- With 32 GB memory, improve system performance to execute complex applications
- RAID provides data reliability, fault tolerance and improves overall performance
- Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
- 800 W power supply unit (PSU) included
Marketing Information: Adaptable for diverse workloads and environments, the secure 2P 2U HPE ProLiant DL380 Gen11 delivers world-class performance with the right balance of expandability and scalability. Designed for supreme versatility and resiliency while being backed by a comprehensive warranty make it ideal for multiple environments from Containers to Cloud to Big Data. Standardize on the industry's most trusted compute platform.
Number of Processors Supported: 2Number of Processors Installed: 1Processor Manufacturer: IntelProcessor Type: Xeon GoldProcessor Generation: 4th GenProcessor Model: 5416SProcessor Core: Hexadeca-core (16 Core)Processor Speed: 2 GHzCache: 30 MBChipset Manufacturer: IntelChipset Model: C741Standard Memory: 32 GBMaximum Memory Supported: 8 TBMemory Technology: DDR5 SDRAMNumber of Total Memory Slots: 32Number of Occupied Memory Slots: 1Signal Processing: Registered (Buffered)Controller Type: Controller Model: MR408i-oRAID Supported: YesNumber of Total Expansion Bays: 8Number of Internal 2.5" Bays: 8Number of SFF Bays: 8Hot Swappable Bays: YesNumber of Total Expansion Slots: 3PCI Express Details: 3-slots (x8, x16, x8) as standardGraphics Memory Capacity: 16 MBEthernet Technology: 10 Gigabit EthernetTotal Number of USB Ports: 5Number of USB 2.0 Ports: 1Number of USB 3.0 Ports: 4Network (RJ-45): YesNumber of Network (RJ-45) Ports: 2VGA: YesRemote Management: YesRemote Management Controller: HPE iLO 6Operating System Supported: - Windows Server
- Red Hat Enterprise Linux
- SuSE Linux Enterprise Server
- Oracle Linux
- Ubuntu
Input Voltage: Number of Power Supplies Supported: 2Number of Power Supplies Installed: 1Plug/Connector Type: C13/C14Maximum Power Supply Wattage: 800 WHot Swappable Power Supply: YesPackage Contents: - ProLiant DL380 G11 Server
- SFF Easy Install Rail Kit
- Cable Management Arm
- 6-foot IEC C-13/C-14 Jumper Cord
Security Features: - UEFI Secure Boot and Secure Start support
- Tamper-free updates - components digitally signed and verified
- Immutable Silicon Root of Trust
- Ability to rollback firmware
- FIPS 140-2 validation
- Secure erase of NAND/User data
- Common Criteria certification
- Configurable for PCI DSS compliance
- Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
- Support for Commercial National Security Algorithms (CNSA)
- Secure Recovery - recover critical firmware to known good state on detection of compromised firmware
Energy Star: YesEnvironmentally Friendly: YesEnvironmental Certification: - ENERGY STAR 3.0
- WEEE
- EU WEEE
Form Factor: RackRack Height: 2UHeight: 3.44" (87.50 mm)Width: 17.64" (448 mm)Depth: 28.62" (727 mm)Weight (Approximate): 33 kgLimited Warranty: 3 YearAdditional Warranty Information: 3-year parts, 3-year labor, 3-year onsite support with next business day response.
[custom-specifications]
SpecificationsManufacturer: Hewlett Packard Enterprise
Manufacturer Part Number: P52561B21
Manufacturer Website Address: http://www.hpe.com
Brand Name: HPE
Product Line: ProLiant
Product Series: DL380 G11
Product Name: ProLiant DL380 G11 Server
Product Type: Server
ProcessorNumber of Processors Supported: 2
Number of Processors Installed: 1
Processor Manufacturer: Intel
Processor Type: Xeon Gold
Processor Generation: 4th Gen
Processor Model: 5416S
Processor Core: Hexadeca-core (16 Core)
Processor Speed: 2 GHz
Cache: 30 MB
ChipsetChipset Manufacturer: Intel
Chipset Model: C741
MemoryStandard Memory: 32 GB
Maximum Memory Supported: 8 TB
Memory Technology: DDR5 SDRAM
Number of Total Memory Slots: 32
Number of Occupied Memory Slots: 1
Signal Processing: Registered (Buffered)
ControllersController Type:
Controller Model: MR408i-o
RAID Supported: Yes
I/O ExpansionsNumber of Total Expansion Bays: 8
Number of Internal 2.5" Bays: 8
Number of SFF Bays: 8
Hot Swappable Bays: Yes
Number of Total Expansion Slots: 3
PCI Express Details: 3-slots (x8, x16, x8) as standard
Display & GraphicsGraphics Memory Capacity: 16 MB
Network & CommunicationEthernet Technology: 10 Gigabit Ethernet
Interfaces/PortsTotal Number of USB Ports: 5
Number of USB 2.0 Ports: 1
Number of USB 3.0 Ports: 4
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
VGA: Yes
Remote Management: Yes
Remote Management Controller: HPE iLO 6
Operating SystemOperating System Supported:
- Windows Server
- Red Hat Enterprise Linux
- SuSE Linux Enterprise Server
- Oracle Linux
- Ubuntu
Power DescriptionInput Voltage:
Number of Power Supplies Supported: 2
Number of Power Supplies Installed: 1
Plug/Connector Type: C13/C14
Maximum Power Supply Wattage: 800 W
Hot Swappable Power Supply: Yes
MiscellaneousPackage Contents:
- ProLiant DL380 G11 Server
- SFF Easy Install Rail Kit
- Cable Management Arm
- 6-foot IEC C-13/C-14 Jumper Cord
Security Features:
- UEFI Secure Boot and Secure Start support
- Tamper-free updates - components digitally signed and verified
- Immutable Silicon Root of Trust
- Ability to rollback firmware
- FIPS 140-2 validation
- Secure erase of NAND/User data
- Common Criteria certification
- Configurable for PCI DSS compliance
- Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser
- Support for Commercial National Security Algorithms (CNSA)
- Secure Recovery - recover critical firmware to known good state on detection of compromised firmware
Energy Star: Yes
Environmentally Friendly: Yes
Environmental Certification:
- ENERGY STAR 3.0
- WEEE
- EU WEEE
Physical CharacteristicsForm Factor: Rack
Rack Height: 2U
Height: 3.44" (87.50 mm)
Width: 17.64" (448 mm)
Depth: 28.62" (727 mm)
Weight (Approximate): 33 kg
WarrantyLimited Warranty: 3 Year
Additional Warranty Information:
3-year parts, 3-year labor, 3-year onsite support with next business day response.
