CyberPower OL5KRTHD Smart App Online UPS Systems - 200 - 240 VAC, Hardwire Terminal (NEMA L6-30P power cord included), 2U, Rack / Sine (OL5KRTHD)

Marketing Information:

• The CyberPower Smart App Online OL5KRTHD high-density design offers more power in less space. In fact, it can be configured into 2U of rack space or as a tower, compared to 3U and 4U for similar competitive UPS models - giving you more room to grow. The OL5KRTHD features double-conversion topology for seamless power protection and a pre-installed RMCARD205.

  For monitoring, this UPS offers a new state-of-the-art, multi-function, color matrix LCD screen that is simple to set up and easy to use. The color-coded alerts provide clear status of the UPS and the screen orientation rotates automatically when placed into a tower configuration.

  The OL5KRTHD ensures maximum efficiency and capacity output with a Power Factor rating (PF) of 1. The energy-saving GreenPower UPS™ ECO Mode enables up to 96% efficiency while reducing power consumption and thermal dissipation. The variable 7-speed fan provides automatic thermal management, based on power load, to reduce noise.

  The optional BP144VL2U01 Extended Battery Module (EBM) expands runtime and up to ten EBMs can be connected in a daisy-chain to the UPS for more backup power. Plus, it's all backed by a three-year warranty (including batteries) and a

• 300,000 Connected Equipment Guarantee.

  More from the Manufacturer

Plug/Connector Type: Hardwired

Receptacle Type: NEMA L6-20R,NEMA L6-30R

Receptacle Detail: 2 x NEMA L6-20R,2 x NEMA L6-30R

Transfer Time: 0 ns

Protection Type: Short Circuit

Overload Protection: Yes

EMI/RFI Noise Filter: Yes

Energy Saving: ECO Mode Efficiency: 96%

Load Capacity (VA): 5 kVA

Input Voltage: 230 V AC

Input Voltage Range: 120 V AC - 139 V AC

Output Voltage: 200 V AC,208 V AC,220 V AC,230 V AC,240 V AC

Input Frequency: 70 Hz

Output Frequency: 60 Hz

Waveform Type: Sine Wave

Surge Energy Rating: 2430 J

Network Management: SNMP/HTTP Remote Monitoring

Alarm: Battery Mode,Low Battery,Overload,UPS Fault

Status Indicators:

• LED Indicators: Power On (White)

Multi-Function Color TFT-LCD Readout that Supports:

• 15 x Types of UPS status
• 7 x Types of Controls
• 20 x Types of Set Up
• 12 x Event Logs
• 11 x Types of About
• 4 x Types of Diagnostics

Serial Port: Yes

USB (HID Compliant) Port: Yes

EPO Port: Yes

DC System Voltage: 12 V DC

Number of Batteries: 12

Battery Characteristics: Sealed

Battery Chemistry: Lead Acid

Battery Size: 12V

Battery Capacity: 6000 mAh

Backup/Run Time (Full Load): 2.30 Minute

Backup/Run Time (Half Load): 6.40 Minute

Typical Battery Recharge Time: 4 Hour

Replaceable Battery: Yes

Maximum Operating Temperature: 104°F (40°C)

Storage Temperature: -4°F (-20°C) - 113°F (45°C)

Maximum Operating Elevation: 10000 ft (3048000 mm)

Maximum Storage Elevation: 50000 ft (15240000 mm)

Storage Relative Humidity: 0% - 95%

Sound Emission (A-Weighted): 66 dB(A)

Thermal Dissipation: 1186 BTU/h

Form Factor: Rack/Tower

Rack Height: 2U

Height: 3.40" (86.36 mm)

Width: 17" (431.80 mm)

Depth: 28.30" (718.82 mm)

Weight (Approximate): 41.91 kg

Package Contents:

• Smart App Online OL5KRTHD 5KVA Tower/Rack Convertible UPS
• Mounting Hardware

Energy Star: Yes

Country of Origin: Taiwan

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 3 Year
