- With 1000Base-LX technology, enjoy up to 1000Mbps data transfer rate over optical fiber cable
- Up to 10x faster than standard Ethernet connection and provides high-performance
- Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
- With its thicker diameter to carry the light of multiple wavelengths, multi-mode fiber optic cable supports the high bandwidth to carry more information with greater fidelity
Marketing Information: Altronix P1MM module allows for an optical or electrical interface when using a managed switch, unmanaged switch or media converter. This hot-pluggable SFP module can be used with multi-mode optical fiber.
Application/Usage: - Data Networking
- Optical Network
Total Number of Ports: 2Connector Type: LCInterfaces/Ports Details: 2 x LC Duplex 1000Base-LX NetworkMedia Type Supported: Optical FiberFiber Mode Supported: Multi-modeEthernet Technology: Gigabit EthernetNetwork Technology: 1000Base-LXForm Factor: Hot-pluggableHeight: 0.50" (12.70 mm)Width: 0.63" (15.88 mm)Depth: 2.25" (57.15 mm)Weight (Approximate): 2.8 gCompatibility: MSA CompliantCountry of Origin: United StatesEnvironmentally Friendly: Yes
[custom-specifications]
SpecificationsManufacturer: Altronix Corporation
Manufacturer Part Number: P1MM
Manufacturer Website Address: http://www.altronix.com
Brand Name: Altronix
Product Model: P1MM
Product Name: Small Form-Factor Pluggable (SFP) Multi-Mode Transceiver
Product Type: SFP (mini-GBIC)
Technical InformationApplication/Usage:
- Data Networking
- Optical Network
Interfaces/PortsTotal Number of Ports: 2
Connector Type: LC
Interfaces/Ports Details: 2 x LC Duplex 1000Base-LX Network
Media & PerformanceMedia Type Supported: Optical Fiber
Fiber Mode Supported: Multi-mode
Ethernet Technology: Gigabit Ethernet
Network Technology: 1000Base-LX
Physical CharacteristicsForm Factor: Hot-pluggable
Height: 0.50" (12.70 mm)
Width: 0.63" (15.88 mm)
Depth: 2.25" (57.15 mm)
Weight (Approximate): 2.8 g
MiscellaneousCompatibility: MSA Compliant
Country of Origin: United States
Environmentally Friendly: Yes
[/custom-specifications]
