AXIOM 100GBS DUAL PORT QSFP28 PCIE 3.0 X16 NIC CARD - MCX456A-ECAT-AX (MCX456A-ECAT-AX)

Marketing Information:

The Axiom QSFP28 PCIe 3.0 x16 100Gbs intelligent network card is designed for Servers and high-end Data Center applications. They provide simple integration into any PCI Express x16 to provide 100 Gigabit Network connectivity. Based on Xilinx Ultrascale+16nm VU3P chip solution, it offers low-latency network processing capability by utilizing the built in auxiliary CPU to perform network functions which results in reduced CPU usage and reduced power consumption in the host system.

Key Features

• P4-enabled with P4 compiler
• P4 featured programmable match-action policies
• Open vSwitch datapath offload
• SR-IOV
• DPDK, zero-copy
• SDN ready as well as supporting legacy network management systems
• High throughput monitoring & data export
• Multi purpose and adaptive fragile service offload & delivery
• Highly Programmable platform in hardware and software
• Includes Full Height and Half Height Mounting Brackets

Chipset Manufacturer: Xilinx

Chipset Model: Ultrascale+16nm VU3P

Features: Single Root I/O Virtualization (SR-IOV),Data Plane Development Kit (DPDK),Extended Message-Signaled Interrupts (MSI-X),VLAN Tagging,RDMA over Converged Ethernet (RoCE),TCP Segmentation Offload (TSO),Large Send Offload (LSO),Large Receive Offload (LRO),Network Virtualization using Generic Routing Encapsulation (NVGRE),PXE Support,UEFI Support

Host Interface: PCI Express 3.0 x16

Total Number of Expansion Slots: 2.0

Expansion Slot Type: QSFP28

Media Type Supported: Optical Fiber

Maximum Data Transfer Rate: 100 Gbit/s

Network Technology: 100GBase-X

Form Factor: Plug-in Card

Bracket Height: Full Height/Half Height

Package Contents:

• 100Gbs PCIe 3.0 x16 Fiber Network Adapter
• Full Height Mounting Bracket
• Half Height Mounting Bracket

Device Supported: Server

Limited Warranty: 3 Year
