Paxton Access Net2 Plus Single Door Expansion Kit, PoE+ PSU - Door - Proximity, Key Code - 50000 User(s) - 1 Door(s) - Ethernet - - 24 (682-950-US)

Marketing Information:

Net2 plus is a networked access control system. A networked system gives the advantages of central control, event reporting and flexible control over users' access. Each control unit is part of a network but can run independently making its own decisions and remembering events.

One Net2 plus control unit can be the network interface to the LAN and also run a wired RS485 daisy chain of other Net2 plus or Net2 classic units, removing the need for an independent TCP/IP to RS485 converter. Net2 plus is available with 12/24V power supply AC DC, power over ethernet (POE), or trigger disconnect power supply, which is suitable for fire alarm disconnect. PoE is a technology that allows both power and data to be passed along Ethernet cabling. Net2 plus with PoE simply plugs straight into the existing LAN using a standard RJ45 plug (providing it is powered by either a PoE switch or a PoE injector).

Control units are sold as a PCB board only or within a plastic housing. The Net2 plus unit now comes with PoE+ power supply in metal/plastic cabinet; no separate mains supply back-up required.

Identification Method: Proximity,Key Code

Number of Users: 50000

Number of Doors: 1

Application/Usage: Door

Ethernet Technology: Ethernet

Network (RJ-45): Yes

Input Voltage: 24 V DC

Package Contents:

• Proximity P50 Mullion Reader
• Net2 Plus in US Metal Enclosure with PoE+ PSU
• Packaging - Net2 Starter Kit, white, small
• Label - Paxton Outer Graphic 247x194mm
• Label - Product Serial Number Label 27x10mm
