Black Box CCTV Power-Through Balun with RJ-45 Connectors - 2500 ft (762000 mm) Maximum Operating Distance - Network (RJ-45) - TAA (IC560A)

(No reviews) Write a Review
$54.22
$54.22
$45.58
(You save $8.64 )
SKU: IC560A
UPC: 822088100201
Weight: 1.00 LBS

Pre-order! 🗨️📞

  • Replace your bulky coax video cables with lightweight CAT5 cabling.
  • Send video plus remote power.
  • Supports NTSC, PAL, and SECAM video.
  • For color video over CAT5, the balun supports 670.5m distances.
  • Extend your links while using inexpensive UTP cable instead of coax wiring.
    Marketing Information:
    • Supports NTSC, PAL, and SECAM video.
    • For color video over CAT5, the balun supports 2200-foot (670.5-m) distances.

    Running multiple cables for your CCTV cameras and other devices? Extend your links while using inexpensive UTP cable instead of coax wiring with this balun.

    This balun has RJ-45 connectors and transmits video plus power over a single 4-pair CAT3 or CAT5 cable. It supports baseband, NTSC, PAL, or SECAM video at up to 2500 feet (762 m), plus it supports 24-VAC power at up to 518 feet (157.8 m) when using 5 VA.

    The balun works with the CCTV Passive Hubs (IC562A - IC563A).


    Network (RJ-45): Yes
    Number of Network (RJ-45) Ports: 1
    Maximum Operating Distance: 2500 ft (762000 mm)
    Length: 1.87" (47.50 mm)
    Diameter: 1" (25.40 mm)
    Environmentally Friendly: Yes
    Environmental Certification:
    • WEEE
    • RoHS

    Country of Origin: Canada
    TAA Compliant: Yes
    Limited Warranty: 3 Year

[custom-specifications]

Specifications
Manufacturer: Black Box Corporation
Manufacturer Part Number: IC560A
Manufacturer Website Address: http://www.blackbox.com
Brand Name: Black Box
Product Name: CCTV Power-Through Balun with RJ-45 Connectors
Product Type: Video Balun
Interfaces/Ports
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 1
Media & Performance
Maximum Operating Distance: 2500 ft (762000 mm)
Physical Characteristics
Length: 1.87" (47.50 mm)
Diameter: 1" (25.40 mm)
Miscellaneous
Environmentally Friendly: Yes
Environmental Certification:
  • WEEE
  • RoHS

Country of Origin: Canada
TAA Compliant: Yes
Warranty
Limited Warranty: 3 Year

[/custom-specifications]

[custom-user-manual]

User Manual

[/custom-user-manual]
3 Year
