1D LASER, BLUETOOTH, ANDROID, APPLE iOS (OPN2006-00)

Marketing Information:

The OPN-2006 enables real-time barcode scanning into any Bluetooth device. It is extremely small and is lightweight. It comes at an affordable price point that enables any business to integrate barcode scanning into their mobile applications

Connectivity Technology: Cable/Wireless

Scanning Capability: 1D

Barcode Symbology Supported:

1D:

• JAN/UPC/EAn incl. add on, Codabar / nW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAn-128), GS1 DataBar (RSS), IATA, Industrial 2 of 5, ISBN-ISMN-ISSN, Matrix 2 of 5, MSI/Plessey-UK/ Plessey, S-Code, Telepen, Tri-Optic

Postal code:

• Chinese Post, Korean Postal Authority code

Light Source: Laser

Scan Rate: 100 scan/s

Scanning Distance: 25.59" (649.99 mm)

Number of Keys: 2

Cable Type Included: USB

Stand Included: Yes

Reading Angle (Skew): 50°

Reading Angle (Pitch): 35°

Maximum Ambient Light: 80000 lux

Drop Specification:

• 1.5 m / 5 ft drop onto concrete surface

Features: Notification LED,Vibration,Scan Button

Standard Memory: 96 KB

Flash Memory: 512 KB

Bluetooth: Yes

Host Interface: USB

Battery Chemistry: Lithium Polymer (Li-Polymer)

Battery Capacity: 240 mAh

Maximum Battery Run Time: 27 Hour

Operating Temperature: 32°F (0°C) to 104°F (40°C)

Storage Temperature: -4°F (-20°C) to 140°F (60°C)

Humidity (Non-condensing): 20% to 85%

Form Factor: Handheld

Color Family: Black

Product Color: Black

Product Material: Acrylonitrile Butadiene Styrene (ABS)

Height: 2.44" (62 mm)

Width: 1.26" (32 mm)

Depth: 0.63" (16 mm)

Package Contents:

• Companion OPN-2006 Barcode Scanner
• USB Cable
• Stand

Ingress Protection (IP) Rating: IP42

Platform Supported: PC,Android,iOS

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 2 Year
