QNAP TS-1273AU-RP-8G SAN/NAS Storage System - AMD Ryzen V1500B Quad-core (4 Core) 2.20 GHz - 12 x HDD Supported - 0 x HDD Installed - (TS-1273AU-RP-8G-US)

Marketing Information:

High-performance dual-2.5GbE NAS Powered by a Quad-core AMD Ryzen™ processor, supporting 10GbE or M.2 SSD caching PCIe expandability for virtual applications

With its powerful AMD Ryzen™ V1000 series V1500B Quad-core processor, the TS-1273AU-RP is capable of boosting virtual machine performance with up to 4 cores/8 threads at 2.2GHz. The TS-1273AU-RP includes two 2.5GbE ports and two PCIe Gen 3 slots, providing you with fast network connectivity and the ability to add extra functionality and additional application potential. The TS-1273AU-RP also features a redundant power supply to ensure maximum system uptime. Cutting-edge hardware integrated with comprehensive software solutions makes the TS-1273AU-RP the preeminent choice to tackle resource-demanding applications and tasks.

• Both 2.5GbE ports are backwards compatible with 1GbE/ 100MbE/ 10MbE speeds. Up to 5 Gbps transfer speeds can be achieved by using port trunking.

• Add extra functionality to the TS-1273AU-RP with PCIe cards, including 10GbE ports, SSD caching, extra USB 3.2 Gen 2 ports, wireless networking, or Fibre Channel.

• Supports entry-level NVIDIA® graphics cards for video processing or GPU-passthrough to VMs.

• Qtier™ technology and SSD caching enable 24/7 optimized storage efficiency.

• Host multiple virtual machines and containers to run a wide range of applications on the TS-1273AU-RP.

• Supports block-based and file-based cloud storage gateways with local caching for low-latency access to cloud data.

Absolute performance with AMD Ryzen™ and up to 32GB RAM

Powered by a 4-core/8-thread AMD Ryzen™ V1500B 2.2GHz processor with AES-NI encryption acceleration and up to 32GB DDR4 RAM, the rackmount TS-1273AU-RP delivers aggressive yet power-smart performance to drive resource-demanding business applications such as VDI, R&D, private cloud, and server virtualization.

Block-based iSCSI LUN: Ideal choice for virtualization storage

The TS-1273AU-RP supports block-based iSCSI LUN and is compatible for VMware®, Citrix®, Microsoft® Hyper-V®, and Windows Server® 2019 virtualization environments to provide a high-performance and affordable storage solution. The TS-1273AU-RP also supports VMware VAAI and Microsoft ODX to increase performance by offloading server loading for ESXi server and Hyper-V respectively, and supporting QNAP vSphere Client plug-in with enhanced operational efficiency and management in virtualization applications.

Optimized performance for VMware Virtualization with iSER

The iSCSI Extensions for RDMA (iSER) protocol boosts the data transfer performance of VMware® ESXi storage and reduces the CPU load of the ESXi server. iSER support can be added to the TS-1273AU-RP by installing a QNAP QXG-10G2SF-CX4 10GbE PCIe card, which uses the Mellanox® ConnectX-4 controller. iSER can provide a significant increase in performance, providing an essential tool to optimize demanding virtualization applications.

All-in-one server to host virtual machines and containers

Regardless of your virtualization needs, you can count on Virtualization Station and Container Station for complete virtualization support. Use the Network & Virtual Switch app to allocate adequate physical network resources to virtual machines, containers, and the TS-1273AU-RP to simplify network deployment.

Number of Hard Drives Supported: 12

Number of Hard Drives Installed: 0

Number of Solid State Drive Supported: 12

Number of Solid State Drive Installed: 0

Flash Memory Capacity: 5 GB

Processor Manufacturer: AMD

Processor Type: Ryzen

Processor Model: V1500B

Processor Core: Quad-core (4 Core)

Processor Speed: 2.20 GHz

Standard Memory: 8 GB

Memory Technology: DDR4 SDRAM

Ethernet Technology: 2.5 Gigabit Ethernet

Number of Total Expansion Bays: 8

Number of 2.5"/3.5" Bays: 8

Total Number of Expansion Slots: 2.0

Expansion Slot Type: PCI Express 3.0 x4

Controller Type: Serial ATA/600

RAID Supported: Yes

RAID Levels: 0, 1, 5, 6, 10, 50, 60, Hot Spare, JBOD

Total Number of USB Ports: 4

Number of USB 3.2 Gen 1 Ports: 1

Network (RJ-45): Yes

Number of Network (RJ-45) Ports: 2

Operating System: QTS 4.4.2

Protocols: TCP/IP,IPv4,IPv6,DHCP,iSCSI,DDNS,NAT,NFSv2,HTTP,HTTPS,WEBDAV,SSL,SSH,Telnet,FTP,CIFS/SMB,AFP,NFSv3,SMSC,SMTP,LDAP,UPnP,SNMP,NFS,SFTP,TFTP,SSL/TLS,FTPS,FXP,RSync,RTSP,PPTP,L2TP,IPSec,DLNA,SNMPv2,SNMPv3

Number of Power Supplies Installed: 2

Maximum Power Supply Wattage: 300 W

Redundant Power Supply: Yes

Height: 3.50" (89 mm)

Width: 18.98" (482 mm)

Depth: 35.42 ft (10795 mm)

Form Factor: Rack-mountable

Rack Height: 2U

Weight (Approximate): 9.69 kg

Package Contents:

• TS-1273AU-RP-8G SAN/NAS Storage System
• 1 x Ethernet Cable
• 2 x Power Cords
• 48 x Flat Head Screws (for 3.5" HDD)
• 36 x Flat Head Screws (for 2.5" HDD)
• Quick Installation Guide (QIG)

Country of Origin: Taiwan

Limited Warranty: 2 Year
