- Capacity: 1000VA/600W
- Topology: Line Interactive
- Waveform: Sine Wave
- Output: 120Vac ± 5%
- Plug type & cord: NEMA 5-15P, 5 ft. cord
- Outlet types: 10 × NEMA 5-15R
- Communication: USB, Relay
- Data line protection: Network
- Management software: PowerPanel® Personal
- ENERGY STAR® certified: Yes
Marketing Information: A mini-tower UPS with line interactive topology, the CyberPower PFC Sinewave CP1000PFCLCD provides battery backup, power protection (using sine wave output), and surge protection for desktop computers, workstations, networking devices, and home entertainment systems requiring active PFC power source compatibility. The CP1000PFCLCD uses Automatic Voltage Regulation (AVR) to correct minor power fluctuations without switching to battery power, which extends battery life. AVR is essential in areas where power fluctuations occur frequently. The CP1000PFCLCD comes with a three-year warranty and a
- 350,000 Connected Equipment Guarantee. Battery Backup
Supplies power long enough for equipment to properly shut down when utility power fails. Helps prevent loss of data and minimizes the component stress caused by a hard shutdown.
Surge Protection
Diverts excess voltage away from sensitive electronic equipment during an AC power surge or power spike to prevent damage.
Data Line Protection
Prevents power surges that travel through telephone, coaxial, and Ethernet lines from causing damage to electronics.
Line Interactive Topology
Exists when a line interactive UPS has an autotransformer that regulates low voltages (e.g., brownouts) and over voltages (e.g., spikes) without having to switch to battery.
Automatic Voltage Regulation (AVR)
Provides clean, consistent AC power by automatically increasing (boosting) low voltage without using battery power when incoming utility power experiences minor fluctuations.
Sine Wave Output
Provides power protection to ENERGY STAR® 6.0 systems with Active PFC power supplies.
GreenPower UPS™ Bypass Design
Is a patented design that allows utility power to bypass the UPS transformer, when AC power is stable, which reduces energy consumption, noise, and heat buildup.
Multifunction LCD Panel
Displays immediate, detailed information on the UPS battery and power conditions, alerting users to potential problems before they can affect critical equipment and cause downtime.
Ultra Quiet Design
Minimizes noise during operation for a quieter work environment.
PowerPanel® Personal Software
Provides a user-friendly dashboard interface for controlling and monitoring the UPS. Free software download available here.
Three-Year Warranty
CyberPower will repair or replace a defective UPS system (including batteries) within three years of the purchase date. See warranty for details.
Connected Equipment Guarantee
CyberPower will repair or replace properly connected equipment if it is damaged by a power surge. What's In The Box
UPS System, User Manual, Telephone Cable, PowerPanel Personal Edition Software CD, Coaxial Cable, USB A+B Type Cable, Warranty Registration Card, Function Setup Guide.
More from the Manufacturer
AVR: YesPlug/Connector Type: NEMA 5-15PReceptacle Type: NEMA 5-15RReceptacle Detail: 10 x NEMA 5-15RNumber of Battery & Surge Outlets: 5Number of Surge-only Outlets: 5Dataline Protection: RJ-45EMI/RFI Noise Filter: YesEnergy Saving: GreenPower UPS™ Bypass DesignApplication/Usage: - Desktop Computer
- Workstation
- Home Theater
- Electronic Equipment
- Home Network
- Router
- Modem
- VoIP Phone System
Load Capacity (VA): 1 kVALoad Capacity (Watt): 600 WInput Voltage: 120 V ACInput Voltage Range: 88 V AC - 144 V ACOutput Voltage: 120 V ACInput Frequency: 63 HzOutput Frequency: 60 HzWaveform Type: Sine WaveSurge Energy Rating: 1150 JAlarm: - On Battery
- Low Battery
- Overload
- Fault
Status Indicators: Serial Port: YesUSB: YesEPO Port: NoUSB (HID Compliant) Port: YesNumber of Batteries: 1Battery Characteristics: Maintenance-freeBattery Chemistry: Lead AcidBattery Size: 12VBattery Capacity: 9000 mAhBackup/Run Time (Full Load): 3 MinuteBackup/Run Time (Half Load): 9 MinuteHot Swappable: YesTypical Battery Recharge Time: 8 HourReplaceable Battery: YesMaximum Operating Elevation: 10000 ft (3048000 mm)Operating Humidity: 0% - 90%Maximum Operating Temperature: 104°F (40°C)Height: 9.70" (246.38 mm)Width: 3.90" (99.06 mm)Depth: 10.20" (259.08 mm)Form Factor: Mini-towerWeight (Approximate): 8.16 kgPackage Contents: - PFC Sinewave CP1000PFCLCD 1000VA Mini-Tower UPS
- User Manual
- Telephone Cable
- PowerPanel Personal Edition Software CD
- Coaxial Cable
- USB A+B Type Cable
- Warranty Registration Card
- Function Setup Guide
Software Included: PowerPanel Personal Edition SoftwareEnergy Star: YesEnvironmentally Friendly: YesLimited Warranty: 3 Year
[custom-specifications]
SpecificationsManufacturer: CyberPower Systems, Inc
Manufacturer Part Number: CP1000PFCLCD
Manufacturer Website Address: https://www.cyberpowersystems.com/
Brand Name: CyberPower
Product Series: PFC Sinewave UPS
Product Model: CP1000PFCLCD
Product Name: PFC Sinewave CP1000PFCLCD 1000VA Mini-Tower UPS
Product Type: Line-interactive UPS
Technical InformationAVR: Yes
Plug/Connector Type: NEMA 5-15P
Receptacle Type: NEMA 5-15R
Receptacle Detail: 10 x NEMA 5-15R
Number of Battery & Surge Outlets: 5
Number of Surge-only Outlets: 5
Dataline Protection: RJ-45
EMI/RFI Noise Filter: Yes
Energy Saving: GreenPower UPS™ Bypass Design
Application/Usage:
- Desktop Computer
- Workstation
- Home Theater
- Electronic Equipment
- Home Network
- Router
- Modem
- VoIP Phone System
Power DescriptionLoad Capacity (VA): 1 kVA
Load Capacity (Watt): 600 W
Input Voltage: 120 V AC
Input Voltage Range: 88 V AC - 144 V AC
Output Voltage: 120 V AC
Input Frequency: 63 Hz
Output Frequency: 60 Hz
Waveform Type: Sine Wave
Surge Energy Rating: 1150 J
ManagementAlarm:
- On Battery
- Low Battery
- Overload
- Fault
Controls/IndicatorsStatus Indicators:
Interfaces/PortsSerial Port: Yes
USB: Yes
EPO Port: No
USB (HID Compliant) Port: Yes
Battery InformationNumber of Batteries: 1
Battery Characteristics: Maintenance-free
Battery Chemistry: Lead Acid
Battery Size: 12V
Battery Capacity: 9000 mAh
Backup/Run Time (Full Load): 3 Minute
Backup/Run Time (Half Load): 9 Minute
Hot Swappable: Yes
Typical Battery Recharge Time: 8 Hour
Replaceable Battery: Yes
Environmental ConditionsMaximum Operating Elevation: 10000 ft (3048000 mm)
Operating Humidity: 0% - 90%
Maximum Operating Temperature: 104°F (40°C)
Physical CharacteristicsHeight: 9.70" (246.38 mm)
Width: 3.90" (99.06 mm)
Depth: 10.20" (259.08 mm)
Form Factor: Mini-tower
Weight (Approximate): 8.16 kg
MiscellaneousPackage Contents:
- PFC Sinewave CP1000PFCLCD 1000VA Mini-Tower UPS
- User Manual
- Telephone Cable
- PowerPanel Personal Edition Software CD
- Coaxial Cable
- USB A+B Type Cable
- Warranty Registration Card
- Function Setup Guide
Software Included: PowerPanel Personal Edition Software
Energy Star: Yes
Environmentally Friendly: Yes
WarrantyLimited Warranty: 3 Year
[/custom-specifications]
