Hanwha TNV-C7013RC 3 Megapixel Outdoor Network Camera - Color - Dome - White - 49.21 ft (15 m) Infrared Night Vision - H.265, H.265M, (TNV-C7013RC)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Write a Review
Hanwha
Hanwha TNV-C7013RC 3 Megapixel Outdoor Network Camera - Color - Dome - White - 49.21 ft (15 m) Infrared Night Vision - H.265, H.265M, (TNV-C7013RC)
HD Recording: Yes
Night Vision: Yes
Night Vision Distance: 49.21 ft (15 m)
Night Vision Type: Infrared
Image Sensor Type: CMOS
Image Sensor Size: 1/1.8"
Color Supported: Color
Field of View: H: 128°, V: 100°
Effective Camera Resolution: 3 Megapixel
Video Formats: H.265,H.265M,H.265B,H.265H,H.264,H.264M,H.264B,H.264H,MJPEG
Maximum Video Resolution: 2048 x 1536
Lens Type: Fixed
Maximum Focal Length: 2.4 mm
Lens Included: Yes
Maximum Aperture: f/2.0
Shortest Shutter Speed: 1/12000 Second
Longest Shutter Speed: 2 Second
Connectivity Technology: Wired
Remote Management: Yes
Ethernet Technology: Fast Ethernet
Protocols: Multicast,ONVIF,IPv4,IPv6,TCP/IP,UDP/IP,RTP/TCP,RTP/UDP,RTCP,RTSP,NTP,HTTP,HTTPS,SSL/TLS,DHCP,FTP,SMTP,ICMP,IGMP,SNMPv1/v2c/v3 (MIB2),ARP,DNS,DDNS,QoS,UPnP,Bonjour,LLDP,CDP,SRTP,MQTT
Storage Type: Memory Card
Network (RJ-45): Yes
Power Source Type: PoE,DC
Color Family: White
Product Color: White
Mount Type: Corner Mount
Form Factor: Dome
Height: 4.13" (104.80 mm)
Width: 7.81" (198.30 mm)
Depth: 7.82" (198.60 mm)
Weight (Approximate): 1.94 kg
Minimum Operating Temperature: 14°F (-10°C)
Maximum Operating Temperature: 131°F (55°C)
Maximum Operating Humidity: 95%
Features: Day/Night,Built-in IR LED,Back Light Compensation (BLC),Built-in HLC,Wide Dynamic Range,Digital Noise Reduction,Digital Image Stabilization,Defog,Motion Detection,Privacy Masking
Indoor/Outdoor: Outdoor
Impact Protection Rating: IK10+
Ingress Protection Rating: IP66,IP6K9K
Country of Origin: Vietnam
Limited Warranty: 3 Year
- For remote surveillance needs, this network camera is best suited
- Up to 2048 x 1536 resolution for surveillance in real-time
- CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
- Up to 49.21 ft (15 m) of night vision
[custom-specifications]
| Specifications | |
| Manufacturer | Hanwha Group |
| Manufacturer Part Number | TNVC7013RC |
| Manufacturer Website Address | http://www.hanwha.com |
| Brand Name | Hanwha |
| Product Model | TNV-C7013RC |
| Product Name | AI Corner Mount Camera |
| Product Type | Network Camera |
| Technical Information | |
| HD Recording | Yes |
| Night Vision | Yes |
| Night Vision Distance | 49.21 ft (15 m) |
| Night Vision Type | Infrared |
| Display & Graphics | |
| Image Sensor Type | CMOS |
| Image Sensor Size | 1/1.8" |
| Color Supported | Color |
| Field of View | H: 128°, V: 100° |
| Effective Camera Resolution | 3 Megapixel |
| Video | |
| Video Formats | H.265,H.265M,H.265B,H.265H,H.264,H.264M,H.264B,H.264H,MJPEG |
| Maximum Video Resolution | 2048 x 1536 |
| Lens | |
| Lens Type | Fixed |
| Maximum Focal Length | 2.4 mm |
| Lens Included | Yes |
| Maximum Aperture | f/2.0 |
| Exposure | |
| Shortest Shutter Speed | 1/12000 Second |
| Longest Shutter Speed | 2 Second |
| Network & Communication | |
| Connectivity Technology | Wired |
| Remote Management | Yes |
| Ethernet Technology | Fast Ethernet |
| Protocols | Multicast,ONVIF,IPv4,IPv6,TCP/IP,UDP/IP,RTP/TCP,RTP/UDP,RTCP,RTSP,NTP,HTTP,HTTPS,SSL/TLS,DHCP,FTP,SMTP,ICMP,IGMP,SNMPv1/v2c/v3 (MIB2),ARP,DNS,DDNS,QoS,UPnP,Bonjour,LLDP,CDP,SRTP,MQTT |
| Storage | |
| Storage Type | Memory Card |
| Interfaces/Ports | |
| Network (RJ-45) | Yes |
| Power Description | |
| Power Source Type | PoE,DC |
| Physical Characteristics | |
| Color Family | White |
| Product Color | White |
| Mount Type | Corner Mount |
| Form Factor | Dome |
| Height | 4.13" (104.80 mm) |
| Width | 7.81" (198.30 mm) |
| Depth | 7.82" (198.60 mm) |
| Weight (Approximate) | 1.94 kg |
| Environmental Conditions | |
| Minimum Operating Temperature | 14°F (-10°C) |
| Maximum Operating Temperature | 131°F (55°C) |
| Maximum Operating Humidity | 95% |
| Miscellaneous | |
| Features | Day/Night,Built-in IR LED,Back Light Compensation (BLC),Built-in HLC,Wide Dynamic Range,Digital Noise Reduction,Digital Image Stabilization,Defog,Motion Detection,Privacy Masking |
| Indoor/Outdoor | Outdoor |
| Impact Protection Rating | IK10+ |
| Ingress Protection Rating | IP66,IP6K9K |
| Country of Origin | Vietnam |
| Warranty | |
| Limited Warranty | 3 Year |
[/custom-specifications]
[custom-options]
| Product | Hanwha Conduit dome cover for TNV-C7013RC - Aluminum - White |
| SKU | SPG-VAN13W |
| Sale Price | $73.25 |
[/custom-options]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
Additional-pdf1
Additional-pdf2
Additional-pdf3
[/custom-user-manual]
Warranty Infomartion
3 Year
