- The TS-855eU-RP has a depth of only 11.7 inches (297.4 mm) and is perfectly suited for installation in a compact rack, or places with a lot of cabling.
- Connect TL-R1620Sep-RP / TL-R1220Sep-RP JBOD units to the TS-855eU-RP for adding up to 48 additional drive capacity to match your business growth.
- Features two 2.5GbE ports (backwards compatible with 1G/100M). Supports port trunking for enhanced performance and fault tolerance.
- Features two PCIe Gen 3 slots for installing 5/10/25GbE network cards, QM2 cards or Fibre Channel cards.
- Dual M.2 PCIe NVMe slots enable SSD caching, SSD storage pools, or Qtier™ auto-tiered storage.
- Centralize your virtualization storage, and host multiple virtual machines and containerized apps.
- TS-855EU-RP-8G SAN/NAS Storage System
- 1 x Ethernet Cable
- 2 x Power Cord
- 32 x Flat head screws (for 3.5" HDD)
- 24 x Flat head screws (for 2.5" HDD)
- Quick Installation Guide (QIG)
Marketing Information:
TS-855eU-RP | 2U short-depth rackmount NAS with 8-core computing power for optimized virtualization
Designed for flexible IT deployment and comprehensive virtualization applications, the short-depth TS-855eU-RP 2.5GbE NAS can easily fit in a compact rack in offices or audiovisual rooms. Powered by an Intel® 8-core processor, the TS-855eU-RP packs excellent performance and computing benefits to empower fast data access, backup/restoration, file server, and virtualization applications, while including redundant power supplies to ensure maximum system uptime. Running the QTS operating system as standard, the TS-855eU-RP can be switched to use the ZFS-based QuTS hero operating system based on your requirements. The TS-855eU-RP will be available and supported by QNAP for an extended period (up to 2030) , ideal for businesses requiring matching NAS models deployed for long-term projects.
Compact, space saving
Flexible storage expansion
Dual 2.5GbE connectivity
PCIe expandability
Optimized SSD performance
Virtual machines and containers
2U short-depth design for up to 38% reduction in size
The rackmount TS-855eU-RP has a short depth design of only 11.7 inches (297.4 mm), making it an excellent choice for smaller racks, wall-mount AV rack cabinets, and network rack cabinets. The space saved by the short depth design can be reserved for cabling or ventilation. The TS-855eU-RP is space-saving for flexible deployment and is especially suitable for compact offices, audiovisual rooms, and security surveillance recording.
Ultimate 8-core performance with up to 64 GB RAM and Intel® QuickAssist Technology
Designed for heavy business workloads, the TS-855eU-RP delivers exceptional 8-core performance for running multiple concurrent tasks. AES-NI encryption and Intel® QuickAssist Technology (QAT) is supported to offload computationally-intensive compression and improving IPsec/SSL cryptography performance. Up to 64 GB ECC RAM is supported and redundant power supplies are included to ensure 24/7 system stability. Combining high performance, reliability, and capacity, the TS-855eU-RP is an all-round budget-friendly storage solution for diverse applications, such as file servers, high-speed storage/backup/recovery, and virtualization.
Number of Hard Drives Supported: 8
Number of Hard Drives Installed: 0
Number of Solid State Drive Supported: 8
Number of Solid State Drive Installed: 0
Flash Memory Capacity: 5 GB
Processor Manufacturer: Intel
Processor Type: Atom
Processor Model: C5125
Processor Core: Octa-core (8 Core)
Processor Speed: 2.80 GHz
Standard Memory: 8 GB
Memory Technology: DDR4 SDRAM
Ethernet Technology: 2.5 Gigabit Ethernet
Number of Total Expansion Bays: 8
Number of 2.5"/3.5" Bays: 8
Total Number of Expansion Slots: 2
Expansion Slot Type: PCI Express 3.0 x4
Controller Type: Serial ATA/600
RAID Supported: Yes
RAID Levels: 0, 1, 5, 6, 10, 50, 60, JBOD
Total Number of USB Ports: 4
Number of USB 3.2 Gen 1 Ports: 4
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
Operating System: QTS 5.0.1
Protocols: LDAP,HTTPS,L2TP,SFTP,DHCP,SSH,IPSec,FTPS,AFP,FTP,CIFS/SMB,SNMPv2,IPv4,WEBDAV,Telnet,SSL,iSCSI,TLS,TFTP,NFS,HTTP,FXP,DDNS,IPv6,PPTP
Number of Power Supplies Installed: 2
Maximum Power Supply Wattage: 300 W
Redundant Power Supply: Yes
Height: 3.49" (88.65 mm)
Width: 17.01" (432.05 mm)
Depth: 11.71" (297.43 mm)
Form Factor: Rack-mountable
Rack Height: 2U
Weight (Approximate): 9.47 kg
Package Contents:
Limited Warranty: 3 Year
Additional Warranty Information:
The TS-855eU-RP is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years.
- Enjoy quick web browsing and efficiently deal with your crazy work weeks or playtime marathons with the Intel Atom 2.80 ghz processor that kicks execution into high gear
- Through RAID levels (0, 1, 5, 6, 10, 50, 60, jbod), RAID provides data reliability, fault tolerance and improves overall performance
[custom-specifications]
Specifications | |
---|---|
Manufacturer | QNAP Systems |
Manufacturer Part Number | TS-855EU-RP-8G-US |
Manufacturer Website Address | http://www.qnap.com |
Brand Name | QNAP |
Product Model | TS-855EU-RP-8G |
Product Name | TS-855EU-RP-8G SAN/NAS Storage System |
Product Type | SAN/NAS Storage System | Storage |
Number of Hard Drives Supported | 8 |
Number of Hard Drives Installed | 0 |
Number of Solid State Drive Supported | 8 |
Number of Solid State Drive Installed | 0 |
Flash Memory Capacity | 5 GB | Processor & Chipset |
Processor Manufacturer | Intel |
Processor Type | Atom |
Processor Model | C5125 |
Processor Core | Octa-core (8 Core) |
Processor Speed | 2.80 GHz | Memory |
Standard Memory | 8 GB |
Memory Technology | DDR4 SDRAM | Network & Communication |
Ethernet Technology | 2.5 Gigabit Ethernet | I/O Expansions |
Number of Total Expansion Bays | 8 |
Number of 2.5"/3.5" Bays | 8 |
Total Number of Expansion Slots | 2 |
Expansion Slot Type | PCI Express 3.0 x4 | Controllers |
Controller Type | Serial ATA/600 |
RAID Supported | Yes |
RAID Levels | 0, 1, 5, 6, 10, 50, 60, JBOD | Interfaces/Ports |
Total Number of USB Ports | 4 |
Number of USB 3.2 Gen 1 Ports | 4 |
Network (RJ-45) | Yes |
Number of Network (RJ-45) Ports | 2 | Software |
Operating System | QTS 5.0.1 | Management & Protocols |
Protocols | LDAP,HTTPS,L2TP,SFTP,DHCP,SSH,IPSec,FTPS,AFP,FTP,CIFS/SMB,SNMPv2,IPv4,WEBDAV,Telnet,SSL,iSCSI,TLS,TFTP,NFS,HTTP,FXP,DDNS,IPv6,PPTP | Power Description |
Number of Power Supplies Installed | 2 |
Maximum Power Supply Wattage | 300 W |
Redundant Power Supply | Yes | Physical Characteristics |
Height | 3.49" (88.65 mm) |
Width | 17.01" (432.05 mm) |
Depth | 11.71" (297.43 mm) |
Form Factor | Rack-mountable |
Rack Height | 2U |
Weight (Approximate) | 9.47 kg | Miscellaneous |
Package Contents |
| Warranty |
Limited Warranty | 3 Year |
Additional Warranty Information | The TS-855eU-RP is backed by a 3-year warranty at no additional cost. You can also purchase a warranty extension that extends your warranty coverage up to 5 years. |
