QNAP Turbo NAS TVS-1282T-I7-64G SAN/NAS/DAS Storage System - Intel Core i7 i7-6700 Quad-core (4 Core) 3.40 GHz - 8 x HDD Supported - x (TVS-1282T-I7-64G-US)

Marketing Information:

The TVS-1282T features advanced hardware by adopting 6th Generation Intel® 14nm multi-core processors and was designed around the concept of tiered storage, application-based partitioning and network traffic distribution. Providing a Thunderbolt DAS/NAS/iSCSI SAN triple solution, the TVS-1282T delivers the incredible power of Thunderbolt™ 2 to double the speed potential to 20 Gbps, supports smooth 4K video transfer, and is a perfect match for Thunderbolt-equipped Mac* users for 4K workflows, file storage and high-speed sharing. Incorporating reliability, security and rich applications, the TVS-1282T delivers the highest transfer rates ever as storage with persistent throughput, and provides a complete business-ready storage solution.

• Built-in M.2 SATA 6Gb/s slots & 2.5" SSD slots
• Qtier technology and SSD cache enable 24/7 optimized storage efficiency
• The Network & Virtual Switch app assists network traffic distribution, and re-routes dedicated bandwidth for diverse applications
• Triple HDMI output for smooth 4K video playback
• Thunderbolt™ 2 (20Gbps) and 10GbE dual network for on-the-fly video editing and speedy sharing
• 4 available combinations with Mac/PC and JBOD for flexible attaching, sharing and expansion
• Scalable up to 448 TB with the Thunderbolt™ 2 storage expansion enclosures TX-800P/ TX-500P
• Virtual JBOD (VJBOD) allows to use QNAP NAS to expand the TVS-1282T's storage capacity
• Supports QRM+ unified remote server management, QvPC technology, virtual machine and container applications, and storage for virtualization

The TVS-1282T provides two options powered by a high-performance Intel® Core™ i5 quad-core processor with 16GB DDR4 RAM and Intel® Core™ i7 quad-core processor with 64GB DDR4 RAM, driving outstanding system performance for CPU-demanding applications. Offering a comprehensive DAS/NAS/iSCSI SAN multi-mode storage solution in a compact form factor, the TVS-1282T not only features Thunderbolt™ 2 technology but also has dual 10GbE ports giving you incredible flexibility for network connectivity.

Advanced hardware for greater efficiency

High-performance hardware, well-designed application functionalities and thoroughly-planned usage scenarios are three distinctive cornerstones for achieving optimum performance.

M.2 SATA 6Gb/s SSD & 2.5" SSD cache

The TVS-1282T provides 4 SSD slots dedicated for caching to increase IOPS performance, and provides higher transfer speeds and reliability with the compact, energy-efficient M.2 SSD. Using an SSD cache boosts overall system performance, and is perfect for improving overall workflow of random IOPS demanding applications such as virtualization. The TVS-1282T combines M.2 SSD, 2.5" SSD and HDD in one box to effectively realize tiered storage for exceptional application performance and lower TCO of storage at the same time.

Perfect storage trio: tiered storage, application-based partitioning & network traffic distribution

The advanced hardware design of TVS-1282T can facilitate optimized storage deployment based on different usage scenarios.

Number of Hard Drives Supported: 8

Number of Hard Drives Installed: No

Number of Solid State Drive Supported: 12

Number of Solid State Drive Installed: No

Flash Memory Capacity: 512 MB

Processor Manufacturer: Intel

Processor Type: Core i7

Processor Model: i7-6700

Processor Core: Quad-core (4 Core)

Processor Speed: 3.40 GHz

Standard Memory: 64 GB

Memory Technology: DDR4 SDRAM

Ethernet Technology: 10 Gigabit Ethernet

Number of Total Expansion Bays: 12

Number of 2.5" Bays: 4

Number of 2.5"/3.5" Bays: 8

Total Number of Expansion Slots: 3

Expansion Slot Type: PCI Express x8,PCI Express 3.0 x4

Controller Type: Serial ATA/600

RAID Supported: Yes

RAID Levels: 0, 1, 5, 6, 10, Hot Spare, JBOD

Host Interface: Thunderbolt 2

HDMI: Yes

Total Number of USB Ports: 4

Number of USB 3.0 Ports: 4

Network (RJ-45): Yes

Operating System: QTS 4.2

Protocols: DNS,Telnet,DLNA,IPv6,FTPS,RSync,WEBDAV,SSL/TLS,AFP,CIFS,Bonjour,HTTPS,FTP,NFSv3,SMSC,SSH,DHCP,SMB,SMTP,FXP,SFTP,AFP 3.3,LDAP,iSCSI,TFTP,IPv4,UPnP,TCP/IP,PPTP,HTTP,DDNS,CIFS/SMB,SNMP

Maximum Power Supply Wattage: 250 W

Height: 9.24" (234.60 mm)

Width: 14.56" (369.90 mm)

Depth: 12.59" (319.80 mm)

Form Factor: Tower

Weight (Approximate): 25.46 lb (11550 g)

Package Contents:

• Turbo NAS TVS-1282T-I7-64G SAN/NAS/DAS Storage System
• 4 x Ethernet Cables
• 2 x 10Gbase-T Ethernet Cables
• 1 x Power Cord
• 2 x Screws for M.2 Installation
• 2 x Bolts
• 24 x Flat Head Screws (for 2.5" HDD)
• 2 x M.2 SSD Heatsink
• IR Remote Control
• Quick Installation Guide

Limited Warranty: 2 Year
