Aruba 6000 48G 4SFP Switch - 48 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X - 3 Layer Supported - Modular - (R8N86A#ABA)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
(No reviews)
Write a Review
Write a Review
Aruba
Aruba 6000 48G 4SFP Switch - 48 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 1000Base-X - 3 Layer Supported - Modular - (R8N86A#ABA)
MSRP:
$3,191.38
$3,191.38
$1,078.35
Save:
$2,113.03 (66.21%)
SKU:
R8N86A#ABA
UPC:
190017533834
Availability:
Ready to ship - Stock in Canada
Weight:
10.05 LBS
Shipping:
Calculated at Checkout
- Enterprise-class Layer 2 connectivity with support for ACLs, robust QoS and static routing
- Convenient built-in 1GbE uplinks and up to 370W of Class 4 PoE for support of IoT devices
- Compact and fanless 12 port model for quiet deployment
- Management flexibility with support for Aruba Central, easy-to-use Web GUI, CLI, and Aruba NetEdit
- Simple deployment with Zero Touch Provisioning
- Software defined ready with REST APIs
- Simplify adds, moves and changes with colorless ports
- Marketing Information: The Aruba CX 6000 Switch Series is modern family of entry level access switches ideal for branch offices, midsize businesses, and small enterprises. Optimized for reliable, simple and secure access, the CX 6000 series provides a convenient and cost-effective wired access solution for networks supporting IoT, mobile, and cloud applications.
- Easy access to all network configuration state information
- REST APIs for fine-grained programmability of network tasks
- A micro-services architecture that enables full integration with other workflow systems and services
- All software processes communicate with the database rather than each other, ensuring near real-time state and resiliency
- Up to 104 Gbps in non-blocking bandwidth and up to 77.3 Mpps for forwarding
- 48 x Gigabit Ethernet Network
- 4 x Gigabit Ethernet Expansion Slot
- Optical Fiber
- Twisted Pair
- 10/100/1000Base-T
- 1000Base-X
- IEEE 802.3
- IEEE 802.3ad
- IEEE 802.1s
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1p
- IEEE 802.1ab
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.3ab
- IEEE 802.3az
- Rack-mountable
- Cabinet Mount
- Surface Mount
- Wall Mountable
The CX 6000 series is based on the Aruba ASIC architecture with the programmable AOS-CX operating system used across the entire Aruba CX portfolio for a more consistent, more efficient operator experience. This fully managed series has convenient built-in uplinks with up to 370W of PoE+ to support IoT devices such as security cameras and wireless APs. A compact and fanless model is ideal for use in quiet, small work spaces.
The CX 6000 series is easy to deploy and use with flexible management choices that include Web GUI, CLI, cloudbased and on-premise Aruba Central management, so you can choose the best fit for your business and network environment. Delivering Layer 2 capabilities with enhanced access security, traffic prioritization, and IPv6 support, the CX 6000 also simplifies ownership and brings peace of mind with no switch software licensing and a Limited Lifetime Warranty.
PRODUCT DIFFERENTIATORS | AOS-CX - a modern software system
The Aruba CX 6000 Switch Series is based on AOSCX, a modern, database-driven operating system that is built on a modular Linux architecture. With the CX 6000 series, the benefits of the AOS-CX architecture is extended to small enterprise deployments providing the following unique capabilities:
Based on over 30 years of continuous investment, Aruba's ASICs create the basis for innovative and agile software feature advancements, unparalleled performance and deep visibility. These programmable ASICs are purpose-built to allow for a tighter integration of switch hardware and software within campus and data center architectures to optimize performance and capacity. The Aruba CX 6000 is based on the Aruba ASIC architecture.
Access layer performance
The Aruba CX 6000 Switch Series uses internally developed Aruba ASICs that provide very low latency, increased packet buffering, and adaptive power consumption. Each switch includes the following:
[custom-specifications]
Specifications
Manufacturer: Hewlett Packard Enterprise
Manufacturer Part Number: R8N86A#ABA
Manufacturer Website Address: http://www.hpe.com
Brand Name: Aruba
Product Series: CX 6000
Product Model: 6000 48G 4SFP
Product Name: 6000 48G 4SFP Switch
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 48
Network (RJ-45): Yes
Uplink Port: Yes
Modular: Yes
Port/Expansion Slot Details:
Media & Performance
Media Type Supported:
Ethernet Technology: Gigabit Ethernet
Network Technology:
I/O Expansions
Number of Total Expansion Slots: 4
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 4
Network & Communication
Layer Supported: 3
Networking Standards:
Management & Protocols
Manageable: Yes
Power Description
PoE (RJ-45) Port: No
Power Source: Power Supply
Power Consumption: 44.20 W
Physical Characteristics
Compatible Rack Unit: 1U
Form Factor:
Height: 1.73" (43.94 mm)
Width: 17.40" (441.96 mm)
Depth: 9.74" (247.40 mm)
Weight (Approximate): 3.42 kg
Miscellaneous
Environmentally Friendly: Yes
Warranty
Limited Warranty: Lifetime
Manufacturer: Hewlett Packard Enterprise
Manufacturer Part Number: R8N86A#ABA
Manufacturer Website Address: http://www.hpe.com
Brand Name: Aruba
Product Series: CX 6000
Product Model: 6000 48G 4SFP
Product Name: 6000 48G 4SFP Switch
Product Type: Ethernet Switch
Interfaces/Ports
Total Number of Network Ports: 48
Network (RJ-45): Yes
Uplink Port: Yes
Modular: Yes
Port/Expansion Slot Details:
- 48 x Gigabit Ethernet Network
- 4 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
- Optical Fiber
- Twisted Pair
Ethernet Technology: Gigabit Ethernet
Network Technology:
- 10/100/1000Base-T
- 1000Base-X
I/O Expansions
Number of Total Expansion Slots: 4
Expansion Slot Type: SFP (mini-GBIC)
Number of SFP Slots: 4
Network & Communication
Layer Supported: 3
Networking Standards:
- IEEE 802.3
- IEEE 802.3ad
- IEEE 802.1s
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1p
- IEEE 802.1ab
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.3ab
- IEEE 802.3az
Management & Protocols
Manageable: Yes
Power Description
PoE (RJ-45) Port: No
Power Source: Power Supply
Power Consumption: 44.20 W
Physical Characteristics
Compatible Rack Unit: 1U
Form Factor:
- Rack-mountable
- Cabinet Mount
- Surface Mount
- Wall Mountable
Height: 1.73" (43.94 mm)
Width: 17.40" (441.96 mm)
Depth: 9.74" (247.40 mm)
Weight (Approximate): 3.42 kg
Miscellaneous
Environmentally Friendly: Yes
Warranty
Limited Warranty: Lifetime
[/custom-specifications]
Warranty Infomartion
Lifetime
