CyberPower Smart App Online OL10KRT 10KVA Tower/Rack Mountable UPS - 6U Rack/Tower - 3.60 Minute Stand-by - 230 V AC Input - 200 V AC, (OL10KRT)

Marketing Information:

• The CyberPower Smart App Online OL10KRT is a 6U rack/tower double-conversion UPS. It provides sine wave output to multiple types of critical IT infrastructure requiring seamless power protection. The OL10KRT is generator compatible and delivers consistent 200-240 V power with zero-transfer time. Automatic-bypass ensures connected equipment continues to operate seamlessly when an overload or internal fault is detected.

  The OL10KRT features a removable LCD control panel to reposition it in a more convenient location (with optional DB-26 cable), and it has a RMCARD205 pre-installed network card. Smart-battery management charging technology increases battery life by up to 50%. Fast-charge technology helps replenish battery charge from 0-90% in five hours, regardless of the number of Extended Battery Modules (EBM) connected. The energy-saving GreenPower UPS™ ECO Mode allows the UPS to reach up to 97% efficiency to reduce power consumption and thermal dissipation.

  This UPS can use the BP240VL3U01 extended battery module for more runtime. The OL10KRT comes with a three-year warranty (including batteries) and a

• 300,000 connected equipment guarantee.
  • Offers power supply with zero transfer time taken to the battery and proves ideal for voltage sensitive equipment
  • 10000 VA load capacity - work without any interruption during power outages
  • Prevent critical data loss by staying powered during a blackout with up to 10 kW load capacity

  More from the Manufacturer

Plug/Connector Type: Hardwired

Receptacle Type: NEMA L6-30R,Terminal Block

Receptacle Detail: 3 x NEMA L6-30R,1 x Terminal Block

Application/Usage: Server,Network Device,Storage Device,VoIP

Load Capacity (VA): 10 kVA

Input Voltage: 230 V AC

Input Voltage Range: 200 V AC - 240 V AC

Output Voltage: 200 V AC,208 V AC,220 V AC,230 V AC,240 V AC

Waveform Type: Sine Wave

Network Management: SNMP Manageable

Network (RJ-45): Yes

Backup/Run Time (Full Load): 3.60 Minute

Backup/Run Time (Half Load): 10 Minute

Product Color: Black

Form Factor: Rack/Tower

Rack Height: 6U

Height: 10.50" (266.70 mm)

Width: 17" (431.80 mm)

Depth: 26" (660.40 mm)

Weight (Approximate): 103 kg

Package Contents:

• Smart App Online OL10KRT 10KVA Tower/Rack Mountable UPS
• Extended Battery Module EBM
• Left & Right Rackmount Rails
• Left & Right Hanging Brackets
• Phone Cable
• USB Communication Cable
• Serial Interface Cable RS-232)
• NEMA L6-30P to IEC-320-C13 Power Cord
• Quick Start Guide
• Safety Instructions
• Registration Warranty Card
• PowerPanel Management Software Download Card
• 4 x Rackmount Ears
• Tie Plate
• 16 x Black M5X7L Flat Head Screws
• 24 x Black M5X12L Pan Head Screws
• 12 x Silver M5X6L Pan Head Screws
• 16 x Plastic Washers 28 x Screw Hole Dust Covers
• 24 x Rubber Pads

Energy Star: No

Country of Origin: China

Environmentally Friendly: Yes

Environmental Compliance: Restriction of Hazardous Substances (RoHS)

Limited Warranty: 3 Year
