HPE MSA 2060 16Gb Fibre Channel SFF 46TB Flash Bundle - 24 x HDD Supported - 1843.20 TB Supported HDD Capacity - 12Gb/s SAS - 24 x SSD (S2E41B)
Have questions?
1-844-836-8268
Ask an Experts-
Canadian distributor
Proud Canadian business since 2007
-
IT experts available
Consulting & Technicial services
-
Pre-configuration services
From VoiP phone to Clustered servers
-
Delivering across Canada
Shipping UPS Fedex & Purolator
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Free Shipping*
Shipping Restrictions
Additional fees may apply for shipments to locations beyond normal service areas and heavy weight or oversize items.
Marketing Information:
HPE MSA 2060 Storage Array
The HPE MSA 2060 is a flash-ready hybrid storage system designed to deliver hands-free, affordable application acceleration for small and remote office deployments. Don't let the low cost fool you. It gives you the combination of simplicity, flexibility, and advanced features you may not expect in an entry-priced array. Start small and scale as needed with any combination of solid state drives (SSDs), high-performance Enterprise SAS HDDs, or lower-cost Midline SAS HDDs. With the ability to deliver up to 395,000 IOPS, the new MSA 2060 is up to 80% faster than its prior generation with ample horsepower for even the most demanding workloads.
Number of Hard Drives Supported: 24
Total Hard Drive Capacity Supported: 1843.20 TB
Hard Drive Interface: 12Gb/s SAS
Number of Solid State Drive Supported: 24
Number of Solid State Drive Installed: 12
Total Solid State Drive Capacity Supported: 1843.20 TB
Total Solid State Drive Capacity Installed: 46 TB
Solid State Drive Configuration: 12 x 3.84TB
Ethernet Technology: 10 Gigabit Ethernet,25 Gigabit Ethernet
Number of Total Expansion Bays: 24
Number of 2.5" Bays: 24
Number of Controllers: 2
Controller Type: Fibre Channel
RAID Supported: Yes
Drive Interface: 12Gb/s SAS
Host Interface: 12Gb/s SAS
Number of Network (RJ-45) Ports: 2
Fibre Channel: Yes
Protocols: SNMP,SMI-S,SSH,SMTP,FTP,SFTP,HTTP,HTTPS,Telnet
Height: 3.50" (88.90 mm)
Width: 19" (482.60 mm)
Depth: 26.40" (670.56 mm)
Form Factor: Rack-mountable
Rack Height: 2U
TAA Compliant: Yes
- RAID technology - data reliability, fault tolerance and improved overall performance
- Optimize business network's performance with 10 Gigabit Ethernet connectivity
[custom-specifications]
Specifications | |
Manufacturer | Hewlett Packard Enterprise |
Manufacturer Part Number | S2E41B |
Manufacturer Website Address | http://www.hpe.com |
Brand Name | HPE |
Product Model | 2060 |
Product Name | MSA 2060 16Gb Fibre Channel SFF 46TB Flash Bundle |
Product Type | SAN/NAS Storage System |
Storage | |
Number of Hard Drives Supported | 24 |
Total Hard Drive Capacity Supported | 1843.20 TB |
Hard Drive Interface | 12Gb/s SAS |
Number of Solid State Drive Supported | 24 |
Number of Solid State Drive Installed | 12 |
Total Solid State Drive Capacity Supported | 1843.20 TB |
Total Solid State Drive Capacity Installed | 46 TB |
Solid State Drive Configuration | 12 x 3.84TB |
Network & Communication | |
Ethernet Technology | 10 Gigabit Ethernet,25 Gigabit Ethernet |
I/O Expansions | |
Number of Total Expansion Bays | 24 |
Number of 2.5" Bays | 24 |
Controllers | |
Number of Controllers | 2 |
Controller Type | Fibre Channel |
RAID Supported | Yes |
Interfaces/Ports | |
Drive Interface | 12Gb/s SAS |
Host Interface | 12Gb/s SAS |
Number of Network (RJ-45) Ports | 2 |
Fibre Channel | Yes |
Management & Protocols | |
Protocols | SNMP,SMI-S,SSH,SMTP,FTP,SFTP,HTTP,HTTPS,Telnet |
Physical Characteristics | |
Height | 3.50" (88.90 mm) |
Width | 19" (482.60 mm) |
Depth | 26.40" (670.56 mm) |
Form Factor | Rack-mountable |
Rack Height | 2U |
Miscellaneous | |
TAA Compliant | Yes |
[/custom-specifications]
[custom-user-manual]
Available Documentation:
User-Manual
Manufacturer-Brochure
Additional-pdf1
Additional-pdf2
Additional-pdf3
[/custom-user-manual]
