Marketing Information: Perfect Protection For Rack-Mount Systems
The PRO-RT Series is a value-priced, yet feature-rich UPS incorporating line-interactive technology that preserves battery power by providing voltage regulation during brownouts or voltage sags. The PRO-RT Series can be used to support servers, telecom or VoIP systems, security systems, plus many other applications.
The PRO-RT UPSs include many useful features such as load-shedding with two load banks, independent battery bypass, plus auto-re-start when power is restored after an extended power outage.
Versatile Communications
Each PRO-RT model is compatible with Minuteman's free downloadable SentryHD™ power management and diagnostic software. When installed on a workstation or server, the user gains complete control over monitoring and managing the UPS using a convenient web browser-based interface. The SentryHD software communicates via a built-in USB port on the UPS. In addition, managing the UPS within a Network Management System (NMS) is easy with the installation of an optional SNMP card.
Designed for versatility, the PRO-RT models can be mounted in a standard rack using the attached rackmount ears. All units can also be installed as a tower using the included feet. An optional kit is available for mounting the unit to a wall.
High-end Features - Budget Friendly Price
The PRO-RT offers many features normally found on higher priced models, including an LCD status display which shows the following:
- Input / Output voltage and frequency
Monitor the status of your utility power - UPS and battery mode / status
Eliminate guesswork with straightforward display of the unit's status - Load capacity
Load indicator shows how much electrical load is being placed on the unit - Estimated runtime based on connected load
Find out how much backup time remains during a blackout right on the unit
Ideally Suited to Protect:
- Network Equipment
- Servers
- Workstations
- VoIP Communications
- IP and Analog Video Equipment
Plug/Connector Type: NEMA 5-15PReceptacle Type: Receptacle Detail: - 6 x NEMA 5-15/20R
- 1 x NEMA L5-20R
Transfer Time: 10 msApplication/Usage: - Network Equipment
- Server
- Telephone System
- Workstation
- VoIP Phone System
- Video Equipment
Load Capacity (VA): 2 kVALoad Capacity (Watt): 1.40 kWInput Voltage: 120 V ACInput Voltage Range: 90 V AC - 150 V ACOutput Voltage: 120 V ACWaveform Type: Simulated Sine WaveNetwork (RJ-45): YesBackup/Run Time (Full Load): 4 MinuteHot Swappable: YesHeight: 3.40" (86.36 mm)Width: 18.90" (480.06 mm)Depth: 20.10" (510.54 mm)Rack Height: 2UForm Factor: Tower/Rack/Wall MountableWeight (Approximate): 28.49 kgEnergy Star: YesEnvironmentally Friendly: YesEnvironmental Certification: - RoHS 2
- TÜV Rheinland Green Product
Limited Warranty: 3 Year
