Marketing Information: TS-1655 | Powerful 2.5GbE hybrid storage solution, 8-core high performance and 16-bay high capacity, and long-term availability
Balance performance and cost with hybrid storage. Designed for diversified business IT environments, the high-capacity TS-1655 has twelve 3.5-inch SATA drive bays (for HDDs) and four 2.5-inch SATA drive bays (for SSDs) with 2.5GbE high-speed connectivity. Fueled by an immense 8-core Intel Processor, the TS-1655 presents a secure, scalable, and complete business-ready storage solution for cross-team file sharing, collaboration, backup & disaster recovery, virtualization, and intensive data transmission. The TS-1655 will be available and supported by QNAP for an extended period (up to 2027), ideal for businesses requiring matching NAS models deployed in multiple locations.
- Dual 2.5GbE connectivity
High-speed 2.5GbE accelerates intensive file access, large backup/restoration tasks, virtualization, and multimedia transfer.
- SSD caching and AI acceleration
Two M.2 NVMe PCIe Gen 3 slots allow implementing SSD cache acceleration, SSD storage pool, or a Coral M.2 accelerator for faster image recognition.
- Flexible PCIe expansion
Three PCIe slots allow for installing 5/10/25GbE adapters, Fibre Channel cards, or QM2 cards to increase application performance.
- Virtual machines and containers
Host virtual machines and containerized apps on one device to optimize resource utilization and IT budgeting. Supports SR-IOV.
- Hybrid cloud
Realize hybrid cloud applications by working with the cache space reserved on NAS to ensure low-latency cloud data access.
- Storage scalability
Satisfy ever-growing storage needs by connecting flexible and economical QNAP expansion enclosures.
Eight cores up to 2.8 GHz, Intel® QuickAssist Technology, and up to 128 GB memory
The TS-1655 adopts the Intel® Atom® C5125 8-core 2.8 GHz processor that supports Intel® QuickAssist Technology (QAT), offloading computationally-intensive compression and improving IPsec/SSL cryptography performance. The TS-1655 comes with four UDIMM DDR4 slots (8 GB preinstalled) that can be upgraded to 128 GB for higher workloads. Error-Correcting Code memory is also supported to deliver server-grade performance and reliability for rugged enterprise IT environments as a cost-efficient NAS solution.
Number of Hard Drives Supported: 12Number of Hard Drives Installed: 0Number of Solid State Drive Supported: 12Number of Solid State Drive Installed: 0Flash Memory Capacity: 5 GBNumber of Processors Installed: 1Processor Manufacturer: IntelProcessor Type: AtomProcessor Model: C5125Processor Core: Octa-core (8 Core)Processor Speed: 2.80 GHzStandard Memory: 8 GBMemory Technology: DDR4 SDRAMEthernet Technology: 2.5 Gigabit EthernetNumber of Total Expansion Bays: 12Number of 2.5"/3.5" Bays: 12Number of Total Expansion Slots: 3Expansion Slot Type: PCI Express 3.0 x4Controller Type: Serial ATA/600RAID Supported: YesRAID Levels: 0, 1, 5, 6, 10, 50, 60, JBODHDMI: YesTotal Number of USB Ports: 4Number of USB 3.2 Gen 1 Ports: 4Network (RJ-45): YesNumber of Network (RJ-45) Ports: 2Operating System: QuTS hero 5.0.1Protocols: - IPv4
- IPv6
- DHCP
- CIFS/SMB
- AFP
- NFSv3
- FTP
- FTPS
- SFTP
- TFTP
- HTTP
- HTTPS
- Telnet
- SSH
- iSCSI
- SNMP
- SSL/TLS
- FXP
- WEBDAV
- LDAP
- DDNS
- DNS
- SNMPv2
- SNMPv3
- PPTP
- L2TP
- NFSv4
Maximum Power Supply Wattage: 550 WHeight: 11.59" (294.39 mm)Width: 14.56" (369.82 mm)Depth: 12.59" (319.79 mm)Form Factor: TowerWeight (Approximate): 13.16 kgPackage Contents: - Turbo NAS TS-1655-8G SAN/NAS Storage System
- 1 x Ethernet Cable
- 1 x Power Cord
- 36 x Flat Head Screw (for 3.5" HDD)
- 36 x Flat Head Screw (for 2.5" HDD)
- 2 x Drive Tray Keys
- Quick Installation Guide (QIG)
Limited Warranty: 3 YearAdditional Warranty Information: The TS-1655 is backed by a 3-year warranty at no additional cost.
[custom-specifications]
SpecificationsManufacturer: QNAP Systems
Manufacturer Part Number: TS-1655-8G-US
Manufacturer Website Address: http://www.qnap.com
Brand Name: QNAP
Product Line: Turbo NAS
Product Model: TS-1655-8G
Product Name: Turbo NAS TS-1655-8G SAN/NAS Storage System
Product Type: SAN/NAS Storage System
StorageNumber of Hard Drives Supported: 12
Number of Hard Drives Installed: 0
Number of Solid State Drive Supported: 12
Number of Solid State Drive Installed: 0
Flash Memory Capacity: 5 GB
Processor & ChipsetNumber of Processors Installed: 1
Processor Manufacturer: Intel
Processor Type: Atom
Processor Model: C5125
Processor Core: Octa-core (8 Core)
Processor Speed: 2.80 GHz
MemoryStandard Memory: 8 GB
Memory Technology: DDR4 SDRAM
Network & CommunicationEthernet Technology: 2.5 Gigabit Ethernet
I/O ExpansionsNumber of Total Expansion Bays: 12
Number of 2.5"/3.5" Bays: 12
Number of Total Expansion Slots: 3
Expansion Slot Type: PCI Express 3.0 x4
ControllersController Type: Serial ATA/600
RAID Supported: Yes
RAID Levels: 0, 1, 5, 6, 10, 50, 60, JBOD
Interfaces/PortsHDMI: Yes
Total Number of USB Ports: 4
Number of USB 3.2 Gen 1 Ports: 4
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
SoftwareOperating System: QuTS hero 5.0.1
Management & ProtocolsProtocols:
- IPv4
- IPv6
- DHCP
- CIFS/SMB
- AFP
- NFSv3
- FTP
- FTPS
- SFTP
- TFTP
- HTTP
- HTTPS
- Telnet
- SSH
- iSCSI
- SNMP
- SSL/TLS
- FXP
- WEBDAV
- LDAP
- DDNS
- DNS
- SNMPv2
- SNMPv3
- PPTP
- L2TP
- NFSv4
Power DescriptionMaximum Power Supply Wattage: 550 W
Physical CharacteristicsHeight: 11.59" (294.39 mm)
Width: 14.56" (369.82 mm)
Depth: 12.59" (319.79 mm)
Form Factor: Tower
Weight (Approximate): 13.16 kg
MiscellaneousPackage Contents:
- Turbo NAS TS-1655-8G SAN/NAS Storage System
- 1 x Ethernet Cable
- 1 x Power Cord
- 36 x Flat Head Screw (for 3.5" HDD)
- 36 x Flat Head Screw (for 2.5" HDD)
- 2 x Drive Tray Keys
- Quick Installation Guide (QIG)
WarrantyLimited Warranty: 3 Year
Additional Warranty Information: The TS-1655 is backed by a 3-year warranty at no additional cost.
