Comnet CNGE2FE8MSPOE+ Ethernet Switch - 8 Ports - Manageable - 2 Layer Supported - Modular - 2 SFP Slots - Twisted Pair, Optical Fiber (CNGE2FE8MSPOE+)

Marketing Information:

The ComNet CNGE2FE8MSPOE+ is a hardened Managed Ethernet Switch. It provides IEEE 802.3at (30W) PoE+ to eight 10/100BASE-T(X) and has twogigabit combination SFP or RJ-45 ports. Up to 240 watts of PoE or PoE+ power is available for distribution across all 8 TX ports. All SFP ports utilize ComNet SFP* modules for fiber and connector type and distance. The CNGE2FE8MSPOE+ is a redundant switch offering multiple Ethernet redundancy protocols, C-Ring (recovery time <10ms over 250 units of connection), ComRing, and MSTP/RSTP/ STP (IEEE 802.1 s/w/D). This redundancy feature protects your applications from network interruptions or temporary malfunctions by redirecting transmission within the network. Network management is supported by eConsole, a powerful, easy-to-use Windows-based utility, as well as Web-based telnet, and Console (CLI) configurations. This environmentally hardened switch is designed for direct deployment in difficult out-of-plant or roadside operating environments

Total Number of Network Ports: 8

Uplink Port: Yes

Modular: Yes

Port/Expansion Slot Details: 8 x Fast Ethernet Network,2 x Gigabit Ethernet Network,2 x Gigabit Ethernet Expansion Slot

Media Type Supported: Twisted Pair,Optical Fiber

Ethernet Technology: Fast Ethernet,Gigabit Ethernet

Network Technology: 100Base-TX,10/100/1000Base-TX,1000Base-X

Total Number of Expansion Slots: 2.0

Expansion Slot Type: SFP

Shared SFP Slot: Yes

Number of SFP Slots: 2

Layer Supported: 2

Manageable: Yes

Height: 5.98" (151.89 mm)

Width: 2.84" (72.14 mm)

Depth: 4.13" (104.90 mm)

Weight (Approximate): 820 g
