CRADLEPOINT NETCLOUD IOT ESS + ADV PLAN AND S700 W WIFI, W AC PWR SPLY 5YR GA (TBA5-0700C4E-GM)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Marketing Information:
The Cradlepoint S700 Series Semi-Ruggedized Router for IoT networks is a semi-ruggedized, cloud-managed LTE router, built for light industrial, IoT, and portable applications where security is a foundational requirement. Offering connectivity through LTE plus wired and Wi-Fi options, the S700 accommodates a variety of use cases in high-availability, portable, or fixed uses. The S700 Series is available with IoT NetCloud Service Plans, which provide features optimized for each unique deployment.
Semi-Ruggedized IoT Solution
When coupled with the NetCloud IoT service plan, the S700 router provides a compact, semi-ruggedized 4G LTE router solution for connecting and protecting IoT devices at scale. With an IP30-rated aluminum housing built to withstand vibration and temperature extremes and designed for DIN rail mounting, the S700 is ideal for use in light industrial applications such as oil and gas monitoring or in portable or fixed applications such as surveillance cameras, digital signs, and parallel networking. With an extensive list of features, it can be confidently deployed in the field, in buildings, or in embedded systems to deliver complete visibility, security, and control of connected devices anywhere.
Advanced, Cloud-Managed IoT Solution
For organizations requiring robust connectivity for IoT networks - with installed routers numbering from hundreds to many thousands - Cradlepoint's NetCloud Service for IoT with the S700 router provides a comprehensive cloud managed network solution. When coupled with advanced IoT features, it provides troubleshooting and diagnostics with in-band and Out-of-Band Management, extensive analytics and insights, and extensibility and integrations such as Microsoft Azure IoT Central. Cradlepoint's NetCloud-managed IoT endpoints can be rapidly deployed and easily scaled to accommodate the diverse requirements of organizations.
Key Software Capabilities
Cradlepoint NetCloud Service for the S700 Series Router includes the appropriate router software with powerful cloud management features for managing IoT at scale. The NetCloud Service includes cloud-based management for optimizing routing, secure tunneling, traffic steering, and foundational security capabilities. The cloud capabilities include defining and applying policies, at-a-glance status insights, reports, troubleshooting, and analytics dashboards. The service includes a warranty for as long as an active IoT Essentials or Essentials + Advanced subscription on the router, online training, live and online support, and all software and firmware updates.
Encrypted Routing Services
The NetCloud Service plus the S700 Series Router provides local processing power to handle demanding, router-delivered services, such as support for VPN tunneling encryption including DMVPN, IPsec, GRE, and other tunneling technologies.
Security Services
Cradlepoint zero trust security networking, delivered through NetCloud Exchange (NCX) Secure Connect, protects the Cradlepoint IoT routers and any connected devices through connect-and-go ease. IoT or other devices simply connect to the router with encrypted tunnels to build micro networks that are instantly hidden from internal and external sites. Access policies are easily defined to enable IoT devices to communicate only with their authorized resources or applications and nothing else. The simple and secure zero trust access, delivered through NCX ZTNA, also enables authorized third parties' remote access to IoT devices on the WAN for remote monitoring and maintenance.
Wi-Fi Generation: Wi-Fi 6
Network Band: Dual Band
Processor Core: Dual-core (2 Core)
Standard Memory: 512 MB
Broadband Transmission Technology: Ethernet
Wireless LAN Standard: IEEE 802.11ax
ISM Band: Yes
UNII Band: Yes
ISM Maximum Frequency: 2.40 GHz
UNII Maximum Frequency: 5 GHz
Cellular Generation: 4G
Cellular Network Supported: LTE 1900,LTE 1700,LTE 850,LTE 700,LTE 600
Cellular Data Connectivity Technology: LTE,WCDMA,UMTS,HSPA+,DC-HSPA+
Total Wireless Transmission Speed: 221.75 MB/s
Total Number of Network Ports: 2
Number of Network (RJ-45) Ports: 1
USB: Yes
Number of Broadband (RJ-45) Ports: 1
Ethernet Technology: Gigabit Ethernet
VPN Supported: Yes
Multi-SIM Supported: Yes
Number of SIM Card Supported: 2
SIM Size Supported: Nano
Flash Memory Capacity: 8 GB
Product Material: Aluminum
Form Factor: Portable
Height: 1.34" (34 mm)
Width: 4.84" (123 mm)
Depth: 4.65" (118 mm)
Weight (Approximate): 516 g
Environmentally Friendly: Yes
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Limited Warranty: Lifetime
- No need to separate hardware from your service provider, enjoy fast Wi-Fi speed and save space
- Gigabit Ethernet port for ultra-fast wired network speeds
- Maximize the throughput for smoother and faster HD video streaming and file transfer by utilizing the ISM Band
- Access USB-compatible peripherals accross the wireless network via built-in USB port
- Portable Design - Enhances your productivity and entertainment while on the move
[custom-specifications]
Specifications | |
Manufacturer | ERICSSON |
Manufacturer Part Number | TBA50700C4EGM |
Manufacturer Website Address | http://www.cradlepoint.com |
Brand Name | CradlePoint |
Product Series | S700 |
Product Name | NetCloud S700 Modem/Wireless Router |
Product Type | Modem/Wireless Router |
Technical Information | |
Wi-Fi Generation | Wi-Fi 6 |
Network Band | Dual Band |
Processor Core | Dual-core (2 Core) |
Standard Memory | 512 MB |
Wireless Specifications | |
Broadband Transmission Technology | Ethernet |
Wireless LAN Standard | IEEE 802.11ax |
ISM Band | Yes |
UNII Band | Yes |
ISM Maximum Frequency | 2.40 GHz |
UNII Maximum Frequency | 5 GHz |
Cellular Generation | 4G |
Cellular Network Supported | LTE 1900,LTE 1700,LTE 850,LTE 700,LTE 600 |
Cellular Data Connectivity Technology | LTE,WCDMA,UMTS,HSPA+,DC-HSPA+ |
Total Wireless Transmission Speed | 221.75 MB/s |
Interfaces/Ports | |
Total Number of Network Ports | 2 |
Number of Network (RJ-45) Ports | 1 |
USB | Yes |
Number of Broadband (RJ-45) Ports | 1 |
Network & Communication | |
Ethernet Technology | Gigabit Ethernet |
VPN Supported | Yes |
Multi-SIM Supported | Yes |
Number of SIM Card Supported | 2 |
SIM Size Supported | Nano |
Storage | |
Flash Memory Capacity | 8 GB |
Physical Characteristics | |
Product Material | Aluminum |
Form Factor | Portable |
Height | 1.34" (34 mm) |
Width | 4.84" (123 mm) |
Depth | 4.65" (118 mm) |
Weight (Approximate) | 516 g |
Miscellaneous | |
Environmentally Friendly | Yes |
Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE),Restriction of Hazardous Substances (RoHS),Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) |
Warranty | |
Limited Warranty | Lifetime |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
Manufacturer-Brochure
[/custom-user-manual]
