackage Contents:
- JetStream TL-SG3452P Ethernet Switch
- Power Cord
- Quick Installation Guide
- Rackmount Kit
- Rubber Feet
Environmentally Friendly: Yes
Country of Origin: China
WarrantyLimited Warranty: 5 Year
