Marketing Information: Unlock the full potential of your premium laptop.
Ideal for professionals and creatives who want more screens for visual productivity, more speed to work with large files, support for multiple 4K monitors, and more ports so they can connect to accessories without using adapters, the SD5800T Thunderbolt™ 4 and USB4® Quad Video Docking Station is a highspeed dock that provides everything you need to unlock the full potential of your premium laptop.
As one of the first Thunderbolt™ 4 docks capable of supporting Quad 4K displays, the SD5800T Thunderbolt™ 4 and USB4® Quad Video Docking Station provides a powerful plug-and-play connection- including support for four 4K monitors for the latest Windows laptops and two 6K monitors for the latest MacBook models, 40Gbps data transfer speeds, up to 100W charging (98W certified), and a 16-in-1 design.
The SD5800T Thunderbolt™ 4 and USB4® Quad Video Docking Station delivers more screens, more speed, and more power-so you can be more productive and focused.
Features include:
- Plug-and-play solution for Thunderbolt™ 4, Thunderbolt™ 3, USB4®, and USB-C®
- Windows (10 or later) or macOS (11 or later)
- 40Gbps of data, video, and audio
- Up to Quad 4K video for Windows and up to Dual 6K for MacBook
- Up to 100W Charging (98W certified)
- 16 Productivity Ports
- Supports Zero-Footprint Mounting
- Kensington Security Cable Lock Slots
- 3-year limited warranty and Kensington DockWorks™ Software
Connectivity Technology: WiredCharging Capability: YesNumber of Displays Supported: 4Supported Resolutions: - 3840 x 2160
- 7680 x 4320
- 2048 x 1080
- 1920 x 1080
- 2560 x 1440
Screen Mode Supported: Memory Card Reader: YesMemory Card Supported: Device Supported: Notebook/Tablet PC/MonitorEthernet Technology: 2.5 Gigabit EthernetHost Interface: Thunderbolt 4Total Number of USB Ports: 7Number of USB 2.0 Ports: 1Number of USB 3.2 Gen 1 Type-A Ports: 2Number of USB 3.2 Gen 2 Type-A Ports: 3Number of USB Type-C Ports: 1USB Type-C: YesUSB Type-C Detail: 1 x USB-C 3.2 Gen2 10GbpsNumber of USB Type-A Ports: 6USB Type-A: YesNumber of RJ-45 Ports: 1Network (RJ-45): YesNumber of DisplayPorts: 2DisplayPort: YesDisplayPort Version: 1.4Headphone/Microphone Combo Port: YesNumber of HDMI Ports: 2HDMI: YesHDMI Version: 2.1Thunderbolt: YesThunderbolt Ports Quantity: 1Number of Thunderbolt 4 Ports: 1USB Power Delivery: 100WOperating System Supported: Maximum Power Supply Wattage: 170 WProduct Color: Height: 7.68" (195 mm)Width: 4.09" (104 mm)Depth: 1.42" (36 mm)Weight (Approximate): 607.8 gPackage Contents: - SD5800T Thunderbolt 4 and USB4 Quad Video Docking Station
- 1 x Thunderbolt™ 4 Passive Cable (0.8m)
- 1 x Power Supply Unit (170W)
- 1 x NA Power Cord
- 1 x Vertical Stand
- 1 x Quick Installation Guide
- 1 x Warranty Card
- 1 x Compliance Sheet
- 1 x Welcome Card
Kensington Security Slot: YesCompatibility: Apple Products:
- MacBook M1 Pro
- MacBook M1 Max
- MacBook M2 Max
- MacBook M2 Pro
- iPad
- MacBook M1
- MacBook M2
Environmentally Friendly: YesEnvironmental Certification: RoHSCountry of Origin: ThailandLimited Warranty: 3 Year
[custom-specifications]
SpecificationsManufacturer: ACCO Brands Corporation
Manufacturer Part Number: K32856NA
Manufacturer Website Address: http://www.acco.com
Brand Name: Kensington
Product Model: SD5800T
Product Name: SD5800T Thunderbolt 4 and USB4 Quad Video Docking Station
Packaged Quantity: 1
Package Type: Retail
Product Type: Docking Station
Technical InformationConnectivity Technology: Wired
Charging Capability: Yes
Number of Displays Supported: 4
Supported Resolutions:
- 3840 x 2160
- 7680 x 4320
- 2048 x 1080
- 1920 x 1080
- 2560 x 1440
Screen Mode Supported:
Memory Card Reader: Yes
Memory Card Supported:
Device Supported: Notebook/Tablet PC/Monitor
Network & CommunicationEthernet Technology: 2.5 Gigabit Ethernet
Interfaces/PortsHost Interface: Thunderbolt 4
Total Number of USB Ports: 7
Number of USB 2.0 Ports: 1
Number of USB 3.2 Gen 1 Type-A Ports: 2
Number of USB 3.2 Gen 2 Type-A Ports: 3
Number of USB Type-C Ports: 1
USB Type-C: Yes
USB Type-C Detail: 1 x USB-C 3.2 Gen2 10Gbps
Number of USB Type-A Ports: 6
USB Type-A: Yes
Number of RJ-45 Ports: 1
Network (RJ-45): Yes
Number of DisplayPorts: 2
DisplayPort: Yes
DisplayPort Version: 1.4
Headphone/Microphone Combo Port: Yes
Number of HDMI Ports: 2
HDMI: Yes
HDMI Version: 2.1
Thunderbolt: Yes
Thunderbolt Ports Quantity: 1
Number of Thunderbolt 4 Ports: 1
USB Power Delivery: 100W
SoftwareOperating System Supported:
Power DescriptionMaximum Power Supply Wattage: 170 W
Physical CharacteristicsProduct Color:
Height: 7.68" (195 mm)
Width: 4.09" (104 mm)
Depth: 1.42" (36 mm)
Weight (Approximate): 607.8 g
MiscellaneousPackage Contents:
- SD5800T Thunderbolt 4 and USB4 Quad Video Docking Station
- 1 x Thunderbolt™ 4 Passive Cable (0.8m)
- 1 x Power Supply Unit (170W)
- 1 x NA Power Cord
- 1 x Vertical Stand
- 1 x Quick Installation Guide
- 1 x Warranty Card
- 1 x Compliance Sheet
- 1 x Welcome Card
Kensington Security Slot: Yes
Compatibility:
Apple Products:
- MacBook M1 Pro
- MacBook M1 Max
- MacBook M2 Max
- MacBook M2 Pro
- iPad
- MacBook M1
- MacBook M2
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country of Origin: Thailand
WarrantyLimited Warranty: 3 Year
