- Works adequately in situations where the supply is prone to sags and surges
- Keep your sensitive devices powered with a backup of up to 5.10 minute at full load
Marketing Information: Intelligent and efficient network power protection from entry level to scaleable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Smart-UPS™ are trusted by millions of IT professionals throughout the world to protect equipment and critical data from costly interruptions by supplying reliable, network-grade power reliably and efficiently. Available in a variety of forms factors and classes (entry level, standard and extended run), there is a model for nearly every application and budget. Standard models are the most popular UPS in the world for business servers, storage and network devices and have long been considered the benchmark for reliability and manageability. Entry level Smart-UPS models are an economical choice for small and medium businesses looking to protect small networking devices, point-of-sale (POS) equipment and entry level servers. The extended run models accept external battery packs for long runtime to power critical servers, security and communication systems through outages that could last hours.
More from the Manufacturer
Plug/Connector Type: NEMA L5-30PReceptacle Type: Receptacle Detail: - 8 x NEMA 5-15R
- 2 x NEMA 5-20R
Number of Battery & Surge Outlets: 10Transfer Time: 10 msApplication/Usage: - Server
- Network Device
- Storage Device
- Switch
- Router
Load Capacity: 2.88 kVA/2.70 kWInput Voltage: 120 V ACInput Voltage Range: 75 V AC - 154 V ACOutput Voltage: 120 V ACWaveform Type: Sine WaveSurge Energy Rating: 530 JBattery Chemistry: Lead AcidBackup/Run Time (Full Load): 5.10 MinuteHot Swappable: YesTypical Battery Recharge Time: 3 HourProduct Color: BlackHeight: 17.13" (435.10 mm)Width: 7.72" (196.09 mm)Depth: 21.42" (544.07 mm)Form Factor: TowerWeight (Approximate): 52.73 kgPackage Contents: - Smart-UPS 3000VA LCD 120V with SmartConnect
- Smart UPS signalling RS-232 cable
- USB cable
Energy Star: YesEnvironmentally Friendly: YesEnvironmental Certification: RoHSLimited Warranty: 3 YearAdditional Warranty Information: 3 years repair or replace (excluding battery) and 2 years for battery, optional on-site warranties available, optional extended warranties available
[custom-specifications]
SpecificationsManufacturer: Schneider Electric SA
Manufacturer Part Number: SMT3000C
Manufacturer Website Address: http://www.schneider-electric.com
Brand Name: APC by Schneider Electric
Product Line: Smart-UPS
Product Model: SMT3000C
Product Name: Smart-UPS 3000VA LCD 120V with SmartConnect
Product Type: Line-interactive UPS
Technical InformationPlug/Connector Type: NEMA L5-30P
Receptacle Type:
Receptacle Detail:
- 8 x NEMA 5-15R
- 2 x NEMA 5-20R
Number of Battery & Surge Outlets: 10
Transfer Time: 10 ms
Application/Usage:
- Server
- Network Device
- Storage Device
- Switch
- Router
Power DescriptionLoad Capacity: 2.88 kVA/2.70 kW
Input Voltage: 120 V AC
Input Voltage Range: 75 V AC - 154 V AC
Output Voltage: 120 V AC
Waveform Type: Sine Wave
Surge Energy Rating: 530 J
Battery InformationBattery Chemistry: Lead Acid
Backup/Run Time (Full Load): 5.10 Minute
Hot Swappable: Yes
Typical Battery Recharge Time: 3 Hour
Physical CharacteristicsProduct Color: Black
Height: 17.13" (435.10 mm)
Width: 7.72" (196.09 mm)
Depth: 21.42" (544.07 mm)
Form Factor: Tower
Weight (Approximate): 52.73 kg
MiscellaneousPackage Contents:
Smart-UPS 3000VA LCD 120V with SmartConnect Smart UPS signalling RS-232 cableUSB cableEnergy Star: Yes
Environmentally Friendly: Yes
Environmental Certification: RoHS
WarrantyLimited Warranty: 3 Year
Additional Warranty Information: 3 years repair or replace (excluding battery) and 2 years for battery, optional on-site warranties available, optional extended warranties available
