AXIS XPQ1785 Outdoor Full HD Network Camera - Color - Turret - Night Vision - Zipstream, H.264, H.264B, H.264M, Motion JPEG, H.264B - (02278-001)

Marketing Information: Ideal for health, safety, environment (HSE) applications within potentially combustible areas, this robust PTZ camera includes early smoke and fire detection analytics. It has worldwide certifications for use in Class I/II/III Division 1 and Zone 1,21.

Protect your personnel and production

Featuring smoke alert analytics, AXIS XPQ1785 serves as an additional layer of safety, monitoring for signs of smoke or fire. If detected, operators are alerted so they can assess the situation to determine appropriate responses. Additionally, it allows you to safeguard the production processes from a distance. This helps ensure that you only send personnel into restricted, potentially combustible environments when necessary.

Total situational awareness

AXIS XPQ1785 offers HDTV 1080p resolution at up to 60 fps. It features 32x optical zoom and a continuous 360° pan and +/- 90° tilt rotation for fast camera repositioning and smooth, continuous tracking of objects. It's got Axis Forensic WDR for clarity even when there are both dark and light areas in the scene. Thanks to Lightfinder, you get sharp, color images in low light. And Axis Zipstream provides exceptional savings on bandwidth and storage requirements without compromising image quality. Plus, electronic image stabilization keeps the picture steady when the camera is exposed to vibrations.

Globally certified and suitable for all environments

AXIS XPQ1785 is a globally certified Class I/II/III Division 1 and Zone 1,21 stainless steel (316L) PTZ camera for use in hazardous areas (according to NEC, CEC, IECEx, ATEX, and more). It can withstand wide temperatures ranging from -60°C to 60°C (-76°F to 140°F). And, it's IP66, IP67, IP68-rated for protection against water and dust ingress. Furthermore, ease of installation is supported by a compact and low-weight design, with both RJ45 and SFP for fiber or coax and 110-240 V AC power input.

HD Recording: Yes

Recording Formats: Full HD

Night Vision: Yes

Image Sensor Type: RGB CMOS

Color Supported: Color

Field of View: Horizontal field of view: 60°-2.3° Vertical field of view: 39°-1.3°

Video Formats: Zipstream,H.264,H.264B,H.264M,Motion JPEG,H.264B (MPEG-4 Part 10/AVC),H.264M (MPEG-4 Part 10/AVC),MJPEG

Maximum Video Resolution: 1920 x 1080

Maximum Frame Rate: 60 fps

Lens Type: Varifocal

Minimum Focal Length: 4.3 mm

Maximum Focal Length: 137 mm

Lens Included: Yes

Minimum Aperture: f/4

Maximum Aperture: f/1.4

Optical Zoom: 32x

Shortest Shutter Speed: 1/66500 Second

Longest Shutter Speed: 1 Second

Connectivity Technology: Wired

Remote Management: Yes

Storage Type: Memory Card

Network (RJ-45): Yes

Power Source Type: AC

Mount Type: Wall Mount,Pole Mount

Form Factor: Turret

Durability: Weather Proof,Explosion Proof

Height: 14.60" (370.84 mm)

Width: 9.40" (238.76 mm)

Depth: 11.90" (302.26 mm)

Weight (Approximate): 23 kg

Minimum Operating Temperature: -76°F (-60°C)

Maximum Operating Temperature: 140°F (60°C)

Maximum Operating Humidity: 100%

Features: PTZ,Smoke Detector,Motion Detection,Wide Dynamic Range,Day/Night,Electronic Image Stabilization,Password Protection,HTTPS Encryption,Defog,White Balance,Cross Line Detection,Video Management System

Indoor/Outdoor: Outdoor

Impact Protection Rating: IK10,IK08

Ingress Protection Rating: IP67,IP66,IP68
