Aruba AP-503H Dual Band 802.11ax 1.50 Gbit/s Wireless Access Point - 2.40 GHz, 5 GHz - Internal - MIMO Technology - 3 x Network - - 5 (R7G97A)

Marketing Information: High performance and cost-effective Wi-Fi 6 (802.11ax) for hospitality, branch, and teleworker deployments

These economical Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing mobile, cloud and IoT requirements. With a wireless aggregate data rate of up to 1.5 Gbps and gigabit local wired ports, they deliver the range of connectivity options needed for venues such as hotels, residence halls, and remote offices alike.

INCREDIBLE EFFICIENCY

The 500H Series APs are designed to optimize user experience by maximizing Wi-Fi efficiency and dramatically reducing airtime contention between clients. Features include Orthogonal frequency-division multiple access (OFDMA), multi-user MIMO and cellular optimization. With up to 2 spatial streams (2SS) and 80MHz channel bandwidth, the 500H Series provides groundbreaking wireless capabilities for budget-conscious deployments.

Wireless LAN Standard: 802.11ax

Bluetooth Standard: Bluetooth 5

Network Band: Dual Band

Frequency Band: 2.40 GHz,5 GHz

Total Number of Antennas: 2

Number of Internal Antennas: 2

Wireless Transmission Speed: 1.50 Gbit/s

MIMO Technology: Yes

Beamforming Technology: Yes

Data Encryption: Yes

Encryption Standard: WPA3-ENT,WPA2-MPSK,WPA2-ENT,WPA-ENT

Ethernet Technology: Gigabit Ethernet

Number of Network (RJ-45) Ports: 3

PoE PD Port: Yes

USB: Yes

Management Port: Yes

Form Factor: Wall Mountable,Desktop

Antenna Form Factor: Internal

Height: 5.91" (150 mm)

Width: 3.39" (86 mm)

Depth: 1.57" (40 mm)

Weight (Approximate): 290 g
