Server Technology 36-Outlets PDU - Basic - NEMA L6-30P - 18 x IEC 60320 C13, 18 x CX - 230 V AC - Branch Circuit, Circuit Protection, (C3B36RL-2CJE0AT4)

(No reviews) Write a Review
$1,289.51
$1,277.57
$1,222.03
(You save $67.48 )
SKU: C3B36RL-2CJE0AT4
Weight: 23.00 LBS
Adding to cart… The item has been added
  • HDOT Cx Outlet: Cx is the future-ready UL tested hybrid of a C13 and C19 outlet accommodating both C14 and C20 plugs.
  • RamLock Locking Outlets: A mechanical locking mechanism built to secure the broadest range of C14 and C20 plugs in place.
  • Branch Circuit Protection: This PDU meets the UL and IEC 62368-1 requirement for branch circuit protection through UL 489 rated magnetichydraulic circuit breakers or UL 248 fuses.
  • High Temperature Rating: This product has been tested and approved for safe and reliable operation in 60 °C data center environments.
  • Flexible Mounting: Includes standard button mounts along with provisions for custom mounting brackets.
  • Color-Coded Options: Select from six colors to designate PDU circuits in the data center - black, white, red, green, blue, and yellow.
    Marketing Information:

    The all-new Server Technology Basic PDU features RamLock, a self-locking, elbow-catch mechanism to prevent accidental cord disconnects on standard power cords along with HDOT Cx, a hybrid C13/C19 outlet that accepts either an IEC C14 or C20 plug. The PDU features dedicated HDOT C13 outlets and HDOT Cx, which can be treated as either a C13 or C19 outlet. The Server Technology Basic PDU provides reliable power distribution for installing IT equipment into the rack/cabinet.


    PDU Type: Basic
    Plug/Connector Type: NEMA L6-30P
    Receptacle Type:
    • IEC 60320 C13
    • CX

    Receptacle Detail:
    • 18 x IEC 60320 C13
    • 18 x CX

    Protection Type:
    • Branch Circuit
    • Circuit Protection
    • Circuit Breaker
    • Fuse

    Locking Receptacles: RamLock Locking Outlet
    Input Voltage: 230 V AC
    Output Voltage: 208 V AC
    Power Rating (Watt): 5 kW
    Input Current: 30 A
    Input Frequency: 60 Hz
    Mount Type:
    • Rack-mountable
    • Cabinet-mountable
    • Button Mount

    Rack Height: 0U
    Height: 70" (1778 mm)
    Width: 2.20" (55.88 mm)
    Depth: 2.50" (63.50 mm)
    Minimum Operating Temperature: 32°F (0°C)
    Maximum Operating Temperature: 140°F (60°C)
    Minimum Operating Humidity: 8%
    Maximum Operating Humidity: 90%
    Minimum Storage Temperature: -40°F (-40°C)
    Maximum Storage Temperature: 185°F (85°C)
    Package Contents:
    • 36-Outlets PDU
    • Standard Button Mounts

    Application/Usage:
    • Data Center
    • Server Rack/Cabinet
    • IT Equipment

    Limited Warranty: 2 Year

[custom-specifications]

Specifications
Manufacturer: Server Technology, Inc
Manufacturer Part Number: C3B36RL2CJE0AT4
Manufacturer Website Address: http://www.servertech.com
Brand Name: Server Technology
Product Name: 36-Outlets PDU
Product Type: PDU
Technical Information
PDU Type: Basic
Plug/Connector Type: NEMA L6-30P
Receptacle Type:
  • IEC 60320 C13
  • CX

Receptacle Detail:
  • 18 x IEC 60320 C13
  • 18 x CX

Protection Type:
  • Branch Circuit
  • Circuit Protection
  • Circuit Breaker
  • Fuse

Locking Receptacles: RamLock Locking Outlet
Power Description
Input Voltage: 230 V AC
Output Voltage: 208 V AC
Power Rating (Watt): 5 kW
Input Current: 30 A
Input Frequency: 60 Hz
Physical Characteristics
Mount Type:
  • Rack-mountable
  • Cabinet-mountable
  • Button Mount

Rack Height: 0U
Height: 70" (1778 mm)
Width: 2.20" (55.88 mm)
Depth: 2.50" (63.50 mm)
Environmental Conditions
Minimum Operating Temperature: 32°F (0°C)
Maximum Operating Temperature: 140°F (60°C)
Minimum Operating Humidity: 8%
Maximum Operating Humidity: 90%
Minimum Storage Temperature: -40°F (-40°C)
Maximum Storage Temperature: 185°F (85°C)
Miscellaneous
Package Contents:
  • 36-Outlets PDU
  • Standard Button Mounts

Application/Usage:
  • Data Center
  • Server Rack/Cabinet
  • IT Equipment

Warranty
Limited Warranty: 2 Year

[/custom-specifications]
