Marketing Information: Eaton Metered Input ePDUs provide remote monitoring of the current draw of individual sections via network communication. This capability, combined with state-of-the-art software allows you to aggregate the information from many ePDUs in one location. A local display is also available for phase balancing and for easy start-up and provisioning of servers. New ePDU G3 Metered Input models feature best-in-class technologies, including ±1% billing grade accuracy, an advanced LCD pixel display, a hot-swap meter and the ability to daisy chain four ePDUs to share the same network connection and IP address.Plug/Connector Type: NEMA L5-30PPlug/Connector Detail: 1 x NEMA L5-30PReceptacle Type: NEMA 5-20RReceptacle Detail: 12 x NEMA 5-20RInput Voltage: 120 V ACOutput Voltage: 120 V ACPower Rating (Watt): 2.88 kWInput Current: 24 ANetwork (RJ-45): YesMounting Orientation: HorizontalRack Height: 1UHeight: 19" (482.60 mm)Width: 1.69" (42.93 mm)Depth: 8" (203.20 mm)Package Contents: - ePDU Metered EMIT03-10 12-Outlet PDU
- SPK021-Installation
- SPK013-Network
Country of Origin: United StatesLimited Warranty: 3 Year
[custom-specifications]
SpecificationsManufacturer: Eaton Corporation
Manufacturer Part Number: EMIT03-10
Manufacturer Website Address: http://www.eaton.com/EatonCom/Markets/NorthAmerica
Brand Name: Eaton
Product Line: ePDU
Product Series: Metered
Product Model: EMIT03-10
Product Name: ePDU Metered EMIT03-10 12-Outlet PDU
Product Type: PDU
Technical InformationPlug/Connector Type: NEMA L5-30P
Plug/Connector Detail: 1 x NEMA L5-30P
Receptacle Type: NEMA 5-20R
Receptacle Detail: 12 x NEMA 5-20R
Power DescriptionInput Voltage: 120 V AC
Output Voltage: 120 V AC
Power Rating (Watt): 2.88 kW
Input Current: 24 A
Interfaces/PortsNetwork (RJ-45): Yes
Physical CharacteristicsMounting Orientation: Horizontal
Rack Height: 1U
Height: 19" (482.60 mm)
Width: 1.69" (42.93 mm)
Depth: 8" (203.20 mm)
MiscellaneousPackage Contents:
- ePDU Metered EMIT03-10 12-Outlet PDU
- SPK021-Installation
- SPK013-Network
Country of Origin: United States
WarrantyLimited Warranty: 3 Year
[/custom-specifications]
